Isokern
See-Thru Glass-Front Gas Fireplace and Chimney System
Installation, Operation, Maintenance and Owner's Manual
with Glass Front Kits GFK-48ST, GFK-72ST, GFK-96ST & GFK-120ST
IMPORTANT: This manual contains assembly rules, installation steps and guidelines, and use and maintenance instructions
for Isokern MAXIMUS Linear Series See-Thru with Glass Front Kit gas appliances. This manual must become the property
of and be reviewed by all current and future users of this product. It is the responsibility of the distributor, general
contractor, and the installer of this product that the instructions in this manual are followed exactly and, further that the
allowed gas log appliance used in this product be installed in strict accordance with the gas log manufacturer's listing and
explicit installation and operation instructions.
Be Sure to Read Entire Manual Before Beginning Construction.
THESE FIREPLACES ARE DESIGNED FOR USE WITH:
THIS MANUAL CAN ONLY BE REPRODUCED IN ITS ENTIRETY
MAXIMUS Linear Series
®
Isokern Models 82L48ST, 82L72ST, 82L96ST & 82L120ST
A PRODUCT OF EARTHCORE
INSTALLER: Leave this manual with the appliance
CONSUMER: Retain this manual for future reference
Contents of this manual may change without prior notification.
PROPANE (LP) or NATURAL GAS (NG), ONLY
INDUSTRIES, LLC
®
Do not install the Isokern MAXIMUS Linear Series
Gas Fireplace in a manufactured home or mobile
home or recreational vehicle.
—
This appliance complies with National Safety and
is tested and listed to ANSI/CSA Z21.50 – 2019 as
vented gas fireplaces.
—
Installation must conform to local codes. Check
local codes prior to installation. In the absence of
local codes, installation must conform with
current National Fuel Gas Code, ANSI Z223.1.
PFS Report No. F19-161
USA: ANSI Z21.50 - 2019
Canadian: CSA 2.22- 2019
Issued: February 2021
Revision: 000
©2020 Earthcore Industries, LLC
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Isokern Maximus Linear 82L48ST
Summary of Contents for Isokern Maximus Linear 82L48ST
- Page 1 IMPORTANT: This manual contains assembly rules, installation steps and guidelines, and use and maintenance instructions for Isokern MAXIMUS Linear Series See-Thru with Glass Front Kit gas appliances. This manual must become the property of and be reviewed by all current and future users of this product. It is the responsibility of the distributor, general contractor, and the installer of this product that the instructions in this manual are followed exactly and, further that the allowed gas log appliance used in this product be installed in strict accordance with the gas log manufacturer’s listing and...
-
Page 2: Table Of Contents
Earthcore Industries 11/30/2020 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Table of Contents Table of Contents ..............2 RS Chimney Fan – Horizontal Termination ....42 General Information ............... 3 Complete Electrical Schematic ........43 Safety Instructions ..............4 MFD Wiring ..............45... -
Page 3: General Information
SEISMIC CODE SPECIFICATIONS If installation of the Isokern Firebox is to be installed in an area with seismic codes please follow these instructions. Four #4 ASTM A615 Grade 40 minimum, vertical reinforcing bars, 2 on each side of the firebox running from top of sidewalls to approximately 4 inches into the concrete slab (for anchorage). -
Page 4: Safety Instructions
1) Always check local building codes governing fireplaces and fireplace installations. The Isokern Maximus Linear Series installation must comply with all local, regional, state, and national codes and regulations. 2) The Isokern Maximus Linear Series fireplaces are listed for use with the specific venting and burner system as detailed in this manual only. - Page 5 19) The Isokern Maximus Linear Series is not intended to heat an entire home or to be used as a primary heat source. 20) Children and adults should be alerted to the hazards of high surface temperature and should stay away from this appliance to avoid burns or clothing ignition.
-
Page 6: Isokern Maximus Linear Series See-Thru Glass Front Kit 48" (Gfk-48St)
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Isokern Maximus Linear Series See-Thru Glass Front Kit 48” (GFK-48ST) Component Part# Description Glass Panels (Qty: 2) E-TG1 Top Glass Bracket B (Qty: 2) E-BC1 Brick Cover Tall... - Page 7 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Isokern Maximus Linear Series See-Thru - 82L48ST Components You will need to order the 82L48ST and GFK-48ST to build the complete Glass Front Fireplace Component Part# Description...
