- Page 1 USER INSTRUCTIONS DKP-8, DKP-12 AND KP-12 KEYPANELS PUSH-BUTTON AND LEVER KEY VERSIONS (Push-button versions shown) ™ 9350-7497-001 V27, Rev E, 8/01...
- Page 2 This warranty is the sole and exclusive express warranty given inches of excelsior or similar shock-absorbing material. All with respect to RTS products. It is the responsibility of the user shipments must be sent to the following address and must in- to determine before purchase that this product is suitable for the clude the Return Authorization.
- Page 3 License based upon the Software, regardless of the form of action, shall not exceed the greater of the license fee for the Software or $50. 38109-709 Rev A 10/97 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys 3...
- Page 4 4 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys...
-
Page 5: Table Of Contents
READ ME FIRST · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · MENU LIST FOR DKP-8, DKP-12, and KP-12 PUSH-BUTTON KEYPANELS · · · · · · · · · · · · · · · · ·... - Page 6 GENERAL DESCRIPTION......... 6 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys...
- Page 7 INDEX ............User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys 7...
-
Page 8: Read Me First
(click) the control to select that item. For many items, brief instructions are given as you navigate. From any level in the menus, you can double- click the SELECT control to exit to the next higher level. 8 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys... -
Page 9: Menu List For Dkp-8, Dkp-12, And Kp-12 Push-Button Keypanels
TONE (pg 47) ..Activates an internal tone generator. Used to test the talk and listen paths. USM (pg 47) ..Activates hot mic to matrix and/or MIC PRE OUT connector of optional Rear Connector Module. User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys 9... - Page 10 Although the DKP-8 has an Expansion Connector for connection of Expansion Panels and Level Control Panels, this feature is generally not used, since the DKP-8 is a desktop unit, while Expansion Panels and Level Control Panels are designed for rack mounting.
- Page 11 Although the DKP-12 has an Expansion Connector for connection of Expansion Panels and Level Control Panels, this feature is generally not used, since the DKP-12 is a desktop unit, while Expansion Panels and Level Control Panels are designed for rack mounting. User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys 11...
-
Page 12: Power-Up And Initial Settings
For intercom port numbers ending in 1 through 9, the keypanel address is the last digit of the port number. If the last digit of the port number is 0, use 10 as the address. 12 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys... -
Page 13: Determining The Address, Adam And Adam Cs Intercoms
To change the power-up preset configuration see “Headset / Speaker Se- lection and Volume Adjustment”, page 15. 3.3.4 CALL AND MENU INDICATORS At power-up, the CALL and MENU indicators should be off. User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys 13... -
Page 14: Basic Intercom Operation
Activate the key as described above to talk back. You can adjust the amount of time that displays will flash for incoming call indication. See “SERVICE MENU, TALLY”, page 46. 14 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys... -
Page 15: Headset / Speaker / Prgm Selection And Volume Adjustment
All new key assignments that you create are automatically uploaded to the intercom system and saved to the on-line configuration. User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys 15... -
Page 16: Telephone Operation (Kp-12 Only, Requires Optional Tif-951 Telephone Interface)
Tap the phone key. The talk and listen indicators will turn off and the call will terminate. 5.1.3 RECEIVING A PHONE CALL The phone key will flash red. Tap the key to answer the call. Hang up as previously described when finished. 16 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys... -
Page 17: Talk Mute During A Phone Conversation
To place a call on a redial or autodial key, simply tap the key. The number will automatically dial, and talk and listen will activate. Hang-up and mute are accomplished as previously described. User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys 17... -
Page 18: Using The Top-Level Menu
Whenever a new name is added to a full call list, the oldest name on the list is dropped. Thus, the call list can change over time. 18 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys... -
Page 19: Top Level Menu, Display
