Instruction Manual book
SPECIFICATION
Wingspan
Length
Weight
Engine
Servo
Radio
:
1,600 mm
:
1,300 mm
:
3.6 kg
:
.61 cu.in - 2 stroke.
or 91 cu.in - 4 stroke.
:
9 servos.
:
6 channels.
63.in.
52.in.
7.92 lbs.
Made in Vietnam.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P-36A Hawk and is the answer not in the manual?

Questions and answers

Related Manuals for Black Horse Model P-36A Hawk

Summary of Contents for Black Horse Model P-36A Hawk

  • Page 1 Instruction Manual book SPECIFICATION Wingspan 1,600 mm 63.in. Length 1,300 mm 52.in. Weight 3.6 kg 7.92 lbs. Engine .61 cu.in - 2 stroke. or 91 cu.in - 4 stroke. Servo 9 servos. Radio 6 channels. Made in Vietnam.
