Driving Safety ................................................................................................................................... 2-1

Fuel and Propane Gas ....................................................................................................................... 2-1

LP Gas Leaks .................................................................................................................................... 2-2

Propane Gas Leak Detector .............................................................................................................. 2-2

Carbon Monoxide Warning .............................................................................................................. 2-3

Carbon Monoxide Alarm .................................................................................................................. 2-3

Smoke Alarm .................................................................................................................................... 2-4

Fire Extinguisher ............................................................................................................................... 2-4

Electrical ........................................................................................................................................... 2-5

Loading ............................................................................................................................................. 2-5

Maintenance ...................................................................................................................................... 2-5

Emergency Exits ............................................................................................................................... 2-5

Power Sofas and Beds ....................................................................................................................... 2-6

Slideout Rooms ................................................................................................................................. 2-6

Formaldehyde Information ............................................................................................................... 2-7

Mold, Moisture, and Your Motor Home ........................................................................................... 2-7

Roof and Ladders .............................................................................................................................. 2-8

Roadside Emergency ........................................................................................................................ 2-8

Jump Starting .................................................................................................................................... 2-9

Engine Overheat ............................................................................................................................. 2-10

3 - DRIVING YOUR MOTOR HOME

Seats - Driver/Co-Pilot ..................................................................................................................... 3-1

Heated Seats ...................................................................................................................................... 3-2

Passenger Footrest ............................................................................................................................ 3-2

Seat Belts .......................................................................................................................................... 3-3

Rev. 1023110418

Part No. 161500-10-023

Table of Contents

Need help?

Do you have a question about the Itasca Ellipse and is the answer not in the manual?

Questions and answers

Gary Hatch

February 13, 2025

Sorry?? 2011 42ft 8.9 Cummins (no ****) and no heat from engine??

1 comments:

Mr. Anderson

February 13, 2025

A 2011 Winnebago Itasca Ellipse 42ft with an 8.9 Cummins engine could have no heat from the engine due to issues with the hydronic heating system. Possible causes include:

1. Low Antifreeze/Water Heating Solution – Check the expansion fill tank and ensure the fluid level is at the "HOT" mark when the system is at maximum operating temperature. If low, replenish with Aqua-Hot® approved propylene glycol-based antifreeze.

2. Thermostat Setting – Ensure the basement temperature control thermostat is not set below 40°F, as this could prevent proper heating.

3. Blocked Drain Lines – If water is flowing from the air conditioner overflow, it may indicate clogged drain lines that need cleaning.

4. Hydronic Heating System Malfunction – If the heating system is not operating correctly, it may require service from a Winnebago Industries® dealer.

Checking these components and ensuring proper maintenance should help restore heat from the engine.

This answer is automatically generated

Gary Hatch

February 13, 2025

Engine Cab heater will not work ?? No **** or heat?? Is there a relay that opens the heat from engine also a fuse for ****??

1 comments:

Mr. Anderson

May 14, 2025

In a Winnebago Ellipse, if the engine cab heater is not working, possible causes include:

- Issues with the controls located on the dash (blower, temperature, or mode selectors).
- Problems with the chassis engine cooling system, as it provides heat to the Motoraid water heater and affects heating functions.
- Low or incorrect coolant levels, which can impact heating performance.
- Electrical issues involving relays, circuit breakers, or fuses related to the dash and chassis features.

The fuses, breakers, and relays for automotive chassis and dash features are located in the main 12-volt electrical panel in the front left exterior compartment. Therefore, faulty relays or blown fuses could be involved.

