BROADBAND-AT-SEA VSAT ANTENNA SYSTEM
Sea Tel, Inc.
4030 Nelson Avenue
Concord, CA 94520
Tel: (925) 798-7979
Fax: (925) 798-7986
Web:
http://www.cobham.com/seatel
Sea Tel Inc is also doing business as Cobham Antenna Systems
February 15, 2013

INSTALLATION MANUAL

FOR SEA TEL 4009-91MK3 KU-BAND
Sea Tel Europe
Unit 1, Orion Industrial Centre
Wide Lane, Swaythling
Southampton, UK S0 18 2HJ
Tel: 44 (0)23 80 671155
Fax: 44 (0)23 80 671166
Web:
http://www.cobham.com/seatel
Document. No. 138683 Revision A
