Summary of Contents for Isokern MAGNUM 28

Page 1 Isokern® MAGNUM® Fireplace with Fire-Lite Application and DM Chimney System Installation, Operation, Maintenance and Owner’s Manual MAGNUM Models 28, 36, 42, 48, 60 & 72 A PRODUCT OF EARTHCORE INDUSTRIES, LLC. Important: This manual contains assembly rules, installation steps, guidelines, use and maintenance in- structions for the MAGNUM Series fireplace, DM 54 chimney system, and Fire-Lite Application with the FTF-13 Chimney System.
Page 2: Table Of Contents
TABLE OF CONTENTS General Information ............................Intended Use Statement ............................Safety Instructions .............................. Warnock-Hersey Listing Label ........................... Assembled Firebox & Smoke Dome Dimensions ....................Component List & Dimensions .......................... Assembled Firebox Dimensions 60 & 72......................Component List & Dimensions 60 & 72......................Required Clearance to Combustibles .........................
Page 3: General Information
Isokern fireplace and chimney system. The FTF- with a masonry adhesive. 13 or equivalent chimney system only must be used with The parts of the MAGNUM fireplace and DM 54 the Fire-Lite application.
Page 4: Intended Use Statement
Isokern is not responsible for other construction work around the fireplace unit. WARNING: This fireplace has not been tested for use with glass doors.
Page 5: Safety Instructions
9. Do not use a fireplace insert or any other product not specified for use with the MAGNUM fireplace and DM 54 chimney systems unless written authorization is given by Isokern. Failure to heed this warning may cause a fire hazard and will void the Isokern warranty.
Page 6 Isokern fireplaces. 15. Wherever insulation is used, the MAGNUM fireplace must not be placed directly against it. Keep all insulation or vapor barriers a minimum of three inches (3”) away from all...
Page 7: Warnock-Hersey Listing Label
FIGURE 1 Isokern Fireplace and Chimney Systems are tested and listed to UL standards: UL 127, ULC S610, and UL 103HT. The listing label shown in Figure 1 above outlines the listed clearances to combustibles and indicates that the units are suitable for use with solid fuel or listed gas appliances.
Page 8: Assembled Firebox & Smoke Dome Dimensions
Assembled Firebox & Smoke Dome Dimensions 28, 36, 42 & 48 2 3/4" 14" TOP PLAN VIEW 3" 5" SIDE VIEW FRONT VIEW PLAN SECTION A-A MODEL WEIGHT MINIMUM FRAMING: “G” “F” "A" "B" "C" "D" "E" 60 1/4" 31" 28"...
Page 9: Component List & Dimensions
Component List & Dimensions 28, 36, 42 & 48...
Page 10: Assembled Firebox Dimensions 60 & 72
Assembled Firebox Dimensions - Models 60 & 72 Top Plan View 3” Right Section Front Elevation Plan Section Model 60” 28” 85 3/4” 38” 69” 55 1/2“ 25 ¼” 4 3/4” 5” 8” 14 1/4” 11” 55 1/2” 73 1/2” 57 1/4”...
Page 11: Component List & Dimensions 60 & 72
Part Fireplace Quantity: Part Fireplace Quantity: Size: Size: Isokern reserves the right to make changes at any time, without notice in design, materials, specifications and also to discontinue styles and products. Please call 1-800-642-2920 for an Isokern dealer near you.
Page 12: Required Clearance To Combustibles
Required Clearance to Combustibles The MAGNUM Series fireplace and DM 54 chimney system is tested and listed for installation with “clearance to combustibles” as follows: The MAGNUM Series firebox side walls and back wall require 1-1/2” clearance. (Figure 3) 0” CLEARANCE The smoke dome front wall requires 0”...
Page 13: Rough Framing Dimensions & Corner Location Layout
Rough Framing Dimensions Rough Framing Dimensions Model Width Height Depth Model 28 38 1/2” 71” 29.5” Model 36 46” 71” 29.5” Model 42 52” 71” 29.5” Model 48 56” 71” 29.5” Model 60 78” 87” 29.5” Model 72 89” 87” 29.5”...
Page 14 Earthcore mortar is squeezed from a grout bag onto the contact surfaces of the Isokern components as they are fitted FIGURE 6 together.
Page 15: Assembly Instructions
It may be convenient to dry set the first course of side wall and back wall into place on the Isokern base plate FIGURE 11 and then to trace their position on the base plate with a pencil.
Page 16 Assembly Instructions - (cont.) Step 3: Continue assembly of the second, third and fourth courses of the firebox side wall and back wall. Apply mortar to the top of each layer of wall components, set the next course above into place.