This answer is automatically generated

Dwight cyril vogel

May 19, 2025

how do i get the rear engine cover off in the rear bathroom

Jeff

February 2, 2025

Where is the power cut off on itasca 2013 ellipse

Summary of Contents for Winnebago Itasca Ellipse

Page 1: Table Of Contents
Engine Overheat ..........................2-10 3 – DRIVING YOUR MOTOR HOME Seats – Driver/Co-Pilot ........................3-1 Heated Seats ............................3-2 Passenger Footrest ..........................3-2 Seat Belts ............................3-3 Rev. 1023110418 Part No. 161500-10-023 Copyright 2009 Winnebago Industries, Inc. All rights reserved.
Page 2 Table Of Contents Child Restraints ..........................3-4 KeyOne™ Lock System ........................3-5 Power Door Locks ..........................3-5 Mirrors – Power Electric ........................3-6 Rearview Monitor System ........................ 3-8 Rearview Monitor System ........................ 3-9 12-Volt Front Drop-Down Solar/Night Shade .................. 3-9 Electronic Compass and Outside Thermometer ................
Page 3 Table Of Contents Refrigerator Service Access Compartment ..................4-3 Refrigerator/Freezer - Portable ......................4-3 Range Top ............................4-4 Microwave Oven/Range Hood ......................4-6 OnePlace® Systems Monitor Panel ....................4-6 Solar Charger Panel .......................... 4-8 Energy Management System (EMS) ....................4-9 Energy Management System (EMS) ....................
Page 4 Table Of Contents Battery Access ..........................6-11 Battery Care ............................ 6-12 Circuit Breakers – House 12-Volt ....................6-13 7 – PLUMBING Fresh Water System .......................... 7-1 Water Pump ............................7-2 Filtered Water Faucet ........................7-4 Full-Coach Water Filtration System ....................7-5 Disinfecting Your Fresh Water System ....................
Page 5 Table Of Contents Rest Easy® Multi-Position Lounge ....................9-5 Extendable Sectional Sofa ........................ 9-7 Theater Seating/Bed Conversion ...................... 9-8 Sleep Number® Bed ........................9-10 Bed - Power Lift ..........................9-10 Day/Night Pleated Blinds ....................... 9-10 Roller Shades (Manual) - Solar Day/Night ..................9-11 Wood Furniture and Cabinetry .......................
Page 6 Weighing Your Loaded Vehicle ..................... 12-1 Car or Trailer Towing ........................12-3 Trailer Wiring Connector ........................ 12-4 Towing Guidelines .......................... 12-4 Fireplace ............................12-5 Entry Step – Electric ........................12-6 Stepwell Cover ..........................12-7 Windows ............................12-8 Power Roof Ventilator – Galley ..................... 12-9 Power Roof Ventilator –...
Page 7: Introduction
DANGER indicates a hazardous situation are intended as a guide, and in no way which, if not avoided, will result in death or extend the responsibilities of Winnebago serious personal injury. Industries beyond the standard written warranty as presented in this manual.
Page 8: Pre-Delivery Inspection
National Highway Traffic Safety Administration (NHTSA) in addition to notifying Winnebago PRE-DELIVERY INSPECTION Industries, Inc. If NHTSA receives similar complaints, it may...
Page 9: Occupant And Cargo Carrying Capacity Label
SECTION 1 – INTRODUCTION You can also obtain other information about motor vehicle safety from the NHTSA website at http://www.safercar.gov OCCUPANT AND CARGO CARRYING CAPACITY LABEL This label is affixed in the driver’s area next to or near the Vehicle Certification Label. It contains vehicle occupant and cargo carrying capacity along with the number of seat belt positions in the vehicle.
Page 10: Vehicle Certification Label
These pressure levels must be maintained to assure proper handling, safety, 2. Chassis manufacture date. and fuel economy. 3. Month and year of manufacture at Winnebago ® 9. Rear Axle Wheel Configuration: Single or Industries Dual as it relates to the inflation.
Page 11: Specifications And Capacities
SECTION 1 – INTRODUCTION SPECIFICATIONS AND CAPACITIES 40BD 40CD 40WD 42AD ® ® ® ® Freightliner Freightliner Freightliner Freightliner Itasca Ellipse MAXUM MAXUM MAXUM MAXUM Tag 34,320 lb. 34,320 lb. 34,320 lb. 44,320 lb. Chassis Chassis Chassis Chassis Feature Number Length 40' 8"...
Page 12: Owner And Vehicle Information
Motor Home Serial Number __________________________________________________________ Chassis Vehicle Identification No. (VIN) ________________________________________________ Vehicle Mileage at Delivery __________________________________________________________ Selling Dealer Name ________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ ® YOUR WINNEBAGO INDUSTRIES DEALER /SERVICE CENTER Name ____________________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ Contact ____________________________________________Phone ________________________ CHASSIS SERVICE CENTER...
Page 13: 2010 New Vehicle Limited Warranty
ITEMS NOT SUBJECT TO WARRANTY COVERAGE Winnebago Industries, Inc. of Forest City, Iowa, warrants each new Chassis, drivetrain and related components* Winnebago and Itasca motor home to the owner for recreational use Wheels* in the U.S.A. and Canada as follows:...
Page 14 If you are touring or have moved, contact any unresolved warranty disputes for recreational vehicles. This dispute Winnebago Industries motor home dealer in the United States or resolution program reviews eligible product and service related Canada for warranty service.
Page 15: Safety And Precautions
SECTION 2 – SAFETY AND PRECAUTIONS • Use care when accelerating or decelerating on GENERAL WARNINGS a slippery surface. Abrupt speed changes can cause skidding and loss of control. • Only seats equipped with seat belts are to be occupied while the vehicle is moving. •...
Page 16: Lp Gas Leaks
SECTION 2 – SAFETY AND PRECAUTIONS • All pilot lights must be extinguished and asphyxiation is greater when the appliance is appliances turned off while refilling the fuel used for long periods of time. Failure to comply tank or LP gas tank. could result in death or serious injury.
Page 17: Carbon Monoxide Warning
SECTION 2 – SAFETY AND PRECAUTIONS The best protection against carbon monoxide entry into the vehicle body is a properly WARNING maintained engine exhaust and ventilation system. It is recommended that the exhaust system and body be inspected by a qualified EXPLOSION HAZARD: DO NOT use an motor home service center: open flame to test for gas leaks.
Page 18: Smoke Alarm
InfoCase for further instructions. that is also listed for RV application. We Replacement recommend obtaining a replacement from your ® Winnebago Industries dealer. When replacing this alarm, we recommend replacing only with the same model, or with one Further Information that is also listed for RV application.
Page 19: Electrical
MAINTENANCE your coach. We recommend obtaining a replacement only from your Winnebago • Do not remove the radiator cap while engine ® Industries dealer or a reliable RV parts supplier.
Page 20: Power Sofas And Beds
SECTION 2 – SAFETY AND PRECAUTIONS POWER SOFAS AND BEDS WARNING Keep people away from operating mechanism and pinch hazard areas during use. Failure to do so could cause injury. SLIDEOUT ROOMS Escape Window - Lift latch handles upward to open WARNING Using Slider Windows As Emergency Exits...
Page 21: Formaldehyde Information
SECTION 2 – SAFETY AND PRECAUTIONS Mold is a plant and requires its own special FORMALDEHYDE environment to grow. That environment includes INFORMATION organic materials, nutrients, moisture, and proper temperature. Some of the materials used in this recreational vehicle emit formaldehyde. Eye, nose, and throat How Can I Avoid Mold? irritation, headache, nausea, and a variety of To reduce the ability for mold to grow, you...
Page 22: Roof And Ladders
® while in use. Never use the ladder when it is Winnebago Industries raining, snowing, or icy. The rungs can If Winnebago Industries determines that mold become slippery. Do not step onto the rungs if ® ® is present in the Winnebago...
Page 23: Jump Starting
We recommend that you ask for an underlift (wheel lift or frame lift) type towing assembly for safe towing. ® Winnebago Industries does not assume responsibility for damage incurred while towing this vehicle.
Page 24: Engine Overheat
SECTION 2 – SAFETY AND PRECAUTIONS ENGINE OVERHEAT If you see or hear steam escaping from the engine compartment or have any other reason to suspect an extreme engine overheating condition, pull the vehicle over to the roadside as soon as it is safe to do so, stop the engine, and get all passengers out of the vehicle.
Page 25: Driving Your Motor Home
SECTION 3 – DRIVING YOUR MOTOR HOME The information in this section refers only to features installed or adapted to the dash and driver compartment area by Winnebago ® Industries . It also includes passenger seating in the living area of the coach.
Page 26: Heated Seats
