This document applies to OpenVox GSM Gateway WGW1002,VS-GW1202-4/8G and VS-GW1600 series.
There are two RJ45 Network ports, ETH1 and ETH2. If you choose ETH1, you can access Board 1 only, and
access other boards with the same IP address, different port numbers. This will help to avoid IP conflict. If
you choose ETH2, you can access different Boards with different IP addresses. But there is only one RJ45
Network port on WGW1002.
VoxStack provides 2 working modes: Stand-alone and Cluster
Stand-alone: A single IP address manages one GSM modules (4 ports).
Stack Num
Cluster: A single IP address manages up to 5 GSM modules (up to 20 ports).
www.openvox.cn
IP
1
172.16.99.1
2
172.16.99.2
3
172.16.99.3
4
172.16.99.4
5
172.16.99.5
Default IP: 172.16.99.1
User Name: admin
Password: admin
.
Username
Password
admin
admin
admin
admin
admin
admin
admin
admin
admin
admin
1 /5
Advertisement
Table of Contents
Related Manuals for OpenVox WGW1002
Summary of Contents for OpenVox WGW1002
- Page 1 This document applies to OpenVox GSM Gateway WGW1002,VS-GW1202-4/8G and VS-GW1600 series. There are two RJ45 Network ports, ETH1 and ETH2. If you choose ETH1, you can access Board 1 only, and access other boards with the same IP address, different port numbers. This will help to avoid IP conflict. If you choose ETH2, you can access different Boards with different IP addresses.
- Page 2 Please select “SIP—>SIP Endpoints—>Add New SIP Endpoint” to set SIP trunk. The following figure shows detail information about how to set it. About other parameters in SIP, please set by your requirements for there is no need to set them in simple calls. www.openvox.cn 2 /5...
- Page 3 Please save all your changes to make effect. ® Step4. Create a SIP Trunk in FreeSWITCH Enter the directory of FreeSWITCH’s default configuration directory, add the gateway’s configuration in /usr/local/freeswitch/conf/directory/default/ vi /usr/local/freeswitch/conf/directory/default/voxstack.xml www.openvox.cn 3 /5...
- Page 4 <action application="bridge" data="sofia/internal/$1@172.16.99.5"/> </condition> </extension> Inbound rules realize all incoming calls transfer to SIP extension 3001. Edit the outband dialplan in /usr/local/freeswitch/conf/dialplan/public/00_inbound_did.xml. <include> <extension name="public_did"> <condition field="destination_number" expression="^(.+)$"> <action application="set" data="domain_name=$${domain}"/> <action application="transfer" data="3001 XML default"/> </condition> </extension> </include> www.openvox.cn 4 /5...
- Page 5 Green and No-flash Best Signal Quality Flash (0.25s) Communicating ○ Call Status LED Blind Normal Green and Flash(0.5s) Work Normally ○ Running Status LED Always Green Supply Power ○ Power Indicator During reset, all LED indicators flash. www.openvox.cn 5 /5...
