OpenVox VS-GW1202-8S Quick Start Manual

Connect with elastix server

VS-GW1202-8S Connect with

Elastix

Server

QuickStart Guide

This document applies to OpenVox VS-GW1202-8S series analog

gateway. This is an example with 8 FXS ports. The Default IP is

172.16.99.1, Username is admin and Password is admin too.

There are two LAN ports, you can connect gateway to Internet

through either of them and you can see the connectivity by LED

status.

Analog Cards

VS-GW120 2 -8S

Analog Phone

Internet

SIP Phone

Elastix Server

172.16.1.194

Soft SIP Phone