SECTION 3 – DRIVING YOUR MOTOR HOME HEATED SEATS Seat Heater Control Switch (Driver and Passenger Seats) (Located on the side of the driver and passenger seats) - If Equipped -Typical View Your coach may be equipped with heated driver and passenger seats. When the heated seat switch is in the middle position, the heater is OFF.
Page 27: Seat Belts
SECTION 3 – DRIVING YOUR MOTOR HOME To Fasten Be sure belt is not twisted. Grasp each part of the belt assembly and push tongue into buckle. Adjust to a snug fit by pulling the loose end away from the tongue. To Release Press button in center of buckle and slide tongue out of buckle.
Page 28: Child Restraints
SECTION 3 – DRIVING YOUR MOTOR HOME 2. Make sure that it will attach to your vehicle and restrain your child securely and WARNING conveniently so that you are able to install it correctly each time it is used. 3. Be certain that it is appropriate for the child's Never wear the shoulder belt in any height, weight, and development.
Page 29: Keyone Lock System
The key number for your coach is registered in Power Door Locks our factory database, so if you ever lose your (Located on dash) ® keys, any Winnebago Industries dealership can -Typical View order a new key for you. Keyless Remote Entry System with...
Page 30: Mirrors - Power Electric
SECTION 3 – DRIVING YOUR MOTOR HOME Further Information Please read the Keyless Entry System information in your InfoCase for a full description of all system features. MIRRORS – POWER ELECTRIC Always adjust mirrors for maximum rear visibility before driving. Make sure the seat is adjusted for proper vehicle control and that you are sitting back squarely into the seat.
Page 31 SECTION 3 – DRIVING YOUR MOTOR HOME Mirror Heaters Mirror Arm Mounting Base The mirrors may also contain heating elements to defog or de-ice the mirror glass during cold weather operation. An ON-OFF switch for the mirror heaters is located near the remote mirror controls.
Page 32: Rearview Monitor System
SECTION 3 – DRIVING YOUR MOTOR HOME Basic Operating Instructions Power • Turn ON to activate monitor for rear viewing while driving or parked. Key must be on. • In OFF (Standby) position the monitor is “asleep” and will “wake up” when the transmission is shifted into reverse.
Page 33: 12-Volt Front Drop-Down Solar/Night Shade
SECTION 3 – DRIVING YOUR MOTOR HOME Sideview Cameras* (if equipped) REARVIEW MONITOR SYSTEM The optional sideview cameras activate with the –If Equipped corresponding turn signals and replace the rear camera view on the monitor until the turn is completed or the signal lever is canceled manually.
Page 34: Electronic Compass And Outside Thermometer
SECTION 3 – DRIVING YOUR MOTOR HOME NOTE: If power is gradually drained and falls below the lower limit of 11-volts, the motors could lose their electronic Set Limits and will require reprogramming once normal power has been restored. Refer to the Solar/Night Shade manufacturer’s information provided in your InfoCase.
Page 35: Parking Brake
SECTION 3 – DRIVING YOUR MOTOR HOME Further Information shutting down either three cylinders or all six cylinders, depending on Low or High setting. See the GPS system manufacturer’s This turns the power-producing diesel engine information in your InfoCase for complete setup into a power-absorbing compressor, which and operating instructions.
Page 36: Tag Axle Suspension System
SECTION 3 – DRIVING YOUR MOTOR HOME WARNING Do not use the exhaust brake if road surfaces are slippery. Using the exhaust brake on wet, icy, or snow-covered roads could result in loss of vehicle control, possibly causing personal unjury or death, or property damage.
Page 37: Hazard Warning Flashers
SECTION 3 – DRIVING YOUR MOTOR HOME HAZARD WARNING FLASHERS SIGNAL LEVER/HEADLIGHT HI/LO BEAM The hazard warning flashers provide additional safety when the vehicle must be The signal lever controls the turn signals and stopped on the side of the roadway and presents a high/low beam changing.
Page 38: Steering Column Adjustment
SECTION 3 – DRIVING YOUR MOTOR HOME WARNING Do not adjust the steering column or tilt wheel while the vehicle is in motion. Doing so may cause loss of vehicle control resulting in death or personal injury. Further Information SMARTWHEEL STEERING See your chassis manual in your InfoCase for ™...
Page 39: Marker Light Courtesy Flash
SECTION 3 – DRIVING YOUR MOTOR HOME Set (Set Speed/Coast) • Press and release to blink or flash the headlights. • Press to maintain current desired driving • Night: If the headlights are already turned on, speed. Will not work below 40 mph. pressing the switch will blink them off briefly.
Page 40: Battery Boost Switch
SECTION 3 – DRIVING YOUR MOTOR HOME NOTE: Many states now have laws that require • If wipers are already active, pressing the headlights to be on during precipitation switch will simply spray fluid onto the conditions. To assure compliance with windshield without affecting wiper setting.
Page 41: Air Conditioner/Heater - Automotive (Dash)
SECTION 3 – DRIVING YOUR MOTOR HOME Press and hold in the ON position while NOTE: The dash air conditioner/heater is not turning ignition key for emergency starting designed to heat and cool the entire power. interior of the coach, but is intended only to provide heating and cooling for the NOTE: The House/Coach Battery Disconnect cab area.
Page 42: Radio Remote Controls
SECTION 3 – DRIVING YOUR MOTOR HOME See the manufacturer’s information in your InfoCase for operating instructions. Radio Remote Controls A steering wheel mounted remote control for the radio lets you change radio stations or CD selections without taking your eyes off the road or hands off the wheel.
Page 43: Sirius Plug And Play Satellite Radio
SECTION 3 – DRIVING YOUR MOTOR HOME Radio Power Switch To install the satellite unit, place your Sirius radio into the docking station, aligning the tabs at The radio power switch lets you connect the the edges of the the radio adapter with the dash radio to the coach batteries with the ignition grooves in your radio.
Page 44: Air Horns
SECTION 3 – DRIVING YOUR MOTOR HOME Look for a pair of wires - yellow (+) and white FUEL SELECTION – DIESEL (-) with connectors and flag labels suspended ENGINE from the wiring harness. –If Equipped Refer to your chassis manual for the manufacturer's recommendations on proper fuel selection (ULSD fuel only).
Page 45: Starting And Stopping Diesel Engine
SECTION 3 – DRIVING YOUR MOTOR HOME coach. When plugged into the receptacle, the STARTING AND STOPPING heater is connected to both the shoreline and the DIESEL ENGINE auxiliary generator, so a separate extension cord is not needed. The power switch is a standard –If Equipped household light switch located near the Refer to the chassis manual in your InfoCase...
Page 46: Engine Top Access Covers - Rear
SECTION 3 – DRIVING YOUR MOTOR HOME Engine Coolant Air Filter Reservoir Restriction Engine Indicator Engine Oil and Diagnostic Transmission Connector Fluid With the grille panel open, you can access the Engine Oil Transmission Fluid Engine Oil following service points: Dipstick Fill/Dipstick Fill...
Page 47 SECTION 3 – DRIVING YOUR MOTOR HOME A falling bed board can injure. Assure the bed is properly supported. Refer to instructions for propping the bed board. • Remove fasteners from metal engine covers and set covers aside. Models with “East-West” Beds (Crosswise to Coach) •...
Page 48: Engine Top Access Covers - Rear Bath Models
SECTION 3 – DRIVING YOUR MOTOR HOME Propping the Bed Board Sliding Step Cover Step Cover Aluminum Tube Steel Frame -Typical View Steel Frame NOTE: When supporting the bed with a suitable prop item (e.g. 6-ft. long 2x4 board), Steel Frame Screw Locations make sure that the top of the board is -Typical View seated firmly against the aluminum tube...
Page 49 SECTION 3 – DRIVING YOUR MOTOR HOME deposits of oil and fuel or other engine fluids and substances that could damage fabrics and interior furnishings. 1. Remove bathroom rug to access rear engine covers. 4. Remove fasteners from the secondary black metal engine cover and set cover aside.
Page 50: Fuel/Water Separator - Diesel
SECTION 3 – DRIVING YOUR MOTOR HOME 2. Remove fasteners from the black metal engine cover (one located on each corner of the cover) and set cover aside. You have now accessed the engine. NOTE: Removal of the cabinet face is required to take the engine cover out and set aside.
Page 51: Chassis Battery Disconnect Switch
SECTION 3 – DRIVING YOUR MOTOR HOME NOTE: Your chassis engine cooling system is Turn the switch to the OFF or ON positions to filled with special extended-life coolant disconnect or reconnect the chassis batteries. that is not the same as common anti- NOTE: The chassis battery disconnect switch freeze available at retail outlets.
Page 52: Front Service Access
SECTION 3 – DRIVING YOUR MOTOR HOME Automotive Fuses (cover removed) Always replace plug-in type fuses with those Hood Latch (Located in 12-volt electrical compartment) of the same amperage size. -Typical View See the chassis manufacturer’s fuse allocation chart on the inside of the fuse block cover. Fuse Diagram (inside of cover) Further Information Pull top of latch outward to release hood panel.
