- Page 1 PureLink’s “SC-HS2” User Manual V1.0 SC-HS2 HDMI to SDI Mini Converter “User Manual” PureLink™ 22-10 State Route 208 Fair Lawn, NJ 07410 Main (201) 488-3232 www.purelinkav.com User Manual V1.0...
-
Page 2: Table Of Contents
PureLink’s “SC-HS2” User Manual V1.0 Introduction Thank you for purchasing the SC-HS2 by PureLink. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Table of Contents 2………………………………………………………………Package Content. -
Page 3: Package Content
PureLink’s “SC-HS2” User Manual V1.0 Package Content: 1. HDMI to SDI Mini Converter 2. 110V-240V 5V 1A DC Power Supply Adaptor 3. User Manual Features: ● Shows HDMI source on SDI display. ● SDI interface operates at bitrates of 2.970 Gbit/s, 2.970/1.001 Gbit/s, 1.485 Gbit/s, 1.485/1.001 Gbit/s and 270 Mb/s. -
Page 4: Specifications
PureLink’s “SC-HS2” User Manual V1.0 Specifications: ● Input Port: 1 x HDMI Female ● Output Port: 1 x BNC (SDI/HD-SDI/3G-SDI) ● SDI Transmission Rates: 2.970 Gbit/s and 2.970/1.001 Gbit/s ● In/Output Resolutions: 480i, 576i, 720p@50/59.94,60, 1080i@50/59.94/60, 1080p@23.97/24/25/29.97/30/50/59.94/60 ● Power Supply: DC 5V -12V ●... -
Page 5: Operations And Functions
PureLink’s “SC-HS2” User Manual V1.0 Operations & Functions: 1. SDI-OUT: This is where you connect the SDI display with coaxial cable. 2. POWER LED: This red LED illuminates when the device is connected with the power supply. 3. DC IN: Plug the 5V-12V DC power supply into the unit. -
Page 6: Application Example
PureLink’s “SC-HS2” User Manual V1.0 Application Example: HDMI and the HDMI Logo are either trademarks or registered trademarks of HDMI Licensing, LLC in the United States and/or other countries. -
Page 7: Warranty
Product or the failure of Product to perform, including incidental or consequential damages. PureLink shall not be liable for any claim made by a third party or made by the purchaser for a third party. Except as expressly set forth in this warranty, PureLink makes no other warranties, expressed or implied, including any implied warranties of merchantability and fitness for a particular purpose. -
Page 8: Customer Service
To better enable PureLink to address a warranty claim, please have the Product’s serial and model numbers. If PureLink, in its sole discretion, determines that an on-site visit or other remedial action is necessary, PureLink may send a representative to Customer’s site.