Page 17 Assembly Instructions - (cont.) Step 7: With the damper beams assembled and mortared Make sure that the top plate is set so that the flue hole is together, set the cast iron throat damper on top of the damper closer to the back wall of the smoke dome assembly. plate and over the damper plate opening.
Page 18: Access Modification
CAUTION: When using the decorative appliance, the fireplace damper must be set in the fully open position. Gas line for gas log sets used in the Isokern firebox can be FIRE BRICK SIDE routed through the side wall, back wall or floor of the firebox by drilling an appropriately sized hole using a masonry drill bit (Figure 20).
Page 19: Firebrick Installation
NOTE: The 60 & 72 units require 4” Fire-Brick on the side walls. (NO GAPS) Isokern makes no claims as to the performance of fire brick or fire brick mortar(s). It is typical for heat stress cracks to appear in the fire bricks in wood burning fireplaces.
Page 20: Flush Wall Finish Detail
Flush Wall Finish Detail FRAMING PROTRUDES PAST FIREBOX FRONT DRYWALL FLUSH WITH FIREBOX FRONT FIGURE 26 FIGURE 25 MAGNUM fireplaces are designed to be installed so that the rough front face of the firebox and damper beam project into the room approximately one-half inch (1/2”) beyond the face of the rough framing members that create the room’s wall surface.
Page 21 Earthcore Mortar. Check for complete sealing of each contact joint while assembly progresses (see “General Isokern Assembly Instructions” on page 14 of this manual for mortar information and instructions). Step 1: Base plate, part M91, two required; All require field cutting.
Page 22: Assembly Instructions - 60
Assembly Instructions - 60” (cont.) Step 5: Continue stacking the remaining three courses of back wall. Be sure to reverse the positions of the 38-1/2” M67 and the 22-1/4” M67 in each successive course.In this way, the butt joint where the two M67 components meet are staggered from course to course.
Page 23 Assembly Instructions - 60” (cont.) Since the inside corner of the steel angle is rounded, it is a good idea to round the bottom front corner of the damper support to match the steel. With the bevel cut ends of the damper support pairs meeting at the middle of the firebox, the bevel joint should be an even and good fit.
Page 24 Assembly Instructions - 60” (cont.) Step 12: Cut one end of two of the smoke dome top large, part 13, components at an angle parallel to the opposite end of the piece. The bottom length of the cut piece should measure 23 3/4 ”...
Page 25 Note: The MAGNUM model 60 is designed to operate with two flues. The top of the smoke dome allows for the placement of two Isokern Modular Masonry DM 54 (14 inch I.D.) chimneys or two solid fuel listed metal chimneys of the FIGURE 43 appropriate size.
Page 26 Earthcore Mortar. Check for complete sealing of each contact joint while assembly progresses (see “General Isokern Assembly Instructions” on page 14 of this manual for mortar information and instructions). Step 1: Base plate, Part M91, two required . These pieces are used “as is”, without any field cutting required.
Page 27: Assembly Instructions - 72
Assembly Instructions - 72” (cont.) Next set the 34-1/2” inch cut M67 piece so that its tongue end interlocks with the side wall component at the opposite end of the base plate. The square cut end of the 34-1/2” M67 should make a snug butt joint with the square cut end of the 38 1/2”...
Page 28 Assembly Instructions - 72” (cont.) The damper support pair at the front of the firebox opening will be set into the 4” x 6” steel angle from Step 7 (Figure 56). Since the inside corner of the steel angle is rounded, it is a good idea to round the bottom front corner of the damper support to match the steel.
Page 29 Assembly Instructions - 72” (cont.) Step 13: Cut one end of the other two smoke dome top big, part 13, components at an angle parallel to the opposite end of the piece. The bottom length of the cut piece should measure 35 3/4”...
Page 30 Note: The MAGNUM model 72 is designed to operate with two flues. The top of the smoke dome allows for the placement of two Isokern DM 54 (14 inch I.D.) chimneys or two solid fuel listed metal chimneys of the appropriate size.
Page 31: Dm 54 Chimney System - 60 & 72
DM 54 Chimney System - 60 & 72” 22’-0” * NOTE: The maximum installed height of the Isokern DM 54 system on the models 60 & 72 dual chimney system is 22’ without additional structural support. * BKE Report dated March 30, 2011...