Page 53: Tires
SECTION 3 – DRIVING YOUR MOTOR HOME Alignment can be affected by worn steering/ suspension parts or by incidents which happen during driving, such as hitting a curb, pothole, or railroad track, etc. Improper alignment can cause tires to roll at an angle and wear unevenly. It may also cause the vehicle to “pull”...
Page 54 SECTION 3 – DRIVING YOUR MOTOR HOME downshifting. Select the lowest adequate gear range for the duration of the incline. See your chassis manual for specific information. Descending A Hill When going down a long grade, you may need to manually shift to a lower gear rather than keeping your foot on the brake pedal.
Page 55: Appliances And Systems
SECTION 4 – APPLIANCES AND SYSTEMS The appliances installed in your motor home are manufactured by reputable RV appliance makers and have been tested by independent laboratories to meet all applicable standards and codes set for RV appliances. See Section 2 of this manual for any safety and precautions you need to take regarding the operation of your appliances.
Page 56: Ice Maker
SECTION 4 – APPLIANCES AND SYSTEMS Basic Operation (Dometic ® “Sidewise”) -If Equipped • Press the MODE button to select energy source. There are three settings: • To start up the refrigerator, press the main LP (Gas Mode) - Refrigerator will operate on power ON/OFF button.
Page 57: Refrigerator Service Access Compartment
SECTION 4 – APPLIANCES AND SYSTEMS NOTE: A water shut-off valve for the ice maker is located near the water faucet filter inside the galley cabinet beneath the sink. Further Information See the refrigerator manufacturer’s operation, care and maintenance information in your InfoCase.
Page 58: Range Top
SECTION 4 – APPLIANCES AND SYSTEMS Further Information See the manufacturer’s user guide provided in your InfoCase for complete operating instructions and cautions. Removing Refrigerator/Freezer Unit from Slide Tray RANGE TOP 1. To remove refrigerator/freezer unit from slide The range in your motor home operates on tray, disconnect the 12-volt power cable and propane gas and will provide most of the the electrical plug from the energy source...
Page 59 SECTION 4 – APPLIANCES AND SYSTEMS Unlike homes, the amount of oxygen supply is limited due to the size of the recreational vehicle, • Fold the top half of the range cover down. and proper ventilation when using the cooking appliances avoids dangers of asphyxiation.
Page 60: Microwave Oven/Range Hood
SECTION 4 – APPLIANCES AND SYSTEMS ONEPLACE SYSTEMS ® MONITOR PANEL NOTICE The OnePlace Systems Monitor Panel Turn off the range and allow it to cool provides a convenient, central location for before closing the range cover. The range checking the condition of all utility systems in cover is made of glass and may shatter ®...
Page 61: Tank Capacities
SECTION 4 – APPLIANCES AND SYSTEMS Water Level Sensors Generator Switch and Hourmeter Water Tank -Typical View Generator Hourmeter For example, if the fluid level is 1-2” below See Electrical Systems section for generator the FULL sensor, the monitor will show the level hourmeter information.
Page 62: Solar Charger Panel
SECTION 4 – APPLIANCES AND SYSTEMS The propane level is registered by a sending unit on the tank. The gauge mounted on the side of the tank will give a more accurate indication of actual tank level if needed. Water Pump Switch When you want to use the self-contained water system, turn on the “Water Pump”...
Page 63: Energy Management System (Ems)
SECTION 4 – APPLIANCES AND SYSTEMS NOTE: The solar battery charger is not intended to make the coach battery system “maintenance free.” The solar panel will not completely compensate for continuous low amperage draw from components such as the propane gas leak detector, the clock in the dash radio and the radio station memory circuitry, for example.
Page 64: Water Heater - Gas/ Electric
SECTION 4 – APPLIANCES AND SYSTEMS For Propane Gas Operation Press the Water Heater switch on the Monitor Panel. The “Pilot Out” light will glow for about 10-15 seconds, then it will go out. The “Heater On” indicator will remain lit. If the “Pilot Out” light comes on during gas operation, it means that the burner has gone into “lockout”...
Page 65: Pressure-Temperature Relief Valve
SECTION 4 – APPLIANCES AND SYSTEMS For Quick Recovery Operation (Dual Heating) CAUTION Turn On both Water Heater switches; the gas one on the monitor panel and the electric one. This will help reheat the water heater tank more Hot water can escape from tank causing quickly than a single source would alone.
Page 66: Motoraid Water Heater
SECTION 4 – APPLIANCES AND SYSTEMS MOTORAID WATER HEATER –If Equipped * NOT AVAILABLE ON COACHES EQUIPPED WITH HYDRONIC HEATING SYSTEM The motoraid uses heat from the chassis engine cooling system to heat water in the water heater while driving. Hoses are routed from the engine to a heat exchanger surrounding the water heater tank.
Page 67: Rear Furnace
SECTION 4 – APPLIANCES AND SYSTEMS and periodic maintenance. See the Coach 3. Furnace fan should start to blow immediately Maintenance Schedule for recommended after setting the thermostat. intervals. 4. After about 30 seconds, the furnace burner should light. NOTE: If the furnace burner has any residuals 5.
Page 68: Electronic Thermostat
SECTION 4 – APPLIANCES AND SYSTEMS Changing Temperature Setpoints ELECTRONIC THERMOSTAT To set the temperature to a new temperature, (Central Heat/Air Conditioning System) simply press the Temperature Selector button up or down until the temperature you want appears ® The thermostat, located on the OnePlace in the display.
Page 69: Electronic Thermostat - Model 42Ad
SECTION 4 – APPLIANCES AND SYSTEMS ELECTRONIC THERMOSTAT - MODEL 42AD (Heating and Cooling) The thermostat (located near the monitor panel) controls the Hydronic Heating System, as well as the three separate roof air conditioners in your coach. The living area and galley are equipped with two air conditioners, and the bedroom and bath area is equipped with one.
Page 70: Heat Pump
SECTION 4 – APPLIANCES AND SYSTEMS 5. Adjust the temperature setpoint to personal extract heat from the outside air on a cold day and preference if needed. See “Changing carry it to the inside of the coach to maintain a Temperature Setpoints.”...
Page 71: Hydronic Heating System
(Located in driver side compartment plugged and water is now flowing out of the behind front wheel well) safety overflow of the air conditioner(s). See ® your Winnebago Industries dealer for service and proper cleaning of the drain lines. 4-17...
Page 72 SECTION 4 – APPLIANCES AND SYSTEMS switch panel for approximately 30 seconds, then turning the switch back Basement Temperature Control NOTICE When the water system is in use, the Expansion Fill Tank thermostat should never be set below 40- • Check antifreeze/water heating solution degrees F.
Page 73 SECTION 4 – APPLIANCES AND SYSTEMS • Zone 3 - Basement The hydronic heating system can be operated off of the 120-volt AC electric heating element or Engine Preheating/Motoraid the 12-volt DC diesel burner. Also included in this system is a motoraid NOTE: Please note that the diesel burner is the feature, which uses heat generated by the RV primary heat source for heating both the...
Page 74 SECTION 4 – APPLIANCES AND SYSTEMS Fuel Nozzle -Typical View See “Winterizing Procedures” in Section 7 - Plumbing (METHOD 2 - ANTIFREEZE FILL PROCEDURE) for complete instructions in winterizing your hydronic heating system. The Aqua-Hot will be winterized along with the rest Hydronic Heating System of the RV water systems.
Page 75: Furnace-A/C Thermostat Operation Chart
SECTION 4 – APPLIANCES AND SYSTEMS FURNACE-A/C THERMOSTAT OPERATION CHART The following chart shows the system functions with the “Heat/Cool” thermostat. Disregard references to heat functions when using the “Cool Only” thermostat in the rear bedroom. X = Switch Position O = Switch position does not matter or is inactive for this feature FAN MODE FAN SPEED...
Page 76: Central Air Conditioner
SECTION 4 – APPLIANCES AND SYSTEMS temperatures begin to reduce the efficiency of the The cooled air is forced through ducts in the heat pump. The heat pump will not operate when ceiling of the coach. Inside air returns to the air the outside temperature falls below 36 degrees F.
Page 77 SECTION 4 – APPLIANCES AND SYSTEMS NOTE: Do not block the filter in any way, such as by setting packages or newspapers, etc. in front of the return air grate. There must be free airflow for the air Access Panel conditioner to operate efficiently.
Page 78: Washer/Dryer
SECTION 4 – APPLIANCES AND SYSTEMS for up to 2 minutes after the cycle ends. DO NOT WASHER/DRYER attempt to open the door unless the “STATUS/ –If Equipped DOOR LOCK” LED is BLINKING SLOWLY! Water Supply Faucets The washing machine water supply faucets are located inside the cabinet door above the machine.
Page 79: Washer/Dryer - Stackable
SECTION 4 – APPLIANCES AND SYSTEMS Model 40CD WASHER/DRYER - STACKABLE –If Equipped Water Supply Faucets (Located below bathroom sink) Model 42AD NOTE: Bedroom slideout must be extended to get to the access panel. To Reset or Cancel a Wash Cycle If resetting or canceling a program is necessary: 1.
