Installation, Operation, Maintenance
MAGNUM
Important: This manual contains assembly rules, installation steps, guidelines, use and maintenance instructions
for the MAGNUM 82084, 82096, 82108 & 82120 fireplaces with the ECO-STEEL & ECOSTEEL + Chimney System. This
manual must become the property of and be reviewed by all current and future users of this product. It is the re-
sponsibility of the general contractor and the installer of this product to ensure that the instructions in this manual
are followed exactly and that any allowed gas log appliance used in this product be installed in strict accordance
with NFPA 58, NFPA 54/ANSI Z223.1 and the gas log manufacturer's explicit installation, sizing and operation in-
structions. It is the responsibility of the general contractor to provide adequate clearances from all firebox surfaces
as specified in this manual.
Be Sure to Read Entire Manual Before Beginning Construction.
Contents of this manual may change without prior notification.
DO NOT install the MAGNUM Series Fireplace in a manufactured home or mobile home or recreational vehicle.
THESE FIREPLACES ARE DESIGNED for USE with: Solid Wood Logs
APPROVED WITH DECORATIVE GAS APPLIANCE with PROPANE (LP) or NATURAL GAS (NG), ONLY
THIS MANUAL CAN ONLY BE REPRODUCED IN ITS ENTIRETY
MAGNUM
®
and Owner's Manual
Models 82084, 82096, 82108 & 82120
A PRODUCT OF EARTHCORE INDUSTRIES, LLC.
INSTALLER: Leave this manual with the fireplace
CONSUMER: Retain this manual for future reference
Fireplace
®
©2019 Earthcore Industries, LLC
Listing Services Report NO. F17-237
ICC Report NO. ESR-2316
Issued: April 2019
Revision: 000
