Vm110P (Plus) Top; Vm110P (Plus) Bottom - NTI VM110 Installation And Operation Instructions Manual

│
Field Wiring
DHW Out
DHW Recirc.
DHW In
Condensate Drain
Central Heat Outlet
Central Heat Inlet
38
Figure 10-3(a) VM110P (Plus) Top
Figure 10-3(b) VM110P (Plus) Bottom
Vmax I&O Manual
Auto Air Vent
(factory supplied)
30 PSI Relief Valve
(factory supplied)
3/4x1/2x3/4" Brass Tee
(factory supplied)
3/4" Brass Street Elbow
(factory supplied)
150 PSI T&P Relief Valve
(factory supplied)
Boiler Outlet
Boiler Inlet
Gaskets
(factory supplied)
60 PSI Pressure Gauge
(factory supplied)
Primary Loop
(factory supplied)