Page 80: Washer/Dryer - Prep Package
We recommend obtaining parts and service drawer will light up. for the washer/dryer installation from your ® ® 5. Press the Power button (left on touch panel) Winnebago or Itasca dealer. the unit is set. DISHWASHER NOTE: If the power is disconnected and...
Page 81 SECTION 4 – APPLIANCES AND SYSTEMS To Change Filter Bags Pull the cover from the square metal canister. Central Vacuum Cleaner System The canister is located in an exterior storage compartment on the passenger side of the coach. To Use Vac Pan Press the vac pan lever to the right using your foot as shown to open the door and turn on the vacuum unit.
Page 83: Propane Gas
SECTION 5 – PROPANE GAS PROPANE GAS SUPPLY The propane gas system supplies fuel for the gas range/oven, water heater, furnace, and refrigerator (while in gas mode). When used and handled properly, this system is safe and economical and provides modern living conveniences wherever you travel.
Page 84: Safe Use Of The Propane Gas System
SECTION 5 – PROPANE GAS phone directory yellow pages for locations of local propane gas refilling stations or bulk DAN GE R dealerships. NOTE: If you travel outside the U.S. with your DO NOT FILL CONTAINER TO MORE motor home, you may find butane or THAN 80 PERCENT OF CAPACITY.
Page 85: Propane Gas Warnings And Precautions
SECTION 5 – PROPANE GAS • Exercise caution at all times. Be familiar with PROPANE GAS WARNINGS the distinctive odor of propane gas. If a leak is AND PRECAUTIONS suspected, turn off the supply valve immediately. Have the propane gas system It is illegal for vehicles equipped with propane checked by your dealer or other qualified tanks to travel on certain roadways or through...
Page 86: Propane Gas Pressure Regulator
SECTION 5 – PROPANE GAS WARNING WARNING Propane cylinders shall not be placed or Visually inspect the pressure regulator stored inside the vehicle. Propane vent periodically for blockage by cylinders are equipped with safety accumulated debris or insect nests, etc. devices that relieve pressure by Vent obstruction could result in excessive discharging propane to the atmosphere.
Page 87: Propane Vaporization In Cold Weather
SECTION 5 – PROPANE GAS This means that in extremely cold weather when a large volume of gas is being used by the furnace for heating, it is possible to experience a loss of gas pressure. At first, this problem may appear to be caused by an empty tank or a regulator freeze-up, but is actually caused by failure of the liquid gas to vaporize as fast as it is needed by the furnace.
Page 89: Electrical
SECTION 6 – ELECTRICAL Your coach is equipped with an electrical the power converter automatically changes a system consisting of two separate voltages: portion of the 120-volt current to 12-volt DC current. All equipment in the motor home that is •...
Page 90: Connecting The Power Cord
SECTION 6 – ELECTRICAL be used is designed to mate with the prongs of the power cord plug, the electrical connection can be expected to carry rated load. Connecting The Power Cord To connect to an external source, remove the cord from the utility compartment and plug it into a suitable 50-amp power receptacle to provide external power to the coach and converter/...
Page 91: Power Cord Reel
SECTION 6 – ELECTRICAL POWER CORD REEL –If Equipped Your coach may be equipped with a 12-volt power cord reel to assist in the retraction of the external power cord (shoreline). Power Cord Reel Switch (Located near the power cord reel) -Typical View Further Information See the manufacturer’s user guide provided in...
Page 92: Charging Section
SECTION 6 – ELECTRICAL If your battery does not charge as described above, it is possible the battery is defective. If the batteries are extremely discharged, the charger unit will not activate to charge batteries. NOTE: We do not recommend leaving the shoreline plugged in continuously during storage periods because the batteries can lose electrolytic fluids and become...
Page 93: Circuit Breakers - House 120-Volt Ac
SECTION 6 – ELECTRICAL refrigerator is in ELECTRIC or AUTO *Breakers are labeled on panel. Arrangement mode, it will continue to draw from may vary according to appliance and equipment house batteries through the inverter options. when the shoreline is unplugged unless ELECTRICAL OUTLETS –...
Page 94: Electrical Generator
SECTION 6 – ELECTRICAL Push to Reset WARNING circuit after monthly testing or Do not plug the power cord into the ground fault generator receptacle while the generator tripping. is running. Electrical shock can cause personal injury. Push to Test Automatic Power Transfer Switch at least monthly.
Page 95: Operation Warnings And Cautions
SECTION 6 – ELECTRICAL The following label is located near the 120- volt house circuit breaker panel and at the generator to warn you to disconnect specific electrical connections before servicing the Generator Switch and Hourmeter generator and storing the coach. (Located on monitor panel) -Typical View Generator Hourmeter...
Page 96 SECTION 6 – ELECTRICAL • Do not open windows or vents on the end or side of the vehicle where exhaust pipe of the generator is located. • Park the vehicle so that the wind will carry the exhaust away from the vehicle. Also, note the position of other vehicles to be sure their exhaust will not enter your vehicle.
Page 97 SECTION 6 – ELECTRICAL • Lift rear access panel up to allow clearance 7. Replace the air filter. for the removal of the front panel. 8. Secure the air filter housing end cap. • Lift front access panel, while pushing back 9.
Page 98: Electrical System - House 12-Volt Dc
SECTION 6 – ELECTRICAL ELECTRICAL SYSTEM – HOUSE 12-VOLT DC The DC voltage system consists of the chassis battery, the 12-volt house batteries, and the 12- volt power converter. Converter See “Power Center.” Chassis Battery The chassis battery is used to operate the engine starter and automotive accessories and controls found on the instrument panel.
Page 99: Battery Information
SECTION 6 – ELECTRICAL avoid battery drain by electrical items that are BATTERY INFORMATION hooked directly to the house batteries, such as clock displays and radio memories, etc. Chassis Batteries Always leave this switch ON while using the The chassis batteries operate the engine starter coach.
Page 100: Battery Care
SECTION 6 – ELECTRICAL 2. Check the battery and recharge as necessary at least once a month during long storage periods. Turn the House/Coach Batt Switch off to avoid electrical arcing when attaching or detaching charger clamps. WARNING California Proposition 65 Warning: Lift Battery Tray Retainer Latches Battery posts, terminals, and related accessories contain lead and lead...
Page 101: Circuit Breakers - House 12-Volt
SECTION 6 – ELECTRICAL WARNING WARNING Before removing any battery cables or To prevent wiring damage, it is essential battery, make sure all 12-volt equipment when replacing the cables on the battery, in the motor home is off and the power or when using a “booster”...
Page 102 SECTION 6 – ELECTRICAL *Typical view of breaker panel. Actual breaker panel location may vary according to model floorplan. Breakers are labeled on panel according to appliance and equipment options. 6-14...
Page 103: Plumbing
SECTION 7 – PLUMBING FRESH WATER SYSTEM The fresh water system provides water to the galley sink, shower, bathroom lavatory, toilet and water heater. Water may be supplied by either of two sources: • a fresh water tank located within the motor home •...
Page 104: Water Pump
SECTION 7 – PLUMBING 2. Open a faucet on the coach (such as exterior wash station) to relieve water line pressure. 3. Disconnect the hose from the city water faucet and store hose (retract the hose into the hose reel- if equipped). Be sure to replace the protective cap on the hose end to avoid entrance by debris or insects.
Page 105: Water Pump Switch
SECTION 7 – PLUMBING are using water. When you open a faucet, the • Remove the bowl and pull the strainer screen waterline pressure drops and the pump begins to out of the bowl to tap out any particles and run, and it will continue to run as long as the rinse clean.
Page 106: Filtered Water Faucet
SECTION 7 – PLUMBING Water Pump Water Pump Switch (Located in passenger compartment (Located in bath area) near front of coach) -Typical View -Typical View FILTERED WATER FAUCET –If Equipped The filtered water faucet is connected to a flow-through, activated carbon filter cartridge that removes chlorine and odors for taste-free drinking water.
Page 107: Full-Coach Water Filtration System
SECTION 7 – PLUMBING • See Winterization Procedure at the end of this section. Also see filter manufacturer’s information in your InfoCase for further instructions or precautions. • When removing the coach from storage, always disinfect and flush the water system thoroughly before installing a new filter.
Page 108: Disinfecting Your Fresh Water System
SECTION 7 – PLUMBING • Turn the Fresh Water Valve to Normal position, next open a faucet inside the coach or the exterior shower, then turn city water on SLOWLY to allow the canister to fill with water. • Thoroughly flush the filtration system by running the water for twenty (20) minutes.
