■ Menu screen items

The Menu screen contains the following items.
D DSC Calls
Item Ref.
• Individual Call p. 27
• Individual ACK* 1 p. 31
• Group Call p. 32
• All Ships Call p. 34
• Distress Call p. 23
• Transmitted Call Log p. 59
* 1 Displayed only after receiving a corresponding call.
* 2 For only U.S.A and Australian version transceivers.
D DSC Settings
Item Ref.
• Position Input* 3 p. 22
• Individual ID p. 19
• Group ID p. 20
• Individual ACK p. 62
• Position ACK p. 62
3
* Displayed only when no GPS information is received.
Item Ref.
• Received Call Log p. 60
• Position Request Call* 2 p. 35
• Position Report Call* 2 p. 37
• Polling Request Call* 2 p. 59
• Test Call p. 41
1
• Test ACK* p. 43
Item Ref.
• Test ACK p. 62
• CH 16 Switch p. 63
• Alarm p. 64
• CH 70 SQL Level p. 64
• DSC Loop Test p. 65
MENU SCREEN OPERATION
D Radio Settings
Item Ref.
• Scan Type p. 70
• Scan Timer p. 70
• Dual/Tri-Watch
D Configuration
Item Ref.
• Backlight p. 71
• Display Contrast p. 71
• Key Beep p. 71
• Key Assignment p. 72
D MMSI/GPS Info
The transceiver shows the preset MMSI and ATIS*
and GPS information* 5 .
If the code is not entered, "NO DSC MMSI" or "NO ATIS
MMSI"* 4 is displayed.
* 4 Displayed only for the Dutch and German version transceivers.
* 5 Displayed only when an external GPS receiver or built-in GPS re-
ceiver is receiving valid position data.
8
Item Ref.
• CHAN Group p. 70
• WX Alert* 2 p. 71
Item Ref.
• UTC Offset p. 73
• Inactivity Timer p. 73
• NMEA Output p. 74
• Remote ID p. 74
4 codes
