  • Page 1 Rev. 1521150827 Part No. 161500-15-001 Copyright 2014 Winnebago Industries, Inc. All rights reserved.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1 – INTRODUCTION About this Manual ..........................1-1 Safety Messages Used in this Manual ....................1-1 Pre-Delivery Inspection ........................1-2 Before Driving ..........................1-2 Front Axle Tire Alignment ....................... 1-2 Service and Assistance ........................1-2 Reporting Safety Defects ........................1-2 Occupant and Cargo Carrying Capacity Label .................
  • Page 4 Table Of Contents Remote Keyless Entry ........................3-6 Collision Avoidance System ......................3-6 Hazard Warning Flashers ........................3-6 Air Conditioner/Heater – Automotive (Dash) .................. 3-7 Radio In-Dash/Rearview Monitor System ..................3-7 Radio In-Dash/Rearview Monitor System ..................3-8 Infotainment Center/GPS ........................ 3-10 Battery Boost Switch ........................
  • Page 5 Table Of Contents Electrical System – House 120-Volt AC ..................6-1 Power Cord – External (Detachable) ....................6-1 Power Center ............................. 6-2 Power Center ............................. 6-3 Circuit Breakers – House 120-Volt AC .................... 6-4 Electrical Outlets – House 120-Volt AC ..................6-5 Ground Fault Circuit Interrupter .......................
  • Page 6 Table Of Contents Dining Table (Model 70C) ....................... 9-1 Dining Table (Model 70X) ....................... 9-2 Sleeping Facilities ..........................9-3 Twin/Full-Size Bed Conversion (Model 70A) ................. 9-3 Sofa/Bed Conversion (Model 70A) ....................9-3 Sofa/Bed Conversion (Model 70X) ....................9-5 Fold and Tumble ..........................9-6 Wardrobe Cabinet –...
  • Page 7 Table Of Contents Towing Guidelines .......................... 12-4 Swing-Out Tire Carrier ........................12-5 Windows ............................12-6 Skylight Vent ..........................12-6 Power Roof Ventilator ........................12-7 Power Roof Ventilator ........................12-8 Soap Dispenser ..........................12-8 Slide-Out Compartment Tray ......................12-9 Awning – Power ........................... 12-10 Effects of Prolonged Occupancy ....................

  • Page 9: Introduction

    The instructions included in this manual are intended as a guide, and in no way DANGER indicates a hazardous situation extend the responsibilities of Winnebago which, if not avoided, will result in death or Industries beyond the standard written serious personal injury.

  • Page 10: Pre-Delivery Inspection

    National Highway Traffic Safety Administration (NHTSA) in addition to notifying Winnebago Industries, Inc. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety...

  • Page 11: Occupant And Cargo Carrying Capacity Label

    However, NHTSA cannot become involved in individual problems between you, your dealer, or ® Winnebago Industries To contact NHTSA, you may either call the Vehicle Safety Hotline toll-free at: 1-888-327-4236; (TTY: 1-800-424-9153) or go to their website at http://www.safercar.gov...

  • Page 12: Vehicle Certification Label

    These pressure levels must be maintained to assure proper handling, safety, 2. Chassis manufacture date. and fuel economy. 3. Month and year of manufacture at Winnebago ® 9. Rear Axle Wheel Configuration: Single or Industries Dual as it relates to the inflation.

  • Page 13: Specifications And Capacities

    (26.4 gal) Notes: All information is based upon the most recent data available. Visit the Winnebago Industries, Inc. web page – www.winnebagoind.com – for the most current product information. The height of each model is measured to the top of the tallest standard feature and is based on the curb weight of a typically equipped unit.

  • Page 14: Owner And Vehicle Information

    Motorhome Serial Number ___________________________________________________________ Chassis Vehicle Identification No. (VIN) ________________________________________________ Vehicle Mileage at Delivery __________________________________________________________ Selling Dealer Name ________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ ® YOUR WINNEBAGO INDUSTRIES DEALER /SERVICE CENTER Name ____________________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ Contact ____________________________________________Phone ________________________ CHASSIS SERVICE CENTER...

  • Page 15: Safety And Precautions

    SECTION 2 – SAFETY AND PRECAUTIONS GENERAL WARNINGS DRIVING SAFETY • Only seats equipped with seat belts are to be occupied while the vehicle is moving. WA RNING • Make sure all passengers have seat belts fastened. Lap belts should fit low on the hips and upper thighs.

  • Page 16: Fuel And Propane Gas

    SECTION 2 – SAFETY AND PRECAUTIONS • Do not adjust tilt steering in a moving vehicle. • Do not operate the cruise control on icy or WA RNING extremely wet roads, winding roads, in heavy traffic, or in any other traffic situation where a constant speed cannot be maintained.

  • Page 17: Propane Gas Leaks

    SECTION 2 – SAFETY AND PRECAUTIONS DANGER DANGER Do not use gas cooking appliances for IF YOU SMELL PROPANE comfort heating. Can lead to carbon 1. Extinguish any open flames and all monoxide poisoning, which can lead to smoking materials. death or serious injury.

  • Page 18: Carbon Monoxide Warning

    RV application. We recommend obtaining a replacement from your ® CARBON MONOXIDE ALARM Winnebago Industries dealer. Your coach is equipped with a Carbon Further Information Monoxide (CO) Alarm, which has a sensor that is See the manufacturer’s user guide provided in...

  • Page 19: Smoke Alarm

    RV application. We injury. recommend obtaining a replacement from your ® Winnebago Industries dealer. Replacement When replacing this alarm, we recommend Further Information replacing only with the same model, or with one Please read the information provided by the that is also listed for RV application.

  • Page 20: Fire Extinguisher

    Extinguisher, the replacement must be the same near the sliding entrance door. type and size as the one originally supplied in your coach. We recommend obtaining a replacement only from your Winnebago ® Industries dealer or a reliable RV parts supplier.

  • Page 21: Maintenance

    SECTION 2 – SAFETY AND PRECAUTIONS Escape Door - Rear Double Doors • Never load the motorhome in excess of the gross vehicle weight rating of the gross axle (Model 70A and 70X) weight rating for either axle. • Pull latch (right door) forward and push door open.