Page 109 SECTION 7 – PLUMBING concentration of approximately 50 ppm in the 2. Remove the full-coach filter cartridge from water system. (If a 100 ppm concentration is the filter canister to avoid prematurely desired as discussed in step 6, use 3 cups of “plugging up”...
Page 110: Shower Hose Vacuum Breaker
SECTION 7 – PLUMBING SHOWER HOSE VACUUM BREAKER After using the shower, you may notice water dripping from the shower faucet assembly. The dripping results when vacuum in the shower hose (after closing the shower faucet) slowly releases and allows water remaining in the hose to drain Important “Don’ts”...
Page 111: Waste Water System
SECTION 7 – PLUMBING • Don’t put automotive antifreeze or caustic Normal Flush Water chemicals, such as laundry bleach or heavy Saver Flush detergents into the toilet or holding tank. These products may damage plastic or rubber parts in the system. See winterizing instructions at the end of this section to prepare the toilet for storage in freezing conditions.
Page 112 SECTION 7 – PLUMBING 2. Push the handle forward to open the hose end into gray tank. Gray water also rinses valve, then extend the hose and place the any black water solids from the drain nozzle into the disposal opening. hose.
Page 113: Utility Light
SECTION 7 – PLUMBING Using On-Site Sewer Hook-Ups NOTE: If the hose will not collapse while storing, open the hose end valve (handle) The drain hose may remain attached to the to release air trapped inside the hose. dump outlet and be routed out the flip-down hatch in the bottom of the compartment while the 8.
Page 114: Waterline And Tank Drain Valves
SECTION 7 – PLUMBING WATERLINE AND TANK DRAIN VALVES The water drain valves are used to drain water from the water tank and the water supply lines when preparing the motor home for storage or when sanitizing the water system. To Drain Tanks and Waterlines The waterline and tank drain valves are located inside driver and passenger side...
Page 115: Water Heater Bypass Valve
SECTION 7 – PLUMBING WATER HEATER BYPASS Method 1 – Blow Out Procedure VALVE (Drain and purge waterlines using compressed air) -If Equipped (Not available on Models 40CD and This procedure is NOT to be performed 42AD) with coaches equipped with the Aqua- Your coach may be equipped with a water Hot Hydronic Heating System! heater bypass valve for easier winterization of...
Page 116 SECTION 7 – PLUMBING next numbered step.) After emptying the canister, remount it onto the filter assembly and continue the Blow-Out Procedure. 6. Open Faucets. Turn the Water Pump switch ON and open all sink faucets and shower head knobs. Leave open after water stops flowing. 7.
Page 117 16. Reinstall the Water Heater drain plug and the system. A blow-out plug can be purchased close the P-T Relief Valve. ® ® at any Winnebago or Itasca dealership. 17. Pour about one cup of RV antifreeze down each drain for the galley sink, lavatory sink, and shower/tub.
Page 118 SECTION 7 – PLUMBING 20. Flush the sewage tank using the Black Waste Leave water heater bypass valve handle in Tank Flush Inlet (if equipped). NORMAL FLOW position if draining water and blowing out waterlines. Place in BYPASS 21. Close dump valves and refit the dust cap onto position ONLY when using antifreeze solution in the drain outlet.
Page 119 SECTION 7 – PLUMBING 2. Remove the filter canister from the full-coach 5. Remove and save the protective cap from the water filtration system in the water center end of the antifreeze siphon tube (which compartment (if equipped) and discard the connects to Winterization Valve 2).
Page 120: Winterizing Optional Appliances
SECTION 7 – PLUMBING Drain Water Heater instructions at the end of this section.) If not equipped with optional appliances, (Not available on Models 40CD and 42AD) proceed to the next numbered step. 12. Turn off the Water Heater switch before Close All Drain Valves draining the water heater tank to avoid 14.
Page 121 SECTION 7 – PLUMBING compartment on the outside of the coach (see 1. With the Washer/Dryer power OFF, pour 1/2 “Refrigerator Service Access Compartment” quart of RV-type antifreeze into the Washer in Section 4 - Appliances and Systems). drum. 2. Close door. Advance Cycle Selector to “B”. 3.
Page 122 SECTION 7 – PLUMBING To use Washer/Dryer again after seasonal 6. After letting antifreeze drain completely from storage: drum, press the ON/OFF button to turn power OFF. Finished. 1. Reconnect water inlet hoses to corresponding HOT/COLD faucets. Turn faucets ON. To use Washer/Dryer again after seasonal storage: NOTE: Check water inlet hoses and pump...
Page 123: Water System Drain Valve Locations
SECTION 7 – PLUMBING 3. With Washer/Dryer power OFF, pour 1/2 4. Set the controls to the end of the Rinse cycle TBSP. of powder detergent (or liquid to pump the liquid out of the Dishwasher to equivalent) into “Compartment 2” inside make sure the lines and pump contain Dispenser Drawer.
Page 125: Entertainment
SECTION 8 – ENTERTAINMENT The TV will display the DVD logo when the HIGH DEFINITION VIDEO correct input is selected. SELECTION SYSTEM To Watch Satellite TV (Dish) –If Equipped -If Equipped • Connect satellite receiver to accessory connection cables (provided in the prep area). High Definition Video Selection Box (Typical View) The video selection system allows you to...
Page 126: Front Tv Ignition Switch Interlock
SECTION 8 – ENTERTAINMENT AUDIO-VIDEO SYSTEM BASIC OPERATION NOTE: For your convenience, we have also included a handy, tear-out version of this “A/V System Basic Operation” guide in Section 8 of your Operator’s Manual Supplement. See your InfoCase for specific operating guides for audio and video components.
Page 127: Cd/Dvd Player - Bedroom
SECTION 8 – ENTERTAINMENT Play DVD with Theater Sound CD/DVD PLAYER - BEDROOM • Insert DVD into player. DVD will begin to (& Stereo Radio Alarm Clock) load automatically. TV screen will typically –If Equipped show “READING” or “LOADING”. • The DVD may load directly to the main title/menu screen or it may begin to play previews.
Page 128: Cd/Dvd Player
SECTION 8 – ENTERTAINMENT • The DVD may load directly to the main title/ The exterior entertainment center TV is menu screen or it may begin to play previews. connected to the exterior DVD player, video You may be able to skip previews if desired by selection box, the rooftop antenna, and the park pressing the NEXT button until you see the cable input.
Page 129: Tv (Bedroom) - Power Lift
SECTION 8 – ENTERTAINMENT Cable (Park cable input located in power cord compartment) • Turn Off antenna booster inside coach. See above photo. • Turn On TV and tune to desired channel. 1. To raise the TV, press the control switch UP Video Programming from the Video and the TV will pop up through the access lid.
Page 130: Tv Antenna
SECTION 8 – ENTERTAINMENT WARNING Never allow the antenna to touch electrical power lines or any other electrical wires. Raising Antenna to Operating Position Turn elevating crank clockwise in “UP” direction until some resistance to turning is noted (about 13 turns). Antenna is now in operating position.
Page 131: Tv Signal Amplifier
SECTION 8 – ENTERTAINMENT is working properly, the TV picture will now be degraded (snowy). When you turn the switch CAUTION back on, the picture should again be sharp. TV DIGITAL SATELLITE To avoid equipment damage, always align directional handle to DOWN position SYSTEM –...
Page 132: Tv Digital Satellite Dish - In-Motion
System allows you to receive TV programs (if equipped.) directly from satellite to your coach while driving ® See your authorized Winnebago Industries down the road. dealer for proper installation and sealing of roof We recommend that you read the satellite dish mounted components.
Page 133: Portable Satellite Dish And Cable Tv Hook-Ups (Input)
SECTION 8 – ENTERTAINMENT PORTABLE SATELLITE DISH AND CABLE TV HOOK-UPS (INPUT) The portable satellite dish and cable television input connectors are located in the shoreline compartment. The cable television and portable satellite dish input lines can be routed through the hatch in the bottom of the compartment so the door can remain shut while connected.
Page 135: Furniture And Softgoods
SECTION 9 – FURNITURE AND SOFTGOODS LOUNGE CHAIR BASE CLAMP TABLE AND CHAIRS –If Equipped While the vehicle is in motion, the base of the lounge chair must be fastened into position with Dinette Chairs a clamp on the floor as shown. The dinette chairs are free-standing to allow greater freedom of movement than typical booth style dinettes or pedestal seats.
Page 136: Sleeping Facilities
SECTION 9 – FURNITURE AND SOFTGOODS Buffet Chairs WARNING Properly secure all free-standing chairs, furniture, and loose items prior to driving. Moving items can cause driver distraction, possibly resulting in an accident that can result in death or serious injury. SLEEPING FACILITIES 1.
Page 137: Booth Dinette - 40Wd Models
SECTION 9 – FURNITURE AND SOFTGOODS Wall Support Table Bracket 2. Remove the table from the wall support bracket by lifting the end of the table. Then 2. Make sure that the table leg is secured into the lower the table to rest on the cleats attached to floor support bracket and the leg brace is each dinette bench.
