Isokern
Installation, Operation, Maintenance and Owner's Manual
Important: This manual contains assembly rules, installation steps, guidelines, use and maintenance instructions for
the MAGNUM 82060 & 82072 Series fireplace and the DM chimney system. This manual must become the property
of and be reviewed by all current and future users of this product. It is the responsibility of the general contractor
and the installer of this product to ensure that the instructions in this manual are followed exactly and, further that
any allowed gas log appliance used in this product be installed in strict accordance with NFPA 58, NFPA 54/ANSI
Z223.1 and the gas log manufacturer's explicit installation, sizing and operation instructions. It is the responsibility
of the general contractor to provide adequate clearances from all firebox surfaces as specified in this manual.
Be Sure to Read Entire Manual Before Beginning Construction.
Contents of this manual may change without prior notification.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warning exactly could
result in serious injury, death, or property damage.
— Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Leave the building immediately.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call
the fire department.
— Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
THESE FIREPLACES ARE DESIGNED for USE with:
Solid Wood Logs, PROPANE (LP) or NATURAL GAS (NG), ONLY
THIS MANUAL CAN ONLY BE REPRODUCED IN ITS ENTIRETY
MAGNUM
®
and DM Chimney System
Isokern MAGNUM Models 82060 & 82072
A PRODUCT OF EARTHCORE
INSTALLER: Leave this manual with the fireplace
CONSUMER: Retain this manual for future reference
Fireplace
®
INDUSTRIES, LLC
®
DO NOT install the MAGNUM Series Fireplace in a
manufactured home or mobile home or recreational
vehicle.
Listing Services Report NO. 3082504-T1
SBCCI NO. 9626
NYC-MEA 241-90-E
ICC Report NO. ESR-2316
LA RR NO. 25483
IBC 2006, IRC 2006, IMC 2006
Issued: June 2016
Revision: 001
©2016 Earthcore Industries, LLC