  • Page 22: Formaldehyde Information

    SECTION 2 – SAFETY AND PRECAUTIONS FORMALDEHYDE MOLD, MOISTURE, AND YOUR INFORMATION MOTORHOME Some of the materials used in this recreational What is Mold? vehicle emit formaldehyde. Eye, nose, and throat irritation, headache, nausea, and a variety of Molds are part of the natural environment. asthma-like symptoms, including shortness of They are as old as the Earth itself and mold breath have been reported as a result of...

  • Page 23: Roadside Emergency

    This carefully after you are certain the lane is clear. is the extent of coverage provided by Winnebago • Let the vehicle coast to a stop, gently steering Industries.

  • Page 24: Recovery Towing

    Vehicle Certification Label. This will allow the towing operator to determine the proper towing equipment to use. ® Winnebago Industries does not assume responsibility for damage incurred while towing this vehicle. NOTE: Consult your chassis manual for towing instructions or precautions provided by the chassis manufacturer.

  • Page 25: Wheel Trim - Standard

    SECTION 2 – SAFETY AND PRECAUTIONS NOTICE Do not lift on bumper. Damage will result to front end body parts. WA RNING Valve Stem Clearance Notch Stay out from beneath the motorhome while it is suspended by the towing assembly. Do not allow passengers to occupy a towed vehicle.

  • Page 26: Wheels - Stylized Chrome

    SECTION 2 – SAFETY AND PRECAUTIONS When re-installing the front liner, make sure Chrome Lug Nut to align the stem clearance notch on the back of Chrome Washer the liner with the valve stem. WA RNING Chrome Adapter If the notch is not aligned with the valve stem, the valve stem may be damaged which could deflate the tire causing steering or handling problems.

  • Page 27: Jump Starting

    SECTION 2 – SAFETY AND PRECAUTIONS 2. Slide the lug wrench onto the adapter and • Once the vehicle is prepared for stylized rotate counter-clockwise to loosen the lug wheel installation, use the chrome washer, nuts. chrome lug nut, and chrome adapter with lug wrench to re-install the stylized chrome Note: Do not place the wheel nuts in sand or wheel.

  • Page 28: Engine Overheat

    SECTION 2 – SAFETY AND PRECAUTIONS NOTICE Do not attempt to push start this vehicle. Damage to the transmission or other parts of the vehicle will occur. ENGINE OVERHEAT If you see or hear steam escaping from the engine compartment or have any other reason to suspect an extreme engine overheating condition, pull the vehicle over to the roadside as soon as it is safe to do so, stop the engine, and get all...

  • Page 29: Driving Your Motorhome

    SECTION 3 – DRIVING YOUR MOTORHOME The information in this section refers only to SEATS – COMPANION features installed or adapted to the dash and driver compartment area by Winnebago –If Equipped ® Industries . It also includes passenger seating in Removing Companion Seats the living area of the coach.
  • Page 30 SECTION 3 – DRIVING YOUR MOTORHOME • With the seat tilted slightly rearward, lower the Pedestal/Seat Assembly Rear Hooks into the pockets in the floor plate. Rear Hooks (insert into floor plate pockets) • Tip the seat rearward until the lock pin clears Floor Plate the floor plate locking ramp, then re-lock the Locking Arm to avoid bending.

  • Page 31: Seat Belts

    SECTION 3 – DRIVING YOUR MOTORHOME 1- Insert tab into buckle slot until it “clicks” and is locked 3- Press to release 2- Pull strap to tighten Adjustment NOTE: Anytime that the Companion Seat is in the vehicle, it must be in position with the To lengthen belt, swivel the tab end at a right Locking Arm in the LOCKED position, angle to belt and pull strap to desired length.

  • Page 32: Child Restraints

    SECTION 3 – DRIVING YOUR MOTORHOME Lap/Shoulder Belts CHILD RESTRAINTS Fastening A properly installed and secured child Hold the belt just behind the tongue. Next, restraint system can help reduce the chance or bring the belt across the body and insert the severity of personal injury to a child in an tongue into the buckle until the latch engages.
  • Page 33 SECTION 3 – DRIVING YOUR MOTORHOME 2. Tether Shoulder or Lap Belt Tether Anchor Loop (Located on back side of companion seat base) 3. Route the shoulder or lap belt through the child seat. Fasten the shoulder or lap belt and pull snug.

  • Page 34: Keys

    SECTION 3 – DRIVING YOUR MOTORHOME • Vehicle and Motorcycle Forward Collision KEYS Warning - Displays only when a vehicle in the same lane is detected. Your motorhome is supplied with several keys. In addition to the chassis manufacturer’s • Lane Departure Warning - Active above 34 ignition key, you receive keys for the entrance MPH and if turn signals are not used when...

  • Page 35: Air Conditioner/Heater - Automotive (Dash)

    SECTION 3 – DRIVING YOUR MOTORHOME AIR CONDITIONER/HEATER – AUTOMOTIVE (DASH) See your chassis manual for operating information on driver and passenger comfort controls – air conditioner, heater, defroster, and ventilation. NOTE: The dash air conditioner is not designed to cool the entire interior of the coach, but is intended only to provide cooling for the cab area.

  • Page 36: Radio In-Dash/Rearview Monitor System

    SECTION 3 – DRIVING YOUR MOTORHOME USB Cable (Located in compartment above dash radio) Radio Power Switch -Typical Installation (Located on dash) • Press HOUSE to listen to the radio while parked See the manufacturer’s information in your without the ignition key on. InfoCase for operating instructions.
  • Page 37 SECTION 3 – DRIVING YOUR MOTORHOME USB Cable –If Equipped Your coach may be equipped with a cable to connect your USB to play through your radio. The USB cable is located in the compartment above dash radio. Basic Operating Instructions •...

  • Page 38: Infotainment Center/Gps

    SECTION 3 – DRIVING YOUR MOTORHOME by house batteries. If the House/Coach Battery Disconnect switch is OFF, the • Menu • Eject • CD/DVD • Navigation speakers will not emit sound. card slot • Navigation • Camera • Picture-in-Picture • USB port Radio Power Switch •...