Page 32: Required Clearances (When Sheathing Protrudes Beyond Front Of Firebox)
Required Clearances (when sheathing protrudes beyond front of firebox) FINISHED OPENING 8" 8" FIGURE 70 MIN. DIM'N. MIN. DIM'N. WOOD (FLAMMABLE) SHEATHING 8" MIN. 8" MIN. FIGURE 71 Combustible sheathing such as plywood and particle board may be used to cover the front face of the MAGNUM smoke dome and be in direct contact with it.
Page 33: Required Clearance To Combustible Framing
(as determined through testing and as stated by the manufacturer) are not maintained due to construction subsequent to the installation of the Isokern unit. It is the general contractor’s responsibility to assure that listed clearances to combustible framing and to insulation are maintained throughout the construction of the project subsequent to the installation of the Isokern unit.
Page 34: Required Clearances To Insulation And Vapor Barriers
When MAGNUM fireplace installations are surrounded by walls that are to be insulated, the walls must have enough clearance to the Isokern unit in order to maintain the three inch (3”) minimum clearance to insulation. (Figure 75) Never spray the MAGNUM fireplace with any type of sealer, insulation or other material.
Page 35: Flush Wall Fire Brick Finish Detail
Flush Wall Fire Brick Finish Detail Drywall Flush With Firebox Front Noncombustible Facing Material FIGURE 76 Recommended Fire Brick Detail: When drywall is the wall finish at the MAGNUM face and flush with the rough face of the MAGNUM firebox and damper beam, it is recommended when installing the required fire brick lining to the interior of the firebox, that the leading edge of the fire brick - at the floor and at the side walls of the firebox - be set flush with the MAGNUM’s rough firebox front.
Page 36: Flush Wall Brick Finish Detail
Flush Wall Brick Finish Detail FIGURE 77 Important: Since there is no fire brick set along the top of the MAGNUM’s firebox opening, when setting the noncombustible finished facing material (code required and supplied by others) across the top of the firebox opening there may be a gap between the back of the noncombustible finish material and the rough front face of the MAGNUM damper plate.
Page 37: Interior Masonry Veneer Fireplace Finishes & Clearances
MASONRY VENEER ENDS OF ISOKERN FIREBOX UNIT AND MASONRY VENEER STEEL L ALIGN 3 1/2" 2" MIN. FIGURE 78 4x6 STEEL L ALIGN ALIGN 2" 4" MINIMUM BEARING CLEARANCE ISOKERN UNIT WIDTH D IM'N. EXTENT OF STEEL L FIGURE 79...
Page 38: Masonry Veneer Construction Details
Masonry Veneer Construction Details Brick, stone or other masonry veneer finished fronts to MAGNUM fireplaces are possible. Special attention is required with regards to: (1) the placement of the proposed masonry veneer facing and its interface with the MAGNUM fire brick WOOD (FLAMMABLE) lining, and SHEATHING...
Page 39: Non Combustible Finished Facing Requirements & Clearance To Combustible Trim
Non-combustible Finished Facing requirements & Clearance to Combustible Trim Hearth Extensions: MAGNUM fireplaces shall have hearth extensions of brick, concrete, stone, tile or other code approved COMBUSTIBLE 12" noncombustible material. Suitable hearth extension material MANTLE SHELF for the MAGNUM fireplace shall be placed on the hearth extension’s noncombustible substrate and must extend to at least twenty inches (20”) in front of the fireplace’s finished opening and must extend to at least twelve inches (12”) beyond...
Page 40: Concrete Support
1. Slab on grade: standard residential, minimum four inch (4”) thick, 2500 psi concrete foundations on properly compacted fill. This type foundation can support Isokern installations up to thirty feet (30’) overall height (brickledge installations not included). (Figure 84) 2. Slab-on-grade foundations, thickened and reinforced: for additional load carrying.
Page 41: Dm Chimney System
DM 54 Chimney System: General Information The DM 54 chimney is a dual module, refractory masonry chimney system. It is composed of two precast, mating components, the outer casing block and an inner liner. General Information: This chimney system is designed for installation in accordance with the National Fire Protection Standard for Chimneys and Solid Fuel-Burning Appliances, NFPA 211 and in accordance with codes such as ICC, BOCA Basic/National Codes, the standard Mechanical...
Page 42: Component List & Dimensions
DM 54 Chimney Component List & Dimensions 12” High ” Small 1 ¼ Inner Liner ” Crown Cap 3 ” 6 ” 6” High Inner Liner 1 ¼ Large ” Crown Cap 3 ” ” Outer Casing 6 ” Offset 3 ”...
Page 43: Component Weights
DM 54 Chimney: Component Weights Isokern DM Chimney Weights: Total installed Isokern DM chimney weight will vary according to each specific installation. Total installed chimney weight will be based on the overall height and the configuration of the chimney system.