Page 138: Sofa/Bed Conversion
SECTION 9 – FURNITURE AND SOFTGOODS • The dinette table may be adjusted to the SOFA/BED CONVERSION position that best suits your needs by moving the table slide mechanism forward or back. Sofa to Bed Lift the front edge of the sofa seat upward and pull outward from the wall while gently pushing downward on the backrest until the cushions lie flat.
Page 139: Rest Easy Multi-Position Lounge
SECTION 9 – FURNITURE AND SOFTGOODS NOTE: Be sure house batteries contain adequate charge. If the batteries are partially discharged, the sofa may not fully recline or return to the upright position. • Slide “fin” on bottom of armrest down between cushion and side of couch REST EASY MULTI-POSITION...
Page 140 SECTION 9 – FURNITURE AND SOFTGOODS To Convert to Bed 1. Extend footrest section and push together with lounge seat cushion, 2. then press recline button until entire lounge lies flat. 3. Reverse steps to return to lounge seating. Pull Strap 3.
Page 141: Extendable Sectional Sofa
SECTION 9 – FURNITURE AND SOFTGOODS EXTENDABLE SECTIONAL SOFA –If Equipped Your coach may be equipped with an L- Shaped Sectional Lounge, which converts easily into additional seating space. The sectional is also featured with the Rest ® Easy powered lounge. See Rest Easy Multi- Position Lounge elsewhere in this section for complete operating instructions.
Page 142: Theater Seating/Bed Conversion
SECTION 9 – FURNITURE AND SOFTGOODS Reverse steps to store the sectional extension. THEATER SEATING/BED To Extend Pull-Out Footrest CONVERSION Section –If Equipped 1. Squeeze latch behind opening at top of lounge face panel and pull footrest trundle section out until it locks in the fully extended position.
Page 143 SECTION 9 – FURNITURE AND SOFTGOODS To Convert to Bed 1. Extend footrest section and push together with lounge seat cushion. 2. Press recline button until entire lounge lies flat. 3. Reverse steps to return to lounge seating. 3. The gap between the footrest and seat should provide ample room to enter and exit the lounge.
Page 144: Sleep Number® Bed
SECTION 9 – FURNITURE AND SOFTGOODS SLEEP NUMBER ® ™ by Select Comfort –If Equipped (2) Adjust to (1) Display Firmer Setting Indicator (3-4) L and R represent the left and right (5) Adjust to side of mattress Softer Setting Power Lift/Lower Control Switch (6) Memory (7) Full-Fill...
Page 145: Roller Shades (Manual) - Solar Day/Night
SECTION 9 – FURNITURE AND SOFTGOODS Preserving Shape A constant-tension cord system holds them at the desired level without slipping. The pleated blinds are made using high quality materials that are designed and woven to Sun Filter retain their shape throughout their useful life. The lower section is a translucent white shade They may lose their crisp shape, however, if left that can be lowered for privacy without...
Page 146: Wood Furniture And Cabinetry
People are drawn to the natural beauty of and the wood is considered part of the natural ® wood. At Winnebago Industries , our craftsmen aging process and is not to be considered defect work with the art found in each piece of wood to or damage.
Page 147: Slideout Rooms And Leveling
SECTION 10 – SLIDEOUT ROOMS AND LEVELING To Release SLIDEOUT ROOM TRAVEL • Press and Hold the UNLOCK side of the LOCKS - ELECTRIC Slideout Room Lock switch for about 7 –If Equipped seconds. (You may be able to hear the lock motor sound stop).
Page 148: Slideout Room Keylock
SECTION 10 – SLIDEOUT ROOMS AND LEVELING SLIDEOUT ROOM RETRACTION (WITH POWER LIFT BED OPTION) -If Equipped Your coach may be equipped with a power lift/lower mechanism that raises and lowers the head of your bed to best suit your comfort needs. This power lift/lower mechanism is equipped with an interlock feature, which will not allow you to retract the bedroom slideout unless the bed...
Page 149 SECTION 10 – SLIDEOUT ROOMS AND LEVELING Systems Monitor Panel. Location varies by alternator can provide maximum power model and floorplan. for proper operation of the slideout mechanisms. Rear slideout switches (if equipped) are located on a wall in the rear of the coach in or Before Extending! near the slide room.
Page 150 SECTION 10 – SLIDEOUT ROOMS AND LEVELING the driver seat, or protruding from compartments which could be crushed or cause damage to floor covering or cabinets NOTICE when the room is retracted. Do not hold a slideout control switch in the “extend”...
Page 151: Slideout Room - Extreme Weather Precaution
SECTION 10 – SLIDEOUT ROOMS AND LEVELING • Press the Slideout Room “RETRACT/IN” switch and hold until the room is fully retracted, then release the switch. NOTE: If your model is equipped with electric slideout locks and the room will not retract, check to be sure the locks are fully released.
Page 152: Slideout Emergency Retraction Procedures
SECTION 10 – SLIDEOUT ROOMS AND LEVELING Operator’s Manual in your InfoCase for SLIDEOUT EMERGENCY control box fuse replacement information. RETRACTION PROCEDURES If no fuses are blown, go to the next step. • If the batteries and fuses are okay, there may Front Slideout Rooms - Emergency be a failure in the hydraulic control system or Crank-In Procedure...
Page 153 SECTION 10 – SLIDEOUT ROOMS AND LEVELING Use provided 1/4” nut driver to turn nut counterclockwise 4 turns only. Hydraulic Pump (Shown with storage bin removed) • The hydraulic pump is equipped with two sets Hydraulic Pump Solenoid Valve of hydraulic solenoid valves that control different systems.
Page 154 SECTION 10 – SLIDEOUT ROOMS AND LEVELING You can speed up the process with the help of an assistant using an additional wrench to CAUTION crank both sides evenly together. DO NOT LOOSEN THE NUTS MORE THAN 4 FULL TURNS. The valve shaft could come out, requiring valve repair or replacement.
Page 155: General Slideout Care
• When the room is snug against the coach wall, close the solenoid valves to prevent “creep out” during transit. See your Authorized Winnebago Indus- ® tries Dealer for service of the slideout system before using again.
Page 156: Leveling System
SECTION 10 – SLIDEOUT ROOMS AND LEVELING LEVELING SYSTEM The leveling system makes selecting a parking site easier and faster by reducing the effect of uneven ground. Hydraulic jacks raise the affected low corners of the coach to make leveling “set up” faster and easier for you.
Page 157 SECTION 10 – SLIDEOUT ROOMS AND LEVELING These switches allow you to extend or retract your jacks and observe them at the same time. It also allows you to stop them suddenly, if needed, without having to climb in and out of the coach. The remote switches are located just inside the entrance door and in the service center.
Page 158: Checking Hydraulic Oil Level
SECTION 10 – SLIDEOUT ROOMS AND LEVELING 4. See the Leveling System Operator’s Manual supplied in your InfoCase for troubleshooting instructions or operating the leveling system if jacks fail to retract or any other functions fail. CHECKING HYDRAULIC OIL Hydraulic Oil Hydraulic Oil FULL Level LEVEL...
Page 159: Maintenance And Storage
• Have the sealant replaced if you notice any of attention. Delaying these repairs may allow water the above. Your local Winnebago Industries leakage and result in damage to interior ceiling dealer has the correct and necessary parts and and body panels, upholstery, etc., which is not experience to help you maintain your sealants.
Page 160: Exterior Automotive Paint Finish
SECTION 11 – MAINTENANCE AND STORAGE weight to the vehicle. This, in effect, reduces the initial 60-day cure stage, a coat of wax or amount of cargo you can carry and remain within polish can help protect the surface from these GVWR and GAWR limits.
Page 161 SECTION 11 – MAINTENANCE AND STORAGE Bug Removal to clean heavy road films on semi trailers and are often dirty. They are not • Rinse the loose debris off with water and designed for custom painted RV’s and allow the remaining residues to soak and they will scratch the clearcoat finish.
Page 162: Care Of Appliques And Decals
LIGHTS They should be treated like any painted surface on your vehicle. Exterior Light Lenses ® Most Winnebago Industries vehicles have Here are a few helpful hints on caring for decals: polycarbonate lenses on exterior lamps, which • Wash appliques and decals with plain soap are very sensitive to a variety of chemical and water or any retail car wash soap.
Page 163: Plastic Parts - Cleaning
SECTION 11 – MAINTENANCE AND STORAGE • Do not use a pressure washer to clean Here is a list of mild cleaners that may be used headlights. safely: • Inspect and operate the lights regularly to • Car washing soap and water confirm proper operation and mounting •...
Page 164: Cabinetry - Cleaning
SECTION 11 – MAINTENANCE AND STORAGE hidden area of fabric before using on visible • Air dry or, if desired, dry quickly using a hair areas. For best results, fabric cleaning should be dryer on warm setting - not hot. referred to a professional carpet and upholstery •...
Page 165: Solid Surface Countertop - Corian