-
Page 8: Isokern Maximus Linear Series See-Thru Glass Front Kit 72" (Gfk-72St)
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Isokern Maximus Linear Series See-Thru Glass Front Kit 72” (GFK-72ST) You will need to order the 82L72ST and GFK-72ST to build the complete Glass Front Fireplace Steel angle: 6” x 6” x 1/2” cut to span firebox opening. This item is not included in the components and can be sourced locally... - Page 9 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Isokern Maximus Linear Series See-Thru - 82L72ST Components You will need to order the 82L72ST and GFK-72ST to build the complete Glass Front Fireplace Steel angle: 6” x 6” x 1/2” cut to span firebox opening. This item is not included in the components and can be sourced locally...
-
Page 10: Isokern Maximus Linear Series See-Thru Glass Front Kit 96" (Gfk-96St)
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Isokern Maximus Linear Series See-Thru Glass Front Kit 96” (GFK-96ST) You will need to order the 82L96ST and GFK-96ST to build the complete Glass Front Fireplace Steel angle: 6” x 6” x 1/2” cut to span firebox opening. This item is not included in the components and can be sourced locally... - Page 11 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Isokern Maximus Linear Series See-Thru Glass Front Kit 96” (GFK-96ST) You will need to order the 82L96ST and GFK-96ST to build the complete Glass Front Fireplace Steel angle: 6” x 6” x 1/2” cut to span firebox opening. This item is not included in the components and can be sourced locally...
- Page 12 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Isokern Maximus Linear Series See-Thru - 82L96ST Components You will need to order the 82L96ST and GFK-96ST to build the complete Glass Front Fireplace Steel angle: 6” x 6” x 1/2” cut to span firebox opening. This item is not included in the components and can be sourced locally...
-
Page 13: Isokern Maximus Linear Series See-Thru Glass Front Kit 120" (Gfk-120St)
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Isokern Maximus Linear Series See-Thru Glass Front Kit 120” (GFK-120ST) You will need to order the 82L120ST and GFK-120ST to build the complete Glass Front Fireplace Steel angle: 6” x 6” x 1/2” cut to span firebox opening. This item is not included in the components and can be sourced locally... - Page 14 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Isokern Maximus Linear Series See-Thru Glass Front Kit 120” (GFK-120ST) You will need to order the 82L120ST and GFK-120ST to build the complete Glass Front Fireplace Steel angle: 6” x 6” x 1/2” cut to span firebox opening. This item is not included in the components and can be sourced locally...
- Page 15 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Isokern Maximus Linear Series See Thru – 82120ST Components You will need to order the 82L120ST and GFK-120ST to build the complete Glass Front Fireplace Steel angle: 6” x 6” x 1/2” cut to span firebox opening. This item is not included in the components and can be sourced locally...
-
Page 16: Required Clearance To Combustibles Framing
EXCEPTION: If insulation is used in walls surrounding the fireplace, insulation may be installed behind sheathing of gypsum board, plywood, particle board, or other rigid fire rated material on the side facing the Isokern. The facing material cannot be within 1-1/2” to the fireplace sidewalls. -
Page 17: Calculating Flooring Loads
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Calculating Flooring Loads Floor framing for Maximus Linear See-Thru installation will need to be designed and built to accept substantial dead loads spread over a relatively small floor area. (Figure 3). -
Page 18: Rough Framing Dimensions
For all “raised hearth” construction - even where concrete blocks are used to create the raised platform, it is still mandatory to use the Isokern base plate. Be sure to Earthcore Adhesive the concrete block platform together. All CMU used for base plate support should be rated ASTM 90. -
Page 19: General Assembly Instructions
(without lumps or dry pockets) of a “toothpaste” consistency. This mixture is suitable for application onto Isokern components by using a masonry grout bag supplied with the unit. Attention should be paid that the Earthcore Adhesive mixture is not too thin or runny, as this will not allow the Earthcore Adhesive to reach its maximum bonding strength. - Page 20 2) Set the first course of the firebox side walls, M65B, into place (Figure 9). NOTE: It may be convenient to dry set the first course of side walls in place on the Isokern base plate and then trace their position on the base plate. After outlining the dry set pieces, remove them and apply Earthcore Adhesive to the areas traced on the base plate where the side walls sit.
- Page 21 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Isokern Maximus Linear See-Thru Glass Front Installation 3) The Air Collector Box Assemblies will be placed on top of the base plate(s)as shown (Figure 10). CAUTION!!: The Glass Support Channels of the Air Collector Boxes must be aligned in the vertical and horizontal planes.
- Page 22 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Isokern Maximus Linear See-Thru Glass Front Installation 5) Continue assembly of the consecutive courses of the firebox side walls. Apply Earthcore Adhesive to the top of each layer of side wall components before setting the next course in place (Figure 12). Look for some Earthcore Adhesive to squeeze out along the joints of all contact surfaces as a sign that the joint is thoroughly sealed with the approved Earthcore Adhesive.