Page 44: Installation
DM 54 Chimney Alignment: Where the chimney run is to be a straight vertical run OUTER the DM 54 outer casing block sits directly onto the Isokern CASING smoke dome lid. The DM 54 outer casing block, properly set is intended to be flush with the back face of the firebox smoke dome assembly (Figures 89 and 90 ).
Page 45: Lateral Support
DM 54 Chimney System: Lateral Support CAUTION: Maintain three inch (3”) minimum clearance to Additionally, a two inch (2”) by four inch (4”) by six insulation from all DM 54 chimney component surfaces. feet (6’) minimum pressure treated member (“rat run”) installed After setting the DM 54 inner liner starter piece, on each side of and butted up to the outer casing block will apply mortar to the top of the starter liner.
Page 46: Lateral Support
DM 54 Chimney System: Lateral Support (cont.) FIGURE 92 FIGURE 93...
Page 47: Offset Block
DM 54 Offset Chimney Block: For vertical DM 54 chimney to bypass overhead obstructions, the Isokern offset chimney block is used. Offset blocks are six inch (6”) thick, single module chimney components, measuring twenty-one and one-half inch (21-1/2”) wide by twenty-five inches (25”) long. The fourteen inch hole passes through the block at thirty (30°) degrees.
Page 48 DM 54 Chimney System: Offset Block (cont.) With straight chimneys the front of the DM 54 outer casing block sits approximately three and three-quarters inch (3- 3/4”) back from the front of the smoke dome. This allows for a nominal 4” thick wall to be flush with the room side face of smoke dome assembly while the DM 54 chimney passes up the backside of the wall.
Page 49 DM 54 Chimney System: Offset Block (cont.) Offset block Support Foundations: It is required that every third Isokern offset chimney block in the sequence be supported down to footings via concrete block or steel support columns. Plan fireplace and DM 54 chimney systems carefully before foundations are laid to assure that proper footings are available to support Isokern offset blocks chimney run.
Page 50: Offset Block
The total chimney weight above the last offset block will be the total weight of the vertical chimney plus any additional allowable loads such as the Isokern brickledge, its OVERHEAD OBSTRUCTION related brick or stone veneers, and any crown caps, clay pots or other masonry chimney terminations.
Page 51: Brick Ledge Installation
Temporarily leave out the inner liner that fits this outer casing block. Set the Isokern brickledge onto the flat top surface of the outer casing in a full bed of Earthcore Mortar. Be sure to align the four 2-1/2”...
Page 52: Brick Ledge Load Capacity
Brickledge Veneer Finish and Flashing Details: When applying brick, stone or other masonry veneer to the Isokern brickledge standard good building practices for masonry veneer work should govern weather-proofing details and the placement of flashings. A typical flashing detail would be to field fabricate an aluminum or galvanized sheet metal flashing, approximately thirty-two inches (32”)square with a twenty inch (20”) square...
Page 53: Crown Caps
The small crown cap is intended for use where DM 54 FLASHING chimneys are to receive thin veneers and cultured stone that do not require the installation of the Isokern brickledge. The small crown cap is also suitable where DM 54 chimneys are to receive FIGURE 106 a stucco finish.
Page 54: Height Requirements
CRICKET Chase enclosures need to be built to local wind load requirements SECTION and shall be structurally independent of the Isokern chimney. As THRU ROOF with all chimney installations, avoid overhead obstructions such as trees, power lines, etc.
Page 55: Structural Information
Structural Information The MAGNUM firebox/smoke dome assembly has a load capacity that allows for the fireplace system to carry a CAST IRON limited amount of straight, vertical DM 54 chimney sections. DAMPER The load capacity for each model, stated as maximum DM 54 chimney heights, are as follows: FRONT DAMPER SUPPORT...
Page 56: Common Chimney Terminations
Common Chimney Terminations Two chimney terminations are offered by Isokern, the DM 54 large crown cap and the DM 54 small crown caps. These are cement crown caps designed to provide a weather cap to the DM 54 chimney system. Their design is typical of the cement caps found on traditional masonry chimneys.
Page 57: Class A Metal Flue
4. Triple-wall air space solid fuel chimney. 5. Listed chimney liners conforming with the seventeen hundred degree (1700°) Fahrenheit requirements of UL 1777 or ULCS635 or ULC640 may also be used with Isokern fireplaces. Notes: The selected, approved chimney manufacturer must provide the masonry anchor plate designed to fit their flue system.