Double-click the SELECT control to return to the previous menu level. Or, press and hold the SE- LECT control for about two to clear the call waiting window if desired. User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys 19... -
Page 20: Top Level Menu, Display, Key Type
The call waiting window will also display TAP KEYS. If the keypanel does not have alphanumeric displays for intercom key assignments, tap any key and the listen assignment for that key will ap- 20 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys... -
Page 21: Top Level Menu, Display
When you click on KEY LIST, the list of all currently assigned keys on all 4 setup pages will be scrollable in the call waiting window. Rotate the SELECT control to locate a key assignment. User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys 21... -
Page 22: Top Level Menu, Level
If restrictions against key assignment have been imposed using the intercom system configuration software the intercom key may ignore the assignment. In this case, contact the intercom system administrator if you need to make a change. 22 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys... -
Page 23: Top Level Menu, Lists, Ifb
In this case, contact the intercom system administrator if you need to make a change. ISO key assignments are automatically uploaded to the intercom system and saved to the on-line configuration. User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys 23... -
Page 24: Top Level Menu, Lists, P-P (Point-To-Point)
Relay key assignments are automatically uploaded to the intercom system and saved to the on-line configuration. Changing a key’s assignment has no effect on any key options that may already be assigned to that key using the KEY OPT menu, page 36. 24 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys... -
Page 25: Top Level Menu, Lists, Spcl (Special Lists)
Starting with version 24, this has been changed so that key options now track not only the keys to which they are assigned, but also the setup page. For version information, see TOP LEVEL MENU, DISPLAY, VERSION, page 21. User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys 25... -
Page 26: Top Level Menu, Tgl Lisn (Toggle Listen On/Off)
You must run TGL LISN again to turn off a listen key after you have used TGL LISN to turn it on. To return to the top-level menu, double-click the SELECT control. If no action is taken for about 30 seconds, the call waiting window will clear. 26 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys... -
Page 27: Menu Mode
“KEY ASGN MENU, AUTODIAL”, page 28. To use stored autodial numbers with an all-purpose phone key see “Dialing an Autodial Number Using an All-Purpose Phone Key”, page 17. Store autodial numbers as follows: User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys 27... -
Page 28: Menus, Key Asgn
ICOM followed by the desired intercom system name, then click SELECT. Wait for the point-to-point list to be obtained from the selected intercom system. 28 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys... -
Page 29: Menus, Key Asgn, Autofunc
Double-click the SELECT control to return to TALK / LISTEN select. If you selected and cleared TALK assignments before, you can now select LISTEN and proceed to clear LISTEN User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys 29... -
Page 30: Menus, Key Asgn, Copy
TALK assignment will reappear in the display. If you select TALK, the new assignment will appear in the display above the key and the left LED in the key will flash for a few seconds. 30 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys... -
Page 31: Menus, Key Asgn, Lists
WAIT will display while the keypanel retrieves the scroll lists from that intercom system. Once the new set of scroll lists are available, you can use them to make key assignments as de- scribed in the following paragraphs: User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys 31... - Page 32 Rotate the SELECT control to select one of the available key activation methods (Table 3, page 31) then click SELECT. 3. The call waiting window will display TAP KEY. Tap an intercom key to assign the ISO. 32 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys...
- Page 33 If restrictions against key assignment have been imposed using the intercom system configuration software the intercom key may ignore the key assignment. In this case, contact the intercom system administrator if you need to make a change. User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys 33...