- Page 23 When properly installed, the angle iron will protrude ½” beyond the front edge of the side wall component (Figure 13). NOTE: It is not necessary to apply Earthcore Adhesive between angle and Isokern sidewall components. NOTE: The steel angle should not be longer than the width of the firebox.
- Page 24 End Block component where it will meet the front and back damper beam lintel components. Next, set the front Damper Beams into place. Magnum Damper End NOTE: Be sure to apply Earthcore Adhesive to contact surfaces between all Isokern components Block; Right: M94R Damper Beams (Rear): 48”: Part# 70...
- Page 25 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Isokern Maximus Linear See-Thru Glass Front Installation 9) For the 72”, 96”and 120” models, once the dampers beams are set into place, secure the Top Glass Bracket A (E-TG2) in place with the bottom of the angle steel as shown (Figure 15).
- Page 26 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Isokern Maximus Linear See-Thru Glass Front Installation Set the rear smoke dome component(s) across the damper beam in a bed of Earthcore Adhesive and flush with the back face of the rear damper beam lintel.
-
Page 27: Assembled Maximus Linear See-Thru Glass Front Units
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Assembled Maximus Linear See-Thru Glass Front Units Assembled 48” Maximus Linear See-Thru w/ GFK (82L48ST-GFK). Note: not shown but required are two cooling air kits. Assembled 72” Maximus Linear See-Thru... - Page 28 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Assembled Maximus Linear See-Thru Glass Front Units Assembled 96” Maximus Linear See-Thru w/ GFK (82L96ST-GFK). Note: not shown but required are four cooling air kits. Assembled 96” Maximus Linear See-Thru w/ GFK (82L120ST-GFK).
-
Page 29: Access Modification
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Access Modification Combustion Air Kits, Gas & Electrical Line Feed The Maximus Linear See-Thru with Glass Front requires 4” cooling air kits to provide cooling air to the glass for safe operation. The 48”... -
Page 30: B-Vent Metal Chimney - General Information
Install your Isokern fireplace as described in this installation manual and maintain all required clearances. Connect only one fireplace per chimney. Follow the fireplace safety manual for maximum efficiency and safety. Do not over fire. - Page 31 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace B-Vent Metal Chimney & Components Component Part# Description Component Part# Description 12M12 B-Vent 12" Length 12MGR B-Vent Guy Ring 12M18 B-Vent 18" Length 12M24 B-Vent 24" Length...
- Page 32 Anchor Plate with Down Draft Diverter. It is important that the surface of the Isokern chimney has a level surface on which to attach the Anchor Plate. If the top of the Isokern does not have a level surface, then it will need to be modified accordingly.
- Page 33 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace IMPORTANT: The B-Vent type chimney system must be enclosed within a chase when installed in or passing through a living area where combustibles or people may contact the chimney. This is important to prevent possible personal injury or fire hazard.
- Page 34 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Vertical Termination Systems – Vent Configurations NOTE: A B-Vent support plate (MSP) is required if vertical height exceeds 30 feet. Maximum of 30 feet between supports. 9) The vertical vent system will be terminated with a mechanical draft system. Installation instruction for the mechanical draft system begins on page 39 NOTE: Vertical termination skip steps 10 &...
- Page 35 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Horizontal Termination Systems – Vent Configurations 10) For horizontal terminations, install at least one 12“vertical pipe section on the anchor plate before any elbow installation NOTE: Two 45° elbows may be combined to achieve 90° offset.
