Instruction Manual book
SPECIFICATION
Wingspan :
Length
Weight
Radio
Servo
Motor
Battery:
Propeller :
Speed control :
1,090 mm
:
1,070 mm
:
092. kg
:
04 channels.
:
04 servos.
:
AXI 2814/12.
3 CELLS-LI-POLY-11.1V-2000 mA.h.
12 x 3.8
30 A.
43 in.
42 in.
2.02 Lbs.
Made in Vietnam.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAP 232-EP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Black Horse Model CAP 232-EP

Summary of Contents for Black Horse Model CAP 232-EP

  • Page 1 Instruction Manual book SPECIFICATION Wingspan : 1,090 mm 43 in. Length 1,070 mm 42 in. Weight 092. kg 2.02 Lbs. Radio 04 channels. Servo 04 servos. Motor AXI 2814/12. Battery: 3 CELLS-LI-POLY-11.1V-2000 mA.h. Propeller : 12 x 3.8 Speed control : 30 A.
  • Page 2 CAP 232-EP. INSTRUCTION MANUAL. This instruction manual is designed to help you build a great flying aeroplane. Please read this manual thoroughly before starting assembly of your CAP 232 - EP. Use the parts listing below to identify all parts.

  • Page 3: Safety Precaution

    CAP 232 -EP. INSTRUCTION MANUAL. Caution: this model is not a toy! SAFETY PRECAUTION. If you are a beginner to this type of powered model, please ask an experienced model flyer + This is not a toy for help and support. If you attempt to operate + Be sure that no other flyers are using your the model without knowing what you are doing radio frequency.

  • Page 4: Installing The Aileron Servos

    CAP 232-EP. INSTRUCTION MANUAL. INSTALLING THE AILERON SERVOS. 1) Install the rubber grommets and brass eyelets onto the aileron servo. 2) Install the metal connector onto servo C/A glue. arm. C/A glue. Bottom of wing. C/A glue. 3) Using a modeling knife, remove the covering at possition show below.
  • Page 5 CAP 232 -EP. INSTRUCTION MANUAL. 5) Attach the micro control connector to the servo arms. Be sure to use the lock tie but it could free rotation. Servo wire. 4) Install the aileron servo as same as C/A glue. picture. Secure Repeat the procedure for the other wing half.
  • Page 6 CAP 232-EP. INSTRUCTION MANUAL. Secure Remove covering Installing aileron control horn to the aile- ron as picture below. Repeat the procedure for the other wing half. INSTALLING ELECTRIC MOTOR. See pictures below: C/A glue.
  • Page 7 CAP 232 -EP. INSTRUCTION MANUAL. 3x10mm Motor mount wood: Front view. COWLING. 1) Slide the cowl over the motor and line up the back edge of the cowl with the marks you made on the fuselage. 2) While keeping the back edge of the cowl flush with the marks, align the front of the cowl with the crankshaft of the motor.

  • Page 8: Installing The Spinner

    CAP 232-EP. INSTRUCTION MANUAL. Secure Secure the cowling. Secure the cowling. Secure Machine screws ELEVAROR INSTALLATION. SERVO INSTALLATION. 1) Install the rubber grommets and brass INSTALLING THE SPINNER. eyelets onto the servos. 2) Install the metal connector onto servo arm.

  • Page 9: Horizontal Stabilizer Installation

    CAP 232 -EP. INSTRUCTION MANUAL. 4) Using the thread as a guide and using masking tape, tape the servo lead to the end of the thread: carefully pull the thread out. When you have pulled the servo lead out, re- move the masking tape and the servo lead from the thread.
  • Page 10 CAP 232-EP. INSTRUCTION MANUAL.  3. Slide the stabilizer into place in the precut slot in the rear of the fuselage.The stabilizer should be pushed firmly against the front of the slot. Remove covering. Top elevator  4. With the stabilizer held firmly in place, use a pen and draw lines onto the stabilizer where it and the fuselage sides meet.
  • Page 11 CAP 232 -EP. INSTRUCTION MANUAL. C/A glue. C/A glue. 7) When you are sure that everything is aligned correctly, mix up a generous amount of Flash 30 Minute Epoxy. Apply a thin layer to the top and bottom of the stabilizer mounting platform sides in the fuselage.

  • Page 12: Control Horn Installation

    CAP 232-EP. INSTRUCTION MANUAL. Remove covering into place in the pre-cut slot in the bottom of elevator as picture below. C/A glue. Remove covering. CONTROL HORN INSTALLATION. Installing the elevator control horn to elevator as show picture. elevator and rudder control horn.

  • Page 13: Mounting The Tail Wheel Bracket

    CAP 232 -EP. INSTRUCTION MANUAL. MOUNTING THE TAIL WHEEL BRACKET. Secure See pictures below: Nilon clasp. Tail gear. C/A glue. VERTICAL STABILIZER INSTALLATION. C/A glue 1) Using a modeling knife, remove the cov- ering from over the precut hinge slot cut into the lower rear portion of the fuselage.
  • Page 14 CAP 232-EP. INSTRUCTION MANUAL. 4) Now, remove the vertical stabilizer and using a modeling knife, carefully cut just in- side the marked lines and remove the film of the vertical stabilizer. Just as you did with the horizontal stabilizer, make sure you only press hard enough to cut the film, not the balsa ver- tical stabilizer.

  • Page 15: Installing The Rudder Pushrod

    CAP 232 -EP. INSTRUCTION MANUAL. INSTALLING THE RUDDER PUSHROD Rudder pushrod install as same as method of aileron wing. See pictures below: Secure Remove covering. 6) When you are sure that everything is a aligned correctly, mix up a generous amount of 30 minute epoxy.

  • Page 16: Main Gear Installation

    CAP 232-EP. INSTRUCTION MANUAL. Remark Rudder pushrod Remove covering into place in the pre-cut slot in the right side of rudder as picture be- low. Elevator pushrod Rudder pushrod Remove covering MAIN GEAR INSTALLATION. 1) Using a modeling knife, remove the covering from over the two main gear mount- ing slots located in the bottom of the fuselage.
  • Page 17 CAP 232 -EP. INSTRUCTION MANUAL. C/A glue C/A glue Secure Remove covering ATTACHMENT WING-FUSELAGE. See pictures below: Drill 1 hole with 6mm diameter. aluminium wing dihedral brace. Remove covering Left side...
  • Page 18 CAP 232-EP. INSTRUCTION MANUAL. wing bolt wing bolt INSTALLING THE RECEIVER AND BATTERY. 1) Plug the servo leads and the switch lead into the receiver. Plug the battery pack lead into the switch. wing bolt 2) Wrap the receiver and battery pack in the protective foam to protect them from vi- bration.
  • Page 19 CAP 232 -EP. INSTRUCTION MANUAL. Battery wing bolt Receiver...

  • Page 20: Control Throws

    4. Check the control surface. 5. Check the receiver antenna . It should be fully extended and not coiled up inside the 100mm fuselage. 6. Properly balance the propeller. We wish you many safe and enjoy- able flights with your CAP 232-EP.