  • Page 39: Battery Boost Switch

    SECTION 3 – DRIVING YOUR MOTORHOME Satellite Radio ® Your coach is equipped with a SiriusXM satellite radio receiver that plays through your radio. See the receiver manufacturer’s information in your InfoCase for programming and operating instructions. iPod Connection Your coach is equipped with an iPod Radio Power Switch connection (located in the dash compartment (Located on lower dash area)

  • Page 40: Engine Cooling System

    SECTION 3 – DRIVING YOUR MOTORHOME Battery Boost Switch (Located on lower dash area) • Press and Hold in the ON position while turning Diesel Exhaust Fluid Fill ignition key for emergency starting power. (Located under front hood) -Typical installation shown ENGINE COOLING SYSTEM Further Information Do not remove the radiator cap while engine...

  • Page 41: Valve Stem Access

    SECTION 3 – DRIVING YOUR MOTORHOME VALVE STEM ACCESS ® (Mercedes-Benz Sprinter Chassis) Front Wheel Valve Stem Access on 18-Hole Steel Wheel with Push-On Full Wheel Trim –If Equipped 1. Obtain a double angle push/pull truck tire gauge. 6. When tire pressure testing is complete, reinstall the valve stem cap (with the cap still retained in the hose extension end).
  • Page 42 SECTION 3 – DRIVING YOUR MOTORHOME end, remove valve stem cap, insert valve stem extension into hose extension, and Inner reinstall valve stem extension onto valve rear stem until snug. dual Hose Pull off hose extension and re-insert extension valve stem cap into end of hose. 5.

  • Page 43: Tires

    SECTION 3 – DRIVING YOUR MOTORHOME checked and adjusted after you have fully loaded the motorhome according to your personal needs. Thereafter, the alignment should be periodically inspected to help prevent uneven tire wear. Any excessive or abnormal tire wear may indicate worn or misaligned suspension or steering, unbalanced tire, or other tire/suspension problem.

  • Page 45: Appliances And Systems

    SECTION 4 – APPLIANCES AND SYSTEMS The appliances installed in your motorhome are manufactured by reputable RV appliance makers and have been tested by independent laboratories to meet all applicable standards and codes set for RV appliances. See Section 2 - Safety and Precautions of this manual for any safety and precautions you need to take regarding the operation of your appliances.

  • Page 46: Refrigerator (Model 70C)

    SECTION 4 – APPLIANCES AND SYSTEMS the unit is level. If over 1/2 of the bubble is inside the circle in any direction, the coach is level enough for continuous operation of the refrigerator while parked. Refrigerator Operating Controls (Located inside refrigerator door) •...

  • Page 47: Refrigerator (Model 70X)

    SECTION 4 – APPLIANCES AND SYSTEMS Basic Operation Further Information For further information and operating cautions, see the refrigerator operating instructions included in your InfoCase. REFRIGERATOR (MODEL 70X) The refrigerator in your coach can operate • On/Off Switch from either of three energy sources available to the motorhome: •...

  • Page 48: Refrigerator Service Access Compartment

    SECTION 4 – APPLIANCES AND SYSTEMS • Set the refrigerator on cooling level 3, with an ambient temperature between 60 and 75 degrees. A higher temperature needs a higher cooling level, a lower temperature a lower level. NOTE: The refrigerator will retain temperature more efficiently if food is cold before placing inside.

  • Page 49: Refrigerator Service Access Compartment

    SECTION 4 – APPLIANCES AND SYSTEMS • Latches Refrigerator Access Compartment (Latch Open) To Open 1. Push both latches inward to unlock. 2. Remove the door from the opening. To Close 1. Replace the door into the opening. 2. Push both latches outward to lock. Refrigerator Access Compartment (Latch Closed) •...

  • Page 50: Range Top

    SECTION 4 – APPLIANCES AND SYSTEMS RANGE TOP WA RNING –If Equipped NOTE: See the appliance manufacturer’s user guide provided in your InfoCase for Gas cooking appliances need fresh air for safe operation. complete operating instructions and Before operating: safety precautions. Open vents or windows slightly or turn on exhaust fan prior to using cooking The range in your motorhome operates on...

  • Page 51: Range Top

    SECTION 4 – APPLIANCES AND SYSTEMS RANGE TOP DANGER –If Equipped NOTE: See the appliance manufacturer’s user guide provided in your InfoCase for Do not use gas cooking appliances for complete operating instructions and comfort heating. Can lead to carbon safety precautions.

  • Page 52: Microwave Oven

    SECTION 4 – APPLIANCES AND SYSTEMS At the touch of a button this panel will display the fresh water and holding tank levels, propane NOTICE gas tank level, plus the house battery condition. You can start the generator or turn on the water pump and water heater.

  • Page 53: Oneplace® Systems Monitor Panel

    SECTION 4 – APPLIANCES AND SYSTEMS If a tank is about 1/4 full, the monitor will Refer to the Water Pump information register an empty tank because the fluid level is elsewhere in this section for additional below the 1/3 sensor even though there is still information on the water pump and initial start- fluid in the tank.

  • Page 54: Battery Charge Meter

    SECTION 4 – APPLIANCES AND SYSTEMS Start Stop Sensors Water Tank Hourmeter -Typical View Typical - Your coach may or may not be equipped with all of the features shown. Tank Capacities See “Tank Capacities” in Section 1 - Water And Holding Tank Levels Introduction.

  • Page 55: Power Control System (Pcs)

    SECTION 4 – APPLIANCES AND SYSTEMS • Both the chassis engine and the generator engine must be shut off and 120-volt AC shoreline unplugged. • An interior light should be turned on to provide a small load which draws off the battery surface charge.

  • Page 56: Hydronic Heating System

    SECTION 4 – APPLIANCES AND SYSTEMS 3-Port Solar Cap not completely compensate for continuous low amperage draw from The 3-Port Solar Cap (located on the roof) is components such as the propane gas leak intended to make it easy to add additional solar detector (if equipped), the dash radio panels to the roof, it has a maximum rating of 450 clock, and the radio station memory...
  • Page 57 SECTION 4 – APPLIANCES AND SYSTEMS Interior Heat This system is also equipped with a circulation pump that circulates the heated fluid. Whenever the room thermostat calls for heat, the water heating solution is circulated through interior heat convector's (similar to radiators) that distributes heat evenly throughout your RV.

