AIRSPRAY GUN
M22
TECHNICAL FEATURES
ORIGINAL MANUAL
IMPORTANT : before assembly and start-up, Please read and clearly understand all documents
.
relating to this equipment (professional use only)
PICTURES AND DRAWINGS ARE NON CONTRACTUAL. WE RESERVE THE RIGHT TO MAKE CHANGES WITHOUT PRIOR
NOTICE.
KREMLIN - REXSON
l
150, avenue de Stalingrad
93 245 - STAINS CEDEX – France
: 33 (0)1 49 40 25 25
Fax : 33 (0)1 48 26 07 16
www.kremlin-rexson.com
KREMLIN REXSON
N° : 578.005.120-UK-0910
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Kremlin-Rexson M22
Summary of Contents for Kremlin-Rexson M22
-
Page 1: Technical Features
PICTURES AND DRAWINGS ARE NON CONTRACTUAL. WE RESERVE THE RIGHT TO MAKE CHANGES WITHOUT PRIOR NOTICE. KREMLIN - REXSON 150, avenue de Stalingrad 93 245 - STAINS CEDEX – France : 33 (0)1 49 40 25 25 Fax : 33 (0)1 48 26 07 16 www.kremlin-rexson.com KREMLIN REXSON N° : 578.005.120-UK-0910... - Page 2 1. M 22 BASIK 1.1. Description Robust, multi-purpose gun for intensive works. There are 3 versions of the M22 BasiK gun : gravity, suction and pressure. 1.2. Technical features M 22 G BasiK M 22 A BasiK M 22 P BasiK...
- Page 3 PRESSURE AND AIR CONSUMPTION OF THE GUNS Adjustment of the air pressure with or without gauge at the gun handle Diagram : P 0 : Wall air (P0) pressure Air hose P 1 : Pressure measured at the gun handle when operating(the air (P1) needles are...
- Page 4 Pressure gun : M 22 P Basik with 9 BA 3 projector Air pressure (P1) Air flow rate Paint flow rate (1) Fan width (1) m3/h g/mn oz/mn " 43.5 16.7 12.2 Paint viscosity : 20 s CA n° 4 ( = 40 centipoises) Gun aircap distance - surface to be painted : 20 cm / 8"...
- Page 5 Note : For HVLP compliance, the maximum inlet air pressure at the gun handle must not exceed 29 psi (2 bar) to maintain 10 psi (0,68 bar) or less at the air cap. Testing for HVLP compliance was performed using the specified HVLP test air cap, the fan control fully open and a pressure gauge on the air inlet fitting at the gun handle.
- Page 6 HTi gun + E 3 K HVLP aircap + hose ∅ 8 mm HPA gun + EN 3 aircap + hose ∅ 7 mm (7.5 m / 24.6 ft length) (7.5 m / 24.6 ft length) (bar) (psi) (bar) (psi) (bar) (psi) (bar)
- Page 7 HPA suction version with projector, model 15 EN 2 Air pressure (P 1) Air flow rate Fluid flow (2) Fan width (3) m3/h g/mn oz/mn " 21.75 19,5 19,5 11.5 13.5 24,5 43.5 26,4 15.5 27,5 10.8 29,7 17.5 28,5 11.2 Fluid viscosity : 20 s CA n°...
- Page 8 3. M 22 HTI – HPA (G) 3.1. Description Guns recommended to spray varnishes, lacquers, shades, polyurethanes, two components... The HTI guns are pneumatic guns with a high transfer efficiency. Two projectors, models EP 5 and E 5 K HVLP can be fitted on the same gun. The guns, model HPA, with high spraying quality, enable to spray any kind of materials (low or high viscosity).
- Page 9 AIR AND FLUID SUPPLY M 22 guns, Elements mounted on the spray Air and fluid supply model HTi & HPA gun (depending on model) Air hose (non-static hose) HTi : minimum 8 mm int. ID (for a 7.5 m / 24.6 ft Fitting : M 1/4 NPS length) (+ MM 1/4 BSP not mounted)
- Page 10 + E 5 (K HVLP) aircap + EP 5 aircap + EN 5 aircap Air flow rate (m3/h) (CFM) (m3/h) (CFM) (m3/h) (CFM) Air pressure (P 1) 1,5 bar / 21.75 psi 21,5 12.7 2 bar / 29 psi 27,2 22,8 13.4 2,5 bar / 36 psi...
- Page 11 Pressure : by means of a fluid hose fitting on the pressure drum or the low pressure pump to the gun (maximum fluid pressure : 6 bar / 87 psi ). Air supply : By means of a grounded air hose connecting the gun to the air regulator (clean air - maximum pressure : 6 bar / 87 psi).
- Page 12 Nota : In some particular cases, if the air hose (4) is not conductive, the fluid hose (3) must be conductive. One of the 2 gun hoses (air or fluid) must be conductive. KREMLIN REXSON N° : 578.001.120-UK-0910...