Page 58: Specialty Applications
Specialty Applications - Two Story Stacked Installations General Information: To install one MAGNUM fireplace and DM 54 chimney system above another, as in a two story stacked installation, both the upper and lower fireplace installations require a concrete slab that is supported down to footings via concrete or steel support structure.
Page 59 “D” is also the sum of “B” plus “C”. “E” is the height of the MAGNUM fireplace chosen for the lower unit and includes the Isokern three inch thick base plate. “E” is seventy inches (69 ½” actual) for all of the MAGNUM models.
Page 60: Fire-Lite Application General Information
Fire-Lite Application - General Information General Information: The Fire-Lite is a fireplace designed, tested and listed with the ability to be installed on a combustible floor system. The design and installation require that the system use FTF- 13, Class A metal flue, or equal. Also the Fire-Lite assembled unit must sit on a raised, noncombustible platform.
Page 61: Fire-Lite Application - Required Clearance To Combustibles
Fire-Lite Application - Required Clearance To Combustibles The Fire-Lite is tested and listed for installation with “clearance to combustibles” as follows: 2” min. 2” min. Four inches (4”) clearance to the combustible floor. FTF 13 Metal Chimney Zero inch (0”) clearance at the Fire-Lite smoke dome front wall (Figure 125).
Page 62: Fire-Lite Application - Combustible Floor System
Consult your local structural engineer for proper floor system design, sizing and specifications. Isokern is not responsible for structural floor support details for the Fire-Lite fireplace. Unless otherwise noted all floor framing drawings in this manual are merely illustrations to indicate the presence of an underlying floor system.
Page 63: Fire-Lite Application - Raised Metal Platform
Fire-Lite Application - Raised Metal Platform The noncombustible raised platform must be set with a minimum one and one half inch (1-1/2") clearance to the wall directly behind the Fire-Lite assembly. Raised Platform: Nominal four (4") metal base. (Figure 129).Set the Fire-Lite base plate in a mortar bed on to the non-combustible raised platform.
Page 64 Fire-Lite Application - Raised Metal Platform (cont.) 14GA. Metal Chanel with a 3” Dia. Hole Centered in each 12” Cavity 1” Thick Insboard onWood Sub-Floor Air From Exterior Air From Room Floor Joists FIGURE 131...
Page 65: Fire-Lite Application - Flush Wall Finish Detail
Fire-Lite Application - Flush Wall Finish Detail FIGURE 132 FIGURE 133 Fire-Lite fireplaces are designed to be installed so that the rough front face of the firebox and damper plate project into the room approximately one-half inch (1/2”) beyond the face of the rough framing members that create the room’s wall surface. The smoke dome unit sits two and three-fourths inches (2 3/4”) back from the rough face of the firebox and damper plate.
Page 66: Ftf-13 Or Equivalent Chimney System
FTF-13 or Equivalent Chimney System The Fire-Lite is designed, tested and listed for use with FTF- 13 Class A metal chimney system, or equal. Do not modify or alter metal flue or metal flue components as this could result in an unsafe and potentially dangerous installation that may cause a serious hazard and void the listings, approvals and the limited warranty of the system.
Page 67 FTF-13 or Equivalent Chimney System (cont.) Installation of the FTF-13 Metal Chimney System for the Fire- Lite: Transition from the Fire-Lite to the FTF-13 Metal Chimney System: The FTF-13 metal flue attaches to the smoke dome’s top plate by use of the anchor plate. The Anchor Plate is fitted with an octagonal base plate to affix it to the smoke dome’s top plate.
Page 68: Ftf-13 Or Equivalent Installation Components
FTF-13 Installation Components Round Termination FireStop Spacer (30°) FireStop Spacer Offset/Return Package (30°) Chimney Section Combination Offset Return Elbow Stabilizer Anchor Plate Locking Band...
Page 69: Summary
3. Log grates are required for burning solid fuel in the 2. Magnum Fireplace and Fire-Lite Fireplace Curing Isokern fireplace. Grates allow for easy air flow up through Instructions: the burning logs thus creating a more complete and efficient It is critical that the Isokern masonry elements in the burning of the fuel.
Page 70 (sealed to the opening with masking tape) before brush fireplace is in operation. Isokern does not limit the use of cleaning. Do not remove sheet until the soot has settled. It is fireplace screens.
Page 71: Notes
Notes...
Page 72 ISOKERN is not responsible for misuse or mishandling of components. Nothing in this warranty makes ISOKERN, or any division thereof, liable in any respect for any injury or damage to the building or structure in which the fireplace or chimney system has been installed or to persons or property therein arising out of the use, misuse, or installation of properly manufactured ISOKERN product.