  • Page 58: Water Heater - Gas/ Electric

    SECTION 4 – APPLIANCES AND SYSTEMS For Electric Operation WATER HEATER – GAS/ Turn on the Water Heater electric element ELECTRIC switch. The shoreline must be connected or –If Equipped generator running for electric operation. The gas/electric water heater has a dual power feature.

  • Page 59: Furnace - Propane Gas

    SECTION 4 – APPLIANCES AND SYSTEMS • Lift handle straight out to open P-T valve when water heater is cold. Water Heater Exterior Service Access -Typical View -Typical View 4. Let the handle of the P-T valve snap shut. Normally there is an air gap at the top of the water heater tank, which acts as a pressure buffer.

  • Page 60: Roof Air Conditioning - With Heat Pump

    SECTION 4 – APPLIANCES AND SYSTEMS To Shut Down Thermostat/Switch • Move Thermostat switch to OFF position. • Move from OFF to desired temperature for furnace operation • Close Propane Gas Tank valve if coach will be stored for a period of time. Further Information Refer to the manufacturer’s user guide provided in your InfoCase for further...

  • Page 61: Roof Air Conditioning - With Heat Strip

    SECTION 4 – APPLIANCES AND SYSTEMS To operate the heat pump ROOF AIR CONDITIONING – • Turn the selector switch to the “High Heat” WITH HEAT STRIP position, which allows the fan to operate at –If Equipped high speed with maximum heat output. •...

  • Page 62: Roof Air Conditioning System

    SECTION 4 – APPLIANCES AND SYSTEMS the cooling mode, it will continue to cycle the compressor on and off until the selector switch is turned to another operation mode. • Position the louvers to the desired direction the discharge air is to flow. During Cooler Nights When outdoor temperatures drop in the evening or at night below 75 degrees F, the...

  • Page 63: Propane Gas

    SECTION 5 – PROPANE GAS PROPANE GAS SUPPLY WA RNING The propane gas system supplies fuel for the gas range/oven, water heater, furnace, and refrigerator (while in gas mode). When used and Do not alter or remove propane tank handled properly, this system is safe and valves or gauge.

  • Page 64: Safe Use Of The Propane Gas System

    SECTION 5 – PROPANE GAS Butane burns about 30 percent hotter than propane and can overheat some DANGER appliances, particularly refrigerators, and cause permanent damage. Other appliances designed to operate on All pilot lights, appliances, and their propane can become sooted and lose igniters (see operating instructions) shall efficiency by using butane fuel.

  • Page 65: Propane Gas Warnings And Precautions

    SECTION 5 – PROPANE GAS system components should be performed only by your dealer or a qualified propane gas DANGER service center. • Never attempt to connect natural gas to the propane gas system. IF YOU SMELL PROPANE • Have the entire propane gas system inspected 1.

  • Page 66: Propane Gas Pressure Regulator

    SECTION 5 – PROPANE GAS • Never use an open flame to test for propane gas leaks. Replace all protective covers and caps on propane system after filling. Make sure valve is closed and door latched securely. • Portable fuel-burning equipment, including wood and charcoal grills and stoves, shall not be used inside the recreational vehicle.

  • Page 67: Propane Vaporization In Cold Weather

    SECTION 5 – PROPANE GAS If regulator freeze-up should occur, you may attempt to thaw the regulator using a light bulb. DO NOT USE AN OPEN FLAME OR HEAT LAMP. If moisture begins to cause problems, have your propane gas dealer inject a small amount of dry methyl alcohol in your tank (approximately one ounce to 20 pounds or one pint to 100 gallons) to help guard against regulator freeze-...

  • Page 69: Electrical

    SECTION 6 – ELECTRICAL Your coach is equipped with an electrical the power converter automatically changes a system consisting of two separate voltages: portion of the 120-volt current to 12-volt DC current. All equipment in the motorhome that is • 12-volt DC system (battery current);...

  • Page 70: Power Center

    SECTION 6 – ELECTRICAL To connect to an external power source, plug the adapter end into the sidewall plug-in (located WA RNING above the rear driver side wheel) and the receptacle end to a suitable power outlet box. Service inlet access must be closed when utility connections are not in use.

  • Page 71: Power Center

    SECTION 6 – ELECTRICAL Certain circuits, however, remain unchanged overheated. This can result from operating above for use by items which require 120-volt current, its maximum limit for an extended period of time such as the air conditioner(s), the refrigerator in or by obstruction of ventilation to unit.

  • Page 72: Circuit Breakers - House 120-Volt Ac

    SECTION 6 – ELECTRICAL overheating. A portion of the house 12-volt load (lights or motors or both) should be turned off to NOTICE reduce total load. Also, inspect the power converter to make sure ventilation is not obstructed. Do not block the converter cover vents in any way.

  • Page 73: Electrical Outlets - House 120-Volt Ac

    SECTION 6 – ELECTRICAL If the GFCI keeps tripping, have the electrical system checked and repaired, if necessary, before using again. • Push to Reset circuit after monthly testing or ground fault tripping. • Push to Test at 120-Volt Circuit Breakers least monthly.

  • Page 74: Automatic Power Transfer Switch

    SECTION 6 – ELECTRICAL Automatic Power Transfer Switch Operation Warnings and Cautions Whenever the generator is needed, an automatic power transfer system automatically WA RNING switches the household electrical system to the generator 10 seconds after the generator is started. The 10-second delay allows the generator The exhaust of all internal combustion to start easily without the burden of electrical engines contains carbon monoxide (CO).

  • Page 75: Electrical Generator

    SECTION 6 – ELECTRICAL ELECTRICAL GENERATOR –If Equipped *Model 70C WA RNING Careless handling of the generator and electrical components can be fatal. Never touch electrical leads or appliances Generator Start/Stop Buttons when your hands are wet, or when (Located on monitor panel) standing in water or on wet ground.

