ImageCard/UltraGrafix (Express and Select Classes) User's Guide

Parts of the printer

This section describes the basic components of the printer.
Top cover – The top cover protects the internal parts of the printer from dust
and debris.
Printhead – The printhead, contained in the printhead cartridge, uses heat and
pressure to transfer dye and other material from the ribbon to the card.
Swing arm – The swing arm opens to give you access to the printhead
cartridge and ribbon cartridge.
Printhead cartridge – The printhead cartridge holds the printhead.
Ribbon cartridge – The ribbon cartridge holds the ribbon.
Manual card feed knob – The manual card feed knob turns the rollers so you
can move jammed cards along the card transport track manually.
Figure 1:-2 Printer internal part names (Express and S models shown)
Top cover
Printhead
Swing arm
Printhead cartridge
Ribbon cartridge
Manual card feed knob
74030d23
1-5
