- Page 1 Vertrieb von CAMBOARD Electronics 1x8 HDTV DA U S E R M A N U A L www.gefen.com www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
- Page 2 Notice Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. The 1:8 HDTV Distribution Amplifi er is a trademark of Gefen Inc.
- Page 3 im Vertrieb von CAMBOARD Electronics TABLE OF CONTENTS Introduction Operation Notes Front Panel Descriptions Back Panel Descriptions Specifi cations Warranty www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
-
Page 4: Introduction
HDTV displays. How it works: Gefen’s ex•tend•it 1:8 HDTV distribution amplifi er sends the same DVI graphics source to eight DVI based digital screens (fl at panels or projectors). It is a fl exible solution that accommodates multiple DVI displays. -
Page 5: Operation Notes
im Vertrieb von CAMBOARD Electronics OPERATION NOTES READ THESE NOTES BEFORE INSTALLING OR OPERATING THE 1:8 HDTV DISTRIBUTION AMPLIFIER SYSTEM • All the monitors connected to the 1:8 HDTV Distribution Amplifi er must be able to run at the same native resolution. The 1:8 HDTV Distribution Amplifi er does not scale the video. •... -
Page 6: Front Panel Descriptions
im Vertrieb von CAMBOARD Electronics 1:8 HDTV DISTRIBUTION DA FRONT PANEL DESCRIPTION Front Panel Function Description DVI OUT - DVI outputs 1-8 Power Light - Indicates when power is on. www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203... -
Page 7: Back Panel Descriptions
im Vertrieb von CAMBOARD Electronics 1:8 HDTV DISTRIBUTION AMPLIFIER BACK PANEL DESCRIPTION Back Panel Function Description DVI IN 1 - DVI source 24 VDC - 4 pin din power 24 VDC connector www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203... - Page 8 im Vertrieb von CAMBOARD Electronics SPECIFICATIONS Video Amplifi er Bandwidth ................. 1.65 GHz Single Link Range ..................1920 x 1200 Vertical Frequency Range ..................60 Hz DVI Input/Output Connector Type ................DVI-I Power Consumption ................60 Watts (max.) Power Supply ......................24VDC Dimensions .................
-
Page 9: Specifi Cations
Gefen Inc. warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen Inc. is notifi ed within two (2) year from the date of shipment, Gefen Inc. will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi...