  • Page 76: Electrical System - House 12-Volt Dc

    SECTION 6 – ELECTRICAL Operation Warnings and Cautions Converter See “Power Center.” Chassis Battery WA RNING The chassis battery is used to operate the engine starter and automotive accessories and The exhaust of all internal combustion controls found on the instrument panel. The engines contains carbon monoxide (CO).

  • Page 77: Battery Access

    SECTION 6 – ELECTRICAL Always leave this switch ON while using the coach. NOTE: Some electronic displays and memory functions may need to be reset after power has been reconnected. See also “Battery Care” elsewhere in this section. House Battery Access House/Coach Battery Disconnect Switch •...

  • Page 78: Battery Care

    SECTION 6 – ELECTRICAL BATTERY CARE Lead-acid type batteries are electro-chemical devices for storing and releasing electrical charge. As such, they are simply an electrical reservoir, not an electrical source. As soon as energy is removed from the battery, it should be replaced by the engine alternator or the coach converter system.
  • Page 79 SECTION 6 – ELECTRICAL WA RNING WA RNING This vehicle, like other vehicles, may Before removing any battery cables or contain small amounts of one or more battery, make sure all 12-volt equipment substances which are listed by the state in the motorhome is off and the power of California for causing cancer or cord has been disconnected.

  • Page 80: Circuit Breakers And Fuses - House 12-Volt Dc

    ELECTRICAL Chassis Battery If your coach is going to be unoccupied for ® two weeks or more, Winnebago Industries recommends disconnecting the chassis battery in your coach to avoid battery discharge. Unplug the Chassis Battery Connector (located to the right of the accelerator pedal) to disconnect battery.
  • Page 81 SECTION 6 – ELECTRICAL Automotive Chassis 12-Volt Circuit Breakers (Located on outboard side of passenger seat) * Shown with cover removed -Typical View 6-13...

  • Page 83: Plumbing

    SECTION 7 – PLUMBING FRESH WATER SYSTEM (MODEL 70A AND 70X) The Fresh Water System provides water to the galley sink, shower, bathroom lavatory, toilet, and water heater. Water may be supplied by either of two sources: • A fresh water tank and water pump located within the motorhome, or •...
  • Page 84 SECTION 7 – PLUMBING Fresh Water Valve Fresh Water Valve (Located in water service center) (Located in water service center) -Typical View -Typical View 4. Turn city water supply ON. Using City Water 5. Use the level display on the monitor panel to When connected to an outside source of water, oversee filling of the tank, or when the tank is the water bypasses the water pump and storage...

  • Page 85: Fresh Water System (Model 70C)

    SECTION 7 – PLUMBING Using Tank Water (Gravity Fill) NOTE: Ensure the Fresh Water valve is in NORMAL position to use the water • Turn Water Pump switch ON. While the pump. If the valve is in Tank Fill position, switch is on, the water pump will the pump will run continuously without automatically supply tank water as needed.
  • Page 86 SECTION 7 – PLUMBING Always fill the fresh water tank at an approved 4. Use the level display on the monitor panel to potable water filling facility or a known purified oversee filling of the tank, or when the tank is drinking water source.

  • Page 87: Water Pump

    SECTION 7 – PLUMBING Water Pump Strainer 2. With the Fresh Water valve in the Normal position, turn the Water Pump switch(es) The pump is equipped with a cleanable OFF. strainer to capture any possible tank-borne particles that could damage pump components. NOTE: Always keep the Fresh Water valve in Normal position unless you are filling the NOTE: We recommend that you check and clean...
  • Page 88 SECTION 7 – PLUMBING Water Pump Switch Water Pump (Model 70A) The Water Pump switch is located near the monitor panel (some models may have an additional switch in the water service center, near the exterior shower, or within the bathroom area for your convenience).

  • Page 89: Cold Water Filter

    SECTION 7 – PLUMBING Water Pump (Model 70X) Replacing the Cold Water Filter Cartridge You should replace the filter cartridge every season and when water flow from the faucet is too slow for convenience. The cartridge must be replaced at least every 12 months. •...

  • Page 90: Disinfecting Your Fresh Water System

    SECTION 7 – PLUMBING Use 1 gallon solution for each 15 gallons of tank capacity. This procedure will result in a residual chlorine concentration of 50 ppm in the water system. NOTE: If a 100 ppm concentration is desired, use 1/2 cup of household bleach with 1 gallon of water to prepare the chlorine solution.
  • Page 91 SECTION 7 – PLUMBING Disinfecting with City Water Fill When disinfecting through the city water fill, an external cartridge-type water filter assembly must be connected in-line between the city water hose and the city water fill to add disinfecting solution to the tank. These filters are commonly available at most RV supply stores.

  • Page 92: Shower Hose Vacuum Breaker

    SECTION 7 – PLUMBING the bleach into the tank and fill the tank with outside the coach. Some models may have a water. water pump switch located in the service center This method has the additional benefit of for convenience. disinfecting the city water hose at the same time.

  • Page 93: Waste Water System (Model 70A And 70C)

    SECTION 7 – PLUMBING • Don’t put automotive antifreeze or caustic 2. Remove dust cap from sewage drain outlet chemicals, such as laundry bleach or heavy and connect sewage drain hose. Be sure it is detergents into the toilet or holding tank. firmly attached.

  • Page 94: Waste Water System - Waste Pump (Model 70X)

    SECTION 7 – PLUMBING Holding Tank Level Indicators NOTE: DO NOT OPEN BOTH VALVES AT ONCE. Do not open the Gray Waste Tank See “Systems Monitor Panel” in Section 4 - Drain valve until the black tank is Appliances for further information on the drained and dump valve closed to avoid monitor panel and checking tank levels.

  • Page 95: Dumping Holding Tanks

    SECTION 7 – PLUMBING NOTE: If Waste Pump stalls, check breaker in until tank is empty (do not run pump dry.) the load center. If problem persists, Move the hose gently about to dislodge any remove end cap and manually turn pump waste and ensure complete drainage.

  • Page 96: Waterline And Tank Drain Valves

    SECTION 7 – PLUMBING NOTE: Sound of Waste Pump will change significantly when tank is empty. WA RNING Service inlet access must be closed when utility connections are not in use. When using a sewer hook-up, keep the dump valves closed until a tank becomes full or when preparing to leave the site.