-
Page 36: Enervex Rs Chimney Fan & Mfd Components
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Enervex RS Chimney Fan & MFD Components Component Part# Description Enervex RS 12 Chimney Fan w/ 101.0499.1200 controls Enervex RS 14 Chimney Fan w/ 101.0699.1200 controls Enervex RS 16 Chimney Fan w/ 101.0899.1200... -
Page 37: Mfd - General Information
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace MFD - General Information The ENERVEX MFD is a low profile, automated fireplace damper. It is for use in conjunction with an ENERVEX ADC100 control and RS model chimney fan as part of the Ecodamper System; It prevents excess heat from escaping through the chimney when the fireplace is not in use. -
Page 38: Rs Chimney Fan - General Information
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace RS Chimney Fan - General Information The RS Chimney Fan is a chimney top mounted ventilator that is designed to provide large flue gas volume capacities. It is designed and intended for use with gas-fired fireplaces. -
Page 39: Mfd- Vertical Termination Installation
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace MFD– Vertical Termination Installation Before installing the MFD on the chimney, a power cable should be wired to the actuator and the actuator cover should be secured (Figure 30). -
Page 40: Rs Fan Mechanical Installation
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace RS Fan Mechanical Installation Support system for the chimney fan Prior to installation of the chimney fan, it must be assured the chimney can safely carry the weight of the chimney fan. -
Page 41: Mfd - Horizontal Termination Installation
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace MFD – Horizontal Termination Installation Before installing the MFD on the chimney, a power cable should be wired to the actuator and the actuator cover should be secured (Figure 33). -
Page 42: Rs Chimney Fan - Horizontal Termination
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace RS Chimney Fan – Horizontal Termination To ease installation, detach the fan base by removing the bolts holding the hinges together. Center the fan base over the outlet and bolt the base onto the wall with the hinges pointing upwards (Figure 35). -
Page 43: Complete Electrical Schematic
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Complete Electrical Schematic FIGURE 38... - Page 44 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Enervex ADC 100 INSTALLATION Connection Diagram FIGURE 39 Overall Connection Diagram Notes • Power supply shall be from building source power on a dedicated circuit • RS fan wiring shall be dedicated for the fan; branching of the circuit will cause erratic fan behavior RS Fan and Mechanical Fireplace Damper may be installed in a vertical mount above the roof or in a horizontal mount on •...
-
Page 45: Mfd Wiring
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace MFD Wiring Wire that actuator for 2 wire/ 2 position operation as shown in Figure 40 (120 VAC) and Figure 41 below. The actuator should be set for clockwise (CW) rotation and should fail to 90⁰ (MFD will open). Verify settings of the actuator before wiring. -
Page 46: Enervex Adc 100 Installation
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Enervex ADC 100 INSTALLATION 1. The ADC100 Control Unit must be installed indoors. As shown in Figure 43, the control will be wired directly to a 120/1/60 VAC power supply. - Page 47 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Enervex ADC 100 INSTALLATION The probe must be installed between the appliance and the exhaust fan. If a damper is used in the system, the probe should be installed between the appliance and damper.
- Page 48 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Enervex ADC 100 Installation ADC 100 Terminal Designation The designations for each terminal on the control board are shown below. Note that Figure 48 only shows the terminals relevant to the Maximus Linear installation.
-
Page 49: Firebrick Installation - General Information
Firebrick Installation - General Information Earthcore/ Isokern requires the Maximus Linear Series fireboxes be lined with a minimum one and one-eighth (1-1/8”) thick firebrick (“Split”) for the sidewalls and 2-1/4” thick firebrick (“Full”) on the floor. Thicker firebrick may be used as an option. -
Page 50: Firebrick Installation - Maximus Linear Fireplace
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Firebrick Installation - Maximus Linear Fireplace Lay two courses of “full” sized firebrick so that the leading edge of the coursing is aligned with the cooling air vents of the air collector box. -
Page 51: Flush Wall Finish Detail
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Flush Wall Finish Detail Maximus Linear See -thru units shall be installed so that the rough front faces of the Isokern firebox are flush to the outside edges (room side) of the rough framing members that create the room wall’s finish... -
Page 52: Clearance To Combustible Trim
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Clearance to Combustible Trim NOTE: “Clearance to Combustible Trim” are those distances required to ensure that a fireplace mantel or facing will not catch fire. In most cases the distances should also be adequate to prevent any discoloration or warping due to heat. -
Page 53: Isoflames Linear Burner - Safety Instructions
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Isoflames Linear Burner - Safety Instructions WARNING!!!: This appliance assembly contains burner orifices specifically for the input gas specified on the burner and box, as well as the BTU rating specified in this manual. Modifying or failure to use the factory... - Page 54 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Isoflames Linear Burner - Safety Instructions 18) It is imperative that the unit’s control areas, burners and circulation air passages be kept clean. 19) Keep all combustible material, gasoline, and other flammable liquids at a safe distance from the fireplace. Do not use the appliance where these items are used or stored.
- Page 55 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Isoflames Linear Burner - Safety Instructions WARNING!!!: This product contains or generates chemicals known to the state of California to cause cancer or birth defects or other reproductive harm.
