Erbauer ERB30Y Manual

Erbauer ERB30Y Manual

6kg sds plus rotary hammer drill
Hide thumbs
Table of Contents

Advertisement

Quick Links

WARRANTY
YEARS
ERB30Y
6kg SDS Plus Rotary Hammer Drill

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ERB30Y and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Erbauer ERB30Y

Summary of Contents for Erbauer ERB30Y

  • Page 1 WARRANTY YEARS ERB30Y 6kg SDS Plus Rotary Hammer Drill...
  • Page 2 Congratulations on your purchase of a quality power tool from Screwfix Direct Ltd. This product should give you reliable service but for your peace of mind this power tool does carry a 24-month guarantee, the terms of which are detailed below. If this product develops a fault within the guarantee period contact Screwfix Direct Ltd on Freephone 0500 41 41 41.

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS WARNING! Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. SAVETHESE INSTRUCTIONS 1. Work area a. Keep work area clean and well lit.Cluttered and dark areas invite accidents. b.
  • Page 4 before plugging in. Carrying power tools with your finger on the switch or plugging in power tools that have the switch on invites accidents. d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
  • Page 5 HEALTH ADVICE WARNING! When drilling, sanding, sawing or grinding, dust particles will be produced. In some instances, depending on the materials you are working with, this dust can be particularly harmful to you (e.g. lead from old gloss paint). You are advised to consider the risks associated with the materials you are working with and to reduce the risk of exposure.You should: - Work in a well-ventilated area.
  • Page 6 Double insulation: The tool is double insulated. This means that all the external metal parts are electrically insulated from the mains power supply.This is done by placing insulation barriers between the electrical and mechanical components making it unnecessary for the tool to be earthed. SYMBOLS Read the manual Warning...
  • Page 7 � � �� �� � � � � �� �� � � � �� 1. ON/OFF SWITCH 2. FUNCTION SELECTOR 3. MODE SELECTOR 4. AUXILIARY HANDLE 5. FASTENING SLEEVE 6. MAINS POWER CABLE 7. SPANNER 8. SDS DRILL BITS (8, 10, 12MM) 9.

  • Page 8: Technical Data

    10. 13MM KEY CHUCK AND ADAPTER 11. 250MM SDS CHISEL BIT (20MM FLAT HEAD, POINTED HEAD) 12. DEPTH GAUGE 13. CHUCK KEY 14. DUST COVER TECHNICAL DATA Voltage: 230V~50Hz Wattage: 1020W No load speed: 800min Drilling capacity Steel: 13mm Concrete: 30mm Wood: 40mm...

  • Page 9: General Description

    GENERAL DESCRIPTION This ROTARY HAMMER DRILL can be used for drilling wood, metal and masonry. It is supplied with a keyed chuck for smaller drill bits. Contained in the case is a selection of larger SDS Plus masonry bits. These fit directly into the rotary hammer.
  • Page 10 chuck. See Fig 3. Note: The SDS tools or chuck will be gripped firmly by its shank and will not be able to be removed. See Fig 3. If the chuck/SDS tool is not located repeat the installation operation again. 4.
  • Page 11 “ “ to stop the hammer action (see Fig 9) 3You are now set up for drilling function. WARNING Only use 13mm key chuck for drilling function mode, never use to hammer action. 8. CHISEL FUNCTION Fig 9 1 Adjust the function selector to position “...

  • Page 12: Maintenance

    Always check there is sufficient grease in the ������ grease box before usage. Check every 5 hrs of usage. Open the grease box lid at the top of the drill using the pin spanner provided. Then top up the grease box (capacity 20gms max) using the grease provided with your tool.

  • Page 13: Environmental Protection

    or pipe work in the path of the bit. • Always operate your drill using both the handle and the front handle. • Never change the operating mode whilst the drill is running. • When using the product in the hammer only mode, or when chiseling masonry, make sure that you wear safety glasses and protective gloves.
  • Page 14 13 AMP FUSE BLUE N (NEUTRAL) BROWN L (LIVE) OUTER SLEEVE CABLE GRIP...

  • Page 15: Declaration Of Conformity

    BA 22 8RT Declare that the product 6kg SDS Plus Rotary Hammer Drill ERB30Y Complies with the essential health and safety requirements of the following directives: 89/336 EEC, 93/68 EEC - EMC Directive. 73/23 EEC, 93/68 EEC – Low Voltage Directive 98/37 EC –...