  • Page 97: Water Heater Bypass Valve

    SECTION 7 – PLUMBING D R A I N D R A I N C L O S E C L O S E L I N E - E N D V A L V E I N - L I N E V A L V E Waterline Drain Valves (Typical)

  • Page 98: Winterizing Procedure

    SECTION 7 – PLUMBING Leave bypass valve handle in NORMAL FLOW position if draining water and blowing out waterlines. Place in BYPASS position ONLY when using antifreeze solution in waterlines. WINTERIZING PROCEDURE You can winterize the water and plumbing system of your coach using one of the following two methods: •...
  • Page 99 A “blow-out” plug can be purchased at any closed. ® Winnebago Industries dealer. Do not add automotive antifreeze or caustic chemicals such as bleach or laundry detergents into the toilet bowl or...
  • Page 100 SECTION 7 – PLUMBING holding tanks. Although these products The system features a Winterization (diverter) may have a deodorizing effect, they may valve with an antifreeze siphon tube to draw non- damage plastic and rubber parts in the toxic RV water system antifreeze into the system.
  • Page 101 SECTION 7 – PLUMBING • Install the diverter plug into the filter socket. Insert plug up into the filter socket as far as possible and twist clockwise (to the right) one-quarter turn until it stops. • Winterization Port • Antifreeze Siphon Tube Set Up Winterization Valves Antifreeze Siphon Tube/Winterization Port 2.
  • Page 102 SECTION 7 – PLUMBING Fill Lines 5. Turn the Water Pump switch ON. 6. Open each hot and cold water faucet handle/ knob in the coach - one at a time each in turn until antifreeze solution just begins to flow from the faucet, then close.
  • Page 103 SECTION 7 – PLUMBING Dump and Clean Holding Tanks 12. Completely drain the waste water holding tanks at an approved waste disposal site. Drain the sewage (black) tank first so the following waste water can rinse any waste solids from the dump outlet and sewage drain hose.

  • Page 104: Water System Drain Valve Locations

    SECTION 7 – PLUMBING WATER SYSTEM DRAIN VALVE LOCATIONS Model System Drain Valve Locations Waterline Drain • Two (2) drain valves in water service center. Valves • Two (2) drain valves beneath bed cabinet (driver side). Remove top panel to access. •...
  • Page 105 SECTION 7 – PLUMBING Waterline Drain • Three (3) drain valves in water service center. Valves • Open exterior shower faucet and lay shower head on ground. Place the tip of your finger inside the city water connection and gently press the backflow valve (small “button” in center of connector) to drain cold water from the city waterline.

  • Page 107: Entertainment

    SECTION 8 – ENTERTAINMENT TV (12-VOLT LED) TV – INDOOR/OUTDOOR (MODEL 70A) The LED flat panel TV is powered by 12-volt DC current. Your coach is featured with swivel TV The 12-volt current is supplied from the house mechanism, which allows you to watch TV batteries (or from the power converter when inside or outside your vehicle.

  • Page 108: Tv - Swivel

    SECTION 8 – ENTERTAINMENT NOTE: Ensure TV is in the stored position AUDIO/VIDEO SYSTEM BASIC (facing interior of coach) before closing OPERATION the sliding entrance door to avoid property damage. NOTE: For your convenience, we have also included a handy, tear-out version of this Further Information “A/V System Basic Operation”...

  • Page 109: Exterior Speakers

    SECTION 8 – ENTERTAINMENT Set TV Video Input 2. Turn the TV ON. 3. Press the AUX button (located just below the • Turn TV and DVD player ON. display on the face of the DVD player.) This • Press the MODE button on the TV or the will route the TV stereo sound output through SOURCE button on the DVD player remote the DVD player and out to the Deluxe Sound...

  • Page 110: Tv Antenna - Digital

    SECTION 8 – ENTERTAINMENT Digital Antenna Power Switch Exterior Speaker Switch (Located in an overhead cabinet or “Speaker C” mounted on a wall near the TV) (Located on the interior stereo radio) 2. Turn ON the Signal Meter Power switch (located on the side of the Signal Meter).

  • Page 111: Tv Signal Amplifier

    SECTION 8 – ENTERTAINMENT 6. Rotate antenna to illuminate the last flickering LED light. 7. Repeat Steps 5 and 6 to pinpoint signal reception. NOTE: Refer to television manufacturer’s instructions to scan for available channels. Further Information See the antenna manufacturer’s user guide HDMI Connection provided in your InfoCase for complete operating (Located in cabinet near TV)

  • Page 112: Exterior Cable Tv - 12V Connection

    SECTION 8 – ENTERTAINMENT EXTERIOR CABLE TV – 12V CONNECTION –If Equipped The exterior cable TV/12-volt connection receptacle on your coach provides connection for use of a TV and/or 12-volt device for your outdoor entertainment. Exterior Cable TV / 12-Volt Connection (Located on passenger sidewall) -Typical View...

  • Page 113: Furniture And Softgoods

    SECTION 9 – FURNITURE AND SOFTGOODS • Insert dinette table leg into metal receiver on DINING TABLE (MODEL 70A) the floor (located behind cab seats). • Lift rear bed board to the open position. • Place dinette table top securely on dinette table leg.

  • Page 114: Dining Table (Model 70X)

    SECTION 9 – FURNITURE AND SOFTGOODS • Insert pedestal leg into the metal receiver on • Insert dinette table leg into metal receiver on the floor. the floor. NOTE: Your coach may be equipped with two metal receivers - one in the rear of the coach in front of the sofa and one in front Pedestal of the two companion seats.

  • Page 115: Sleeping Facilities

    SECTION 9 – FURNITURE AND SOFTGOODS SLEEPING FACILITIES WA RNING Sleeping facilities are not intended for use while vehicle is in motion. For safety, passengers must use safety belted seating positions while vehicle is in motion. • Reverse steps to convert back into twin beds. TWIN/FULL-SIZE BED SOFA/BED CONVERSION CONVERSION (MODEL 70A)
  • Page 116 SECTION 9 – FURNITURE AND SOFTGOODS 2. Lift countertop extension (located on galley 5. Remove cushion extension from rear of end) up until it “clicks” in the extended vehicle (accessible through rear doors). position. 6. Adjoin cushion extension hooks with metal 3.

