Table of Contents

SPECIFICATIONS
AIRMIX  GUN
MODEL MX 120 LT
Manual : 0510 573.044.212
Date : 21/10/05
Supersede : 15/09/03
Modif. : + note (page 1)
ADDITIONAL DOCUMENTATIONS
SPARE PARTS :
GUN, MX 120 LT
(Doc. 573.309.050)
KREMLIN REXSON – Site de Stains : 150, avenue de Stalingrad
93 245 - STAINS CEDEX - FRANCE
Téléphone : 33 (0)1 49 40 25 25
Fax : 33 (0)1 48 26 07 16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AIRMIX MX 120 LT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kremlin-Rexson AIRMIX MX 120 LT

Summary of Contents for Kremlin-Rexson AIRMIX MX 120 LT

  • Page 1 SPECIFICATIONS AIRMIX  GUN MODEL MX 120 LT Manual : 0510 573.044.212 Date : 21/10/05 Supersede : 15/09/03 Modif. : + note (page 1) ADDITIONAL DOCUMENTATIONS SPARE PARTS : GUN, MX 120 LT (Doc. 573.309.050) KREMLIN REXSON – Site de Stains : 150, avenue de Stalingrad 93 245 - STAINS CEDEX - FRANCE Téléphone : 33 (0)1 49 40 25 25 Fax : 33 (0)1 48 26 07 16...
  • Page 2 SPECIFICATIONS AIRMIX  MANUAL GUN - MODEL MX 120 LT TECHNICAL FEATURES TECHNICAL FEATURES GUN MX 120 LT OPTIONAL Air supply pressure 6 bar / 87 psi max. Fluid supply pressure ⇒ 90 bar / 1305 psi (refer to § 3) 120 bar / 1740 max.
  • Page 3 2. DISASSEMBLY SEAT-HOLDER (15) Remove air cap. With the wrench (52) supplied with the gun, unscrew seat-holder (16). Clean inside of the gun. If required, replace seat- holder (refer to spare parts, ind. 15). Unscrew seat retainer (18) from the seat assembly to reveal the seat (17).
  • Page 4 FILTER REPLACEMENT (37) Unscrew knurled nut (40) located at the gun material inlet. Clean the filter, and by hand, unscrew the filter support (38). Remove the microfilter (37), change it (refer to chart). Reassemble in reverse order. Before reassemblying the different components, some precautions have to be taken : Clean all the parts with the appropriate cleaning solvent and a brush.
  • Page 5 4. ASSEMBLY INSTRUCTIONS Index Instructions Description Part number "TECHNILUB" grease PTFE grease 560.440.101 (10 ml) Low strength - Aneorobic Glue bottle (50 ml) 554.180.010 Adhesive - Loctite 222 Screwing torque : 9 - 11 Nm / 6.6 - 8.1 ft / lbf Screwing torque : 24 Nm / 17.7 ft / lbf KREMLIN Page 4...