-
Page 34: Menus, Key Asgn, Local I/O (For Kp-12 Only)
Each local relay or open collector output can only be assigned to one key at a time. A relay or open collector output will only activate if the key it is assigned to also has a regular key assignment. 34 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys... -
Page 35: Menus, Key Asgn, Phone (For Kp-12 Only)
ICOM followed by the desired intercom system name, then click SELECT. Wait for the point-to-point list to be obtained from the selected intercom system. User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys 35... -
Page 36: Menus, Key Asgn, Redial (For Kp-12 Only)
ICOM followed by the desired intercom system name, then click SELECT. Wait for the point-to-point list to be obtained from the selected intercom system. 36 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys... -
Page 37: Menus, Key Opt, Btn Lock (Button Lock)
LECT control for about two seconds to exit menu mode. Remember to save your changes if you want them retained for future use. See “SERVICE MENU, SAVE CFG”, page 45. User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys 37... -
Page 38: Menus, Key Opt, Copy
KEYS. Tap keys as desired to enable or disable latching. The talk indicators will turn green for all keys that have latching enabled and will be off for keys that do not have latching enabled. 38 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys... -
Page 39: Menus, Key Opt, Solo
LECT control for about two seconds to exit menu mode. Remember to save your changes if you want them retained for future use. See “SERVICE MENU, SAVE CFG”, page 45. User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys 39... -
Page 40: Menus, Service, Hdst Mic
4-digit passcode is being cleared, then the keypanel will reset to the top level menu. You do not need to run SAVE CFG to store this change. 40 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys... -
Page 41: Menus, Service, Mod Asgn
MODS. MODS are simply groups of 4 consecutive intercom keys and their associated displays (or groups of 4 control knobs in the case of LCP’s). Since the DKP-8 and DKP-12 keypanels are typi- cally used without expansion panels and level control panels, only a few MODS are used. If you need to assign MODS on a DKP keypanel, simply refer to the “Procedure to Assign MODS”... - Page 42 MODs. Or, press and hold the SELECT control for about two seconds to exit menu mode. MOD changes are saved automatically. You do not need to run SAVE CFG. 42 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys...
- Page 43 Setup Page 3 Keys 33-36 MOD9 Keys 37-40 MOD10 Keys 41-44 MOD11 Keys 45-48 MOD12 Setup Page 4 Keys 49-52 MOD13 Keys 53-56 MOD14 Keys 57-60 MOD15 Keys 61-64 MOD16 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys 43...
-
Page 44: Menus, Service, Mute Lvl
If the opto-isolator is assigned to a setup page, the setup page number and the panel to which it is assigned will appear in the call waiting window. 44 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys... -
Page 45: Menus, Service, Reset
When you click on SAVE CFG, all alphanumeric displays will briefly display asterisks while the new configuration is being stored, then the keypanel will return to normal operation. The keypanel should now power up with the new configuration. User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys 45... -
Page 46: 7.5.11 Menus, Service, Set Addr
Double-click the SELECT control to return to the previous menu level. Or, press and hold the SELECT control for about two seconds to exit menu mode. 46 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys... -
Page 47: 7.5.14 Menus, Service, Test Pnl
Rotate the SELECT control to select either ON or OFF, then click again. Double-click the SELECT control to return to the previous menu level. Or, press and hold the SE- LECT control for about two seconds to exit menu mode. User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys 47... - Page 48 Table 7. Correspondence between ADDR numbers and intercom port numbers for ADAM and ADAM CS Intercom Systems Settings for Intercom Port Numbers ADDR 1000...
-
Page 49: Index
Factory Service Information BTN LOCK (Button Lock) Green indication CALL Indicator Flashing green talk indicator Indication at power-up For intercom keys Red flashing call indication GROUP Assigning groups to keys User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys 49... - Page 50 Message at power-up Selecting lever or pushbutton intercom keys Party Line Keys Assigning a party line to a key 32 Indications for talk/listen keys Momentary vs latching operation See Party Line 50 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys...
- Page 51 Assigning a relay to a key RESET TALLY Return Authorization Information Telephone Assigning a general purpose phone key See Relays Assigning a redial phone key Assigning autodial numbers to keys Basic operation User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys 51...
- Page 52 Storing autodial numbers TEST PNL TIF-951 See Telephone TONE UNLOCK USM (Unswitched Microphone) Warranty Information 52 User Manual, DKP-8, DKP-12 and KP-12 Keypanels with Push-button Keys...