  • Page 117: Sofa/Bed Conversion (Model 70X)

    SECTION 9 – FURNITURE AND SOFTGOODS To Store Countertop Extension SOFA/BED CONVERSION • Grasp the release loop (on underside of (MODEL 70X) countertop extension) and pull outward toward front of vehicle. Sofa to Bed (Typical View – Your coach may differ in appearance) WA RNING Keep people away from operating...

  • Page 118: Fold And Tumble

    SECTION 9 – FURNITURE AND SOFTGOODS Bed to Sofa • Arrange cushions to maximize sleeping area. • Press and Hold the UP arrow on the electric couch switch until couch is in the fully upright position, then release. • Reverse steps to store bed extension. FOLD AND TUMBLE (Model 70C) –If Equipped...

  • Page 119: Wardrobe Cabinet - Removable

    SECTION 9 – FURNITURE AND SOFTGOODS Sofa to Bed • Pull sofa seat UP and OUT. Removable Wardrobe Cabinet (Installed in place of inboard • Pull sofa back cushion OUT and DOWN. Companion Seat) To Remove Wardrobe Cabinet NOTE: Remove personal items from cabinet before removing from coach.
  • Page 120 SECTION 9 – FURNITURE AND SOFTGOODS Locking Arm (Located inside Wardrobe Cabinet) - Unlocked position shown 3. Reinstall wood panel inside cabinet and close Refer to “Seats - Companion” in Section 3 - wardrobe doors. Driving Your Motorhome for installing and 4.

  • Page 121: Roller Shades

    CABINETRY –If Equipped People are drawn to the natural beauty of ® wood. At Winnebago Industries , our craftsmen work with the art found in each piece of wood to create cabinets of superior quality, backed by the Winnebago Industries warranty.
  • Page 122 No matter which species you chose for your new Winnebago Industries motorhome cabinetry, please keep in mind that no two pieces of wood are exactly the same.

  • Page 123: Slideout Rooms

    The ignition key must be placed in the on or run position to operate the slideout room(s). The park brake must be applied for the room(s) to run. Winnebago recommends running the engine whenever you run the slideout rooms in or out, the engine alternator should insure the rooms have adequate 12-volt DC power to operate correctly.
  • Page 124 SECTION 10 – SLIDEOUT ROOMS To Retract Slideout Room Before Retracting! WARNING • Be sure the coach is level and the Parking Brake is set. CRUSH HAZARD. Keep people and • Ensure exterior compartment doors are closed objects clear of the inside and outside of so that they will not interfere with slideout the slideout room when operating.

  • Page 125: Slideout Room - Extreme Weather Precaution

    SECTION 10 – SLIDEOUT ROOMS • Press the Slideout Room “RETRACT/IN” If the slideout mechanism is malfunctioning switch and hold until the room is fully and the room will not retract using the interior retracted, then release the switch. control switch, you may need to disconnect the motor/gear assembly and manually push the •...

  • Page 126: General Slideout Care

    SECTION 10 – SLIDEOUT ROOMS Slideout Room Seal Care and Maintenance 1) Lift tab inside protrusion on boot to disengage motor brake. While most household cleaners work well for cleaning slideout room seals, certain chemical agents may cause the seals to degrade. Typically, ®...

  • Page 127: Maintenance And Storage

    • Have the sealant replaced if you notice any of vehicle can cause damaging rust or corrosion on the above. Your local Winnebago Industries steel or aluminum parts and can add needless dealer has the correct and necessary parts and weight to the vehicle.

  • Page 128: Exterior Finish

    SECTION 11 – MAINTENANCE AND STORAGE undercarriage regularly with water, especially NOTE: Avoid aiming water flow from a hose or horizontal surfaces, cavities, and other areas spray from high-pressure washing where mud and other deposits may collect. equipment into any appliance intake because damage or difficulty in operating appliances may occur.

  • Page 129: Exterior Graphic Care

    SECTION 11 – MAINTENANCE AND STORAGE NOTE: If you use a polish or a cleaning compound that does not contain a wax NOTICE preservative, we recommend reapplying a coat of hard wax after cleaning or polishing the finish. Do not use citrus-based cleaners on polycarbonate finishes.

  • Page 130: Exterior Lights

    EXTERIOR LIGHTS motorhome is parked for an extended ® period of time. Most Winnebago Industries vehicles have polycarbonate lenses on exterior lamps, which are very sensitive to a variety of chemical WA RNING solvents and cleaners.

  • Page 131: Cabinetry - Cleaning

    SECTION 11 – MAINTENANCE AND STORAGE Vinyl simulated wood panels may be cleaned with a mild, water-based cleaner and a soft cloth. UltraLeather Cleaning Chart Do not use solvents on vinyl wood panels. Detergent/ Cleaner/ Type of Stain Water Degreaser NOTE: Many cabinetry and furniture items ...

  • Page 132: Tables And Countertops

    SECTION 11 – MAINTENANCE AND STORAGE If the stain is not water-base or oil-base TABLES AND COUNTERTOPS material, you may need to gently remove it using a plastic scraper (disposable plastic knife for Work surfaces are covered with a plastic or example) followed by normal cleaning methods thermo-formed laminate that resists solvents, described above.

  • Page 133: Range And Refrigerator

    SECTION 11 – MAINTENANCE AND STORAGE • Remove spills immediately with a damp RANGE AND REFRIGERATOR cloth, followed by rinsing with clean water. For care and appearance maintenance of the • The use of stiletto heels is not recommended, range and refrigerator, refer to the appliance as they may cause permanent damage to the manufacturer’s operation and maintenance flooring.

  • Page 134: Bathroom

    SECTION 11 – MAINTENANCE AND STORAGE 4. Clean and defrost the refrigerator. Prop the BATHROOM door open slightly to allow any odors to dissipate. Place an open box of baking soda Toilet inside the refrigerator to help absorb odors. For instructions on the care of your toilet, refer 5.