SECTION 11 – MAINTENANCE AND STORAGE Vinyl simulated wood panels may be cleaned To remove cuts and scratches, use a more ® with a mild, water-based cleaner and a soft cloth. aggressive cleaning powder such as Comet Do not use solvents on vinyl wood panels. moistened steel wool soap pad, or green scouring pad.
Page 166: Range And Refrigerator
SECTION 11 – MAINTENANCE AND STORAGE • Never use steel wool. Particles of steel from General Cleaning. Rinse all food, beverage, or the wool pad can embed into the sink surface, cosmetic residue from the sink as soon as then become rusty and unsightly. possible.
Page 167: Vehicle Storage - Preparation
SECTION 11 – MAINTENANCE AND STORAGE engine computer. VEHICLE STORAGE – 7. Have the vehicle chassis completely serviced PREPARATION and lubricated. Be sure radiator antifreeze protection level is sufficient for the lowest Properly preparing your vehicle for storage anticipated temperatures. will lessen the possibility of damage to your vehicle.
Page 168: Chassis Service And Maintenance
SECTION 11 – MAINTENANCE AND STORAGE 9. After flushing fresh waterlines, install a new 3. Be sure the ice bin is in place and the water filter cartridge on the galley sink water automatic shutoff arm is down. filter and/or full-coach water filteration 4.
Page 169: Chassis Diagnostic Connectors
SECTION 11 – MAINTENANCE AND STORAGE Fuse Diagram (inside of cover) Diagnostic Plug (Located on steering column support See the chassis manufacturer’s fuse allocation beneath left side of dash) chart on the inside of the fuse block cover. -Typical View Towing Fuses The fuses for the chassis supplied towing package are located inside the driver side rear...
Page 170: Coach Maintenance Chart
SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Propane Gas System Have propane gas system checked for leaks Pressure Regulator - inspect and adjust if needed Check propane tank condition, mounting, and fittings...
Page 171 SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Safety Equipment Check operation of the following items: Headlights, Taillights, and Marker Lights Turn Signals...
Page 172: Miscellaneous
SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Sealants Inspect (see “Sealants”...
Page 173: Loading The Vehicle
SECTION 12 – MISCELLANEOUS NOTE: We recommend that you dump all LOADING THE VEHICLE holding tanks before traveling to avoid carrying unnecessary weight. NOTE: Your motor home’s load capacity is designated by weight, not by volume, so you cannot necessarily use all available space when loading your motor home.
Page 174 SECTION 12 – MISCELLANEOUS Corner Weighing (Side-to-Side) You will first drive only your front wheels onto the scale pad, then drive ahead so that the The most accurate method of weighing a whole vehicle is on the scale, then finally pull off motor home is to weigh each “corner”...
Page 175: Car Or Trailer Towing
SECTION 12 – MISCELLANEOUS axle is 12,000 lbs., then the load on each rear dual less than hitch rating. set (left rear duals or right rear duals) should not When towing a trailer or vehicle, do not exceed 6,000 lbs. exceed either the GVWR, the rear axle GAWR, Tires must be filled to the recommended air or the chassis GCWR by the combined loaded...
Page 176: Trailer Wiring Connector
SECTION 12 – MISCELLANEOUS Finally, do not forget to consider the actual tongue weight. This should not exceed the stated NOTICE hitch vertical load for your vehicle. This weight is typically defined as the tongue weight of a towed vehicle hitch, boat trailer tongue weight, Exceeding any of the recommended or a receiver-mounted carrier rack.
Page 177: Fireplace
The tow vehicle brakes may be rated for label limiting vertical tongue load to 350 operation at GVWR, not GCWR. lbs. All Winnebago Industries models equipped with a Class IV hitch have a NOTE: State or provincial laws/regulations may label limiting vertical tongue load to 500 require the “trailer”...
Page 178: Entry Step - Electric
SECTION 12 – MISCELLANEOUS Whenever there is a loss of AC power to the fireplace, the remote control provided in your InfoCase will need to be reprogrammed. Entry Step Switch (Located near the entrance door) -Typical View The step has several automatic extend/retract functions that are controlled by the position of a sensor mounted on the inner edge (hinge side) of Fireplace Remote Control...
Page 179: Stepwell Cover
SECTION 12 – MISCELLANEOUS The step WILL RETRACT even if the Step switch is OFF. This feature is intended to prevent injury or damage by an extended step while the vehicle is moving. Further Information For additional information on the step, see the manufacturer’s operators manual included in your InfoCase.
Page 180: Windows
SECTION 12 – MISCELLANEOUS • Pull out the lever on the crank-out handle and begin cranking out the window counter- clockwise to the position desired. Lift snap-in plate from front edge of step cover • To close, crank the window in snugly (by turning the crank-out handle clockwise), then back off 1/4 turn to help avoid glass warping, which can result in wind noise.
Page 181: Power Roof Ventilator - Galley
SECTION 12 – MISCELLANEOUS Vertical Slider Windows Fan Power Fuse Fan Speed Vertical windows have spring-loaded catches Switch Selector on both sides of the window that pop out to hold the window in its fully raised position. Press the catches outward toward the frames while lowering the window.
Page 182: Power Roof Ventilator - Bath
SECTION 12 – MISCELLANEOUS NOTE:In event of power failure the ventilator Fan Power Fan Speed dome may be opened or closed manually Fuse Switch Selector using the Dome Crank knob. Ventilator Thermostat -If Equipped The thermostat lets you set a temperature at which you want the ventilator to open automatically and exhaust room air.
Page 183: Tool And Ladder Storage
SECTION 12 – MISCELLANEOUS Further Information See the power ventilator manufacturer’s operating instructions supplied in your InfoCase for further instructions, care, and cleaning information. TOOL AND LADDER STORAGE The roof ladder extension and various tools supplied with your coach are stored in one or more of the exterior storage compartments.
Page 184: Storage Compartment Doors
SECTION 12 – MISCELLANEOUS • Remove extension from storage clips in cargo compartment. WARNING • Unfold the ladder support and pin into place as Do not exceed 225 lbs. maximum weight capacity. indicated on the following photo. Misuse of ladder could result in death or serious injury. See Operators Manual before using ladder.
Page 185: Power Awning (Over The Door)
SECTION 12 – MISCELLANEOUS complete latching of the compartment doors if Power OFF - The Off position shuts down the they are simply “dropped shut” or closing force is system. The awning cannot be extended or applied only to the center of the door. retracted in this mode.
Page 186: Power Awning (Over The Door)
SECTION 12 – MISCELLANEOUS NOTE: Power On/Off and the Auto-Retract sensitivity can only be operated at the CAUTION control panel. • Extend - Press and release. The awning will extend out to the fully extended position and The Auto-Retract feature provides stop automatically.
Page 187: Air Hose Connector
SECTION 12 – MISCELLANEOUS Quick-connect air coupler at front end of coach The air is supplied by the chassis air brake/ suspension system air accumulator tank. When the air pressure is less than what you need to inflate an item, you must start the coach engine to run the system air compressor to fill the accumulator tank.
Page 188 SECTION 12 – MISCELLANEOUS Ventilate with outside air Partially open one or more windows and a roof vent to circulate outside air through the coach. In cold weather, this ventilation may increase use of the furnace, but it will greatly reduce the condensation inside the coach.
Page 189 INDEX 12-Volt Front Drop-Down Solar/ Disinfecting Your Fresh Water System ..7-6 Night Shade ..........3-9 Doors and Windows ........11-8 2010 New Vehicle Limited Warranty ..1-7 Driving Safety ..........2-1 About this Manual ........1-1 DVD Home Theater System ......8-2 Air Conditioner Filter ........
Page 190 Index Fuel and Propane Gas ........2-1 Power Awning (Over the Door) ....12-14 Fuel Selection – Diesel Engine ....3-20 Power Cord Reel .......... 6-3 Fuel/Water Separator – Diesel ....3-26 Power Door Locks ........3-5 Full-Coach Water Filtration System .... 7-5 Power Roof Ventilator –...
Page 191 Index Slideout Room Keylock ......10-2 Water Heater - Gas/ Electric ...... 4-10 Slideout Room Operation – Hydraulic ..10-2 Water Heater Bypass Valve ....... 7-13 Slideout Room Retraction Water Pump ..........7-2 (with Power Lift Bed Option) ....10-2 Water System Drain Valve Locations ..

This manual is also suitable for:

Itasca ellipse 40bd Itasca ellipse 40cd Itasca ellipse 40wd Itasca ellipse 42ad

Winnebago Itasca Ellipse Owner's Manual

1 Introduction

2 Safety and Precautions

3 Driving Your Motor Home

4 Appliances and Systems

5 Propane Gas

6 Electrical

7 Plumbing

8 Entertainment

9 Furniture and Softgoods

10 Slideout Rooms and Leveling

11 Maintenance and Storage

12 Miscellaneous

Quick Links

TABLE OF CONTENTS

Need help?

Questions and answers

Related Manuals for Winnebago Itasca Ellipse

Summary of Contents for Winnebago Itasca Ellipse
