AL-96 S5
Before use, adjustment or maintenance, it is important to read this instruction manual very
GB
carefully. This manual must be stored in a safe place for any future reference that may be necessary.
This ANEST IWATA airless spray guns kit complies to ATEX regulations 94/9/EC.
Protection level: II 2 G X Suitable for using Zones 1 and 2.
X marking: Any static electricity discharge from the spray gun is to be diverted to the ground via the conductive air hose as stipulated.
This airless spray gun should be operated only by an adequately trained operator, for safe use and maintenance of the equip-
ment. Any misuse or handling other than those indicated in this Instruction Manual is not covered by guarantee. ANEST IWATA
disclaims all responsibility for any accident or damage caused by failure to observe the operational and safety procedures in this
manual. In the interest of user friendliness, this manual contains information in a brief and concise form.
For any additional information you may require regarding Airless spray gun operations, or if any missing parts or any damage
during transportation is found, please contact your nearest ANEST IWATA Company (see last cover page).
Be sure to observe warnings and cautions in this instruction manual.
If not, it can cause paint ejection and serious bodily injury by drawing organic solvent.
Be sure to observe following
WARNING Indicates a potentially hazardous situation which, if not avoided, may result in serious injury or loss of life.
CAUTION Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury or pro-
perty damage.
IMPORTANT Indicates notes which we ask you to observe. The safety precautions in this instruction manual are the mini-
mum necessary conditions. Follow national and local regulations regarding fire prevention, electricity and
safety as well as your own company regulations.
IMPORTANT SPECIFICATIONS
Max. Pressure Fluid: 250 bar (3600 PSI)
Max. Pressure Air: 7.0 bar (100 PSI)
Noise Level (LAeqT) 62.9 dB (A)
Spray conditions Used with nozzle tip NT-3005
Fluid pressure 100 bar (1440 PSI)
Tested with water

TECHNICAL SPECIFICATIONS

Max. operating
Model pressure
bar (PSI)
AL-96 S5
250 (3600)
Manufactured by:
ANEST IWATA Corporation 3176,Shinyoshida-cho, Kohoku-ku, Yokohama, 223-8501 Japan
AIRLESS AUTOMATIC

SPRAY GUN

IMPORTANT
marked items which are especially important.
Operating Use
air pressure
bar (PSI)
4.0 ~ 7.0
General
(57~100)
Max. Temperature:
Atmosphere
Air and fluid
Measuring point: 1m backwards from gun, 1.6 m height
Fluid Fluid
output hose connection
ml/min.
Ref. to 4. selection
G 1/4" Air
of nozzle tip accor-
G 1/4" Fluid
ding to kind of paint
Instruction Manual
5 ~ 40 °C
5 ~ 43 °C
Fitting Mass
dimension
g (lbs)
Ø 16 hole
480 (1.06)
or M8 screw
