SECTION 7 –
PLUMBING
• Remove the bowl and pull the strainer screen
out of the bowl to tap out any particles and
rinse clean.
• Insert the strainer screen back into the bowl,
then screw the bowl back onto the strainer
assembly.
NOTE: You must also empty the strainer when
winterizing your coach to avoid water
freezing and cracking the filter bowl.
Water Pump Switch
The Water Pump switch is located near the
monitor panel (some models may have an
additional switch in the water service center or
within the bathroom area for your convenience).
While the switch is "ON", the pump will
automatically supply water as it is needed.
We recommend that you turn the Water Pump
switch off whenever you will be away from the
vehicle or not using the water system. In time, a
slow leak in a faucet could drain the water tank,
fill the holding tank, and discharge the house
batteries.
Initial Waterline Priming
1. Ensure that all water drain valves are closed,
including water heater valve.
2. Turn Water Pump switch to "OFF" position.
3. Fill water tank.
4. Open all faucets, hot and cold.
5. Turn ON the Water Pump switch.
6. Close each faucet as it begins to deliver a
steady stream of water (close cold water first.)
Leave hot water faucets on until they also
deliver a steady stream of water. This will
ensure that the water heater is filled with
water.
7. Check to ensure the Water Pump stops soon
after all faucets have been closed.
8. The Water Pump is now ready for automatic
operation. The pump will start when a faucet
is opened and stop when the faucet is closed.
7-4
Water Pump
(Model 524G)
• Located beneath step cover on side of bed
(extend backwall slideout to access)
Water Pump
(Model 524V)
• Located in backwall compartment
(remove side panel to access)

COLD WATER FILTER

–If Equipped
To obtain filtered cold water for drinking or
cooking, simply open the galley sink cold water
faucet.
NOTE: Only the cold water faucet is filtered.
The cold waterline flows through an activated
carbon filter that removes chlorine and odors for
taste-free drinking water.