-
Page 56: Isoflames Linear Burner - Components List
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Isoflames Linear Burner - Components List NOTE: burner segment shown ① ③ Top view Bottom view ⑦ ⑨ ⑧ Table 2 Item No. Part Description Main Burner Assembly (natural gas) -
Page 57: Isoflames Linear Burner - Specifications
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Isoflames Linear Burner - Specifications Table 3 Burner Specifications Minimum Fireplace Dimension (in) Width Nat. Gas L.P. Gas Burner Model Depth Height Front Rear High High ISF36LB 17.5... -
Page 58: Gas Line & Valve Box Installation
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Gas Line & Valve Box Installation This appliance must be connected to the gas line in accordance with local codes and/or the National Fuel Gas Code, ANSI Z223.1. -
Page 59: Valve Box & Burner Wiring Diagram
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Valve Box & Burner Wiring Diagram WARNING!!!: Do not connect 120 V AC to the control valve The appliance and its appliance main gas valve must be disconnected from the gas supply piping system during and pressure testing of that system at test pressures in excess of 1/2 psi (3.5 kPa). -
Page 60: Burner Installation
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Burner Installation IMPORTANT: Prior to installation: Shut off main gas supply to fireplace. The ISOFLAMES Linear Burner system shall be installed by qualified professional service technician. To ensure proper performance of the appliance the owner’s installation manual must be followed carefully. - Page 61 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Burner Installation 1) Connect all burner segments according to burner model diagram page 62 - 64. Make sure all connections are tightly secured. 2) Place burner assembly in center of fireplace floor or cavity.
- Page 62 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace 36” Burner Connection - ISF36LB For Isokern Maximus Linear 82L48 ISF36LB Box No. Part No. Qty. E-18BP4 E-12BP1 60” Burner Connection – ISF60LB For Isokern Maximus Linear 82L72ST ISF60LB Box No.
- Page 63 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace 72” Burner Connection – ISF72LB For Isokern Maximus Linear 82L96ST ISF72LB Box No. Part No. Qty. E-18BP4 E-18BP5 E-12BP2 E-12BP3 E-BPC...
- Page 64 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace 96” Burner Connection - ISF96LB For Isokern Maximus Linear 82L120 ISF96LB Box No. Part No. Qty. E-18BP2 E-18BP3 E-12BP2 E-12BP3 E-12BP4 E-12BP5 E-BPC...
-
Page 65: Burner Lighting Instructions
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Burner Lighting Instructions INSTALLER INSTRUCTIONS It is required that the set of safety instruction labels that have been supplied with the appliance be affixed to the operation and control points of the appliance. It is the installers responsibility to ensure these warnings are properly affixed during installation. -
Page 66: Remote Control System
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Remote Control System The Remote allows you to command the flame height adjustment for your appliance from the comfort of your chair. It is configured to control the ON/OFF burner operation and the flame height through six (6) levels. The remote’s primary purpose is to only control flame height. - Page 67 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Remote Control System TEMPERATURE INDICATOR DISPLAY With the system in the “OFF” position, press the Thermostat Key and the Mode Key at the same time (Figure 65). Look at the LCD screen on the Remote to verify that a C or F is visible to the right of the Room Temperature display (Figure 66).
-
Page 68: Full System Initialization
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Full System Initialization Once the burner system, MFD, Fan, PDS, and ADC100 have been wired correctly, a full system check is required. 1) Place the ADC100 ON/OFF switch in the “ON” position. -
Page 69: Brick Cover Installation
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Brick Cover Installation 1) Orient the brick cover so that the slotted holes are oriented to the exterior edge of the fireplace, with the contours of the Brick Cover matching to the contours of the sidewalls of the firebox (Figure 69). -
Page 70: Troubleshooting
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Troubleshooting Earthcore Industries Technical Support: 1-800-642-2920 Probable Issue Possible Solution Cause - Verify power at the switch Verify wiring connections No power Verify “POWER” LED on ADC100 is illuminated... - Page 71 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Troubleshooting ADC100 Alarm Stages • Flashes 1 - If damper prove does not close 90 seconds after AUX IN, go into alarm for 30 seconds, followed by a full retry Flashes 2 - If initial PDS prove does not close 180 seconds after damper prove, go into alarm for 30 seconds, •...
-
Page 72: Glass Media Options
Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace Glass Media Options Component Part# Description RFG-10-PB 1/2” REFLECTIVE POSEIDON BLUE FIRE GLASS (10 LB JAR) RFG-10-TC 1/2” REFLECTIVE TERRA COPPER FIRE GLASS (10 LB JAR) RFG-10-VB 1/2”... - Page 73 Earthcore Industries 02/12/2021 Isokern Maximus Linear Series See-Thru with Glass Front Gas Fireplace...
- Page 74 Isokern Maximus Linear Series Gas Fireplace ISOKERN offers a Lifetime Warranty for all Isokern components, to be free from defects in materials that negatively affect system performance from the date of purchase, subject to the terms and conditions of this limited warranty.