  • Page 135: Vehicle Storage - Removal

    SECTION 11 – MAINTENANCE AND STORAGE 13. Follow “Vehicle - Leaving in Storage” 12. Check around all appliances for obstructions suggestion in chassis owner’s manual and ensure that all vent openings are clear. included in your InfoCase. 13. Start refrigerator and check for proper If you are storing your vehicle through the cooling.

  • Page 136: Coach Maintenance Chart

    SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Propane Gas System ...
  • Page 137 SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Safety Equipment Check operation of the following items: ...
  • Page 138 SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Sealants ...

  • Page 139: Miscellaneous

    SECTION 12 – MISCELLANEOUS NOTE: We recommend that you dump all LOADING THE VEHICLE holding tanks before traveling to avoid carrying unnecessary weight. NOTE: Your motorhome’s load capacity is designated by weight, not by volume, so you cannot necessarily use all available space when loading your motorhome.
  • Page 140 SECTION 12 – MISCELLANEOUS Corner Weighing (Side-to-Side) You will first drive only your front wheels onto the scale pad, then drive ahead so that the The most accurate method of weighing a whole vehicle is on the scale, then finally pull off motorhome is to weigh each “corner”...

  • Page 141: Car Or Trailer Towing

    SECTION 12 – MISCELLANEOUS axle is 12,000 lbs., then the load on each rear dual Because of individual vehicle use and loading set (left rear duals or right rear duals) should not habits, we recommend weighing the vehicle exceed 6,000 lbs. while fully loaded to avoid exceeding any of the listed Gross Weight Ratings.

  • Page 142: Trailer Wiring Connector

    SECTION 12 – MISCELLANEOUS We do not recommend the usage of a “surge- TRAILER WIRING style” braking device. The usage of a surge brake CONNECTOR (especially when coupled with a hitch ball located outside our recommended limits) places Your coach is pre-wired for trailer or car excessive stress on the hitch.

  • Page 143: Swing-Out Tire Carrier

    ® NOTE: Some Winnebago Industries models equipped with a Class 3 hitch may have a label limiting vertical tongue load to 350 lbs. All Winnebago Industries models equipped with a Class IV hitch have a 12-5...

  • Page 144: Windows

    SECTION 12 – MISCELLANEOUS 3. Swing-out tire carrier and open rear doors. 4. To lock the swing-out carrier in the extended position, move the locking bolt and pin to the hole shown in the following photo. • To close window, crank the window in snugly by turning the crank-out handle “clockwise”, then back off 1/4 turn to help avoid glass warping, which can result in wind noise.

  • Page 145: Power Roof Ventilator

    SECTION 12 – MISCELLANEOUS Further Information See the skylight vent manufacturer’s operating instructions supplied in your InfoCase for further instructions, care, and cleaning information. POWER ROOF VENTILATOR –If Equipped The vent dome is raised and lowered using the Dome Crank knob on the fan. The turbine fan will start automatically as the •...

  • Page 146: Power Roof Ventilator

    SECTION 12 – MISCELLANEOUS 4. Open a window or door to provide airflow. 4. Pull the Fan Lift Bar down to close dome. Direction of airflow is determined by which window or door is opened. SOAP DISPENSER NOTE: For best results, close all other roof –If Equipped vents, windows, and doors, then open The Soap Dispenser in your vehicle is a...

  • Page 147: Slide-Out Compartment Tray

    SECTION 12 – MISCELLANEOUS 2. Insert Cover Lock/Key into lock opening on the side of dispenser. 3. Press release button (located on bottom of dispenser) to open. 3. Rotate Cover Lock/Key “clockwise” to the OFF position and remove Key. The dispenser is now locked. NOTE: When the Key is removed, the Cover Lock will remain intact.

  • Page 148: Awning - Power

    SECTION 12 – MISCELLANEOUS Power Awning and Awning Light Switch (Located at front of galley or shower wall) -Typical View 2. Extend slide tray. A Second Power Awning switch is located near the right side of the passenger seat. 3. To store, push slide tray in until it “clicks” into locked position.

  • Page 149: Effects Of Prolonged Occupancy

    SECTION 12 – MISCELLANEOUS Operating the Awning Humidity and Condensation Moisture condensing on the inside of Note: The awning opens and closes with a steep windows is a visible indication that there is too pitch. On low profile vans, the leading much humidity inside the coach.
  • Page 151 INDEX About this Manual ..........................1-1 Air Conditioner Filter ........................... 4-18 Air Conditioner/Heater – Automotive (Dash) ..................3-7 Audio/Video System Basic Operation ....................8-2 Audio/Video System Connection ......................8-5 Awning – Power ..........................12-10 Bathroom .............................. 11-8 Battery Access ............................6-9 Battery Boost Switch ..........................
  • Page 152 Index Engine Overheat ............................ 2-14 Exterior Cable TV – 12V Connection ....................8-6 Exterior Finish ............................11-2 Exterior Graphic Care ........................... 11-3 Exterior Lights ............................11-4 Exterior Shower/Wash Station ......................7-10 Exterior Speakers ............................ 8-3 Fire Extinguisher ............................. 2-6 Fold and Tumble ............................. 9-6 Formaldehyde Information ........................
  • Page 153 Index Propane Gas Leak Detector ........................2-3 Propane Gas Leaks ..........................2-3 Propane Gas Pressure Regulator ......................5-4 Propane Gas Supply ..........................5-1 Propane Gas Warnings and Precautions ....................5-3 Propane Vaporization in Cold Weather ....................5-5 Radio In-Dash/Rearview Monitor System ....................3-7 Radio In-Dash/Rearview Monitor System ....................
  • Page 154 Index Specifications and Capacities ......................... 1-5 Suspension Alignment and Tire Balance ....................3-15 Swing-Out Tire Carrier ......................... 12-5 Systems Monitor Panel ........................... 4-8 Tables and Countertops ........................11-6 Tires ..............................3-15 Toilet ..............................7-10 Towing Guidelines ..........................12-4 Trailer Wiring Connector ........................12-4 TV –...

Table of Contents

Save PDF
