Summary of Contents for Erbauer ERB1127
- Page 1 WARRANTY YEARS ERB1127 1080W Percussion Drill SFX-ERB1127-M-050510.indd 1 2005-5-10 16:36:23...
- Page 2 SFX-ERB1127-M-050510.indd 2 2005-5-10 16:36:24...
- Page 3 This guarantee does not affect your statutory rights.This guarantee is only valid in the UK. For further technical advice, spare parts or repair service (outside of guarantee) please contact the customer helpline number on 0845 607 6380 1080W Percussion Drill SFX-ERB1127-M-050510.indd 3 2005-5-10 16:36:24...
-
Page 4: Safety Instructions
Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. e. Do not overreach. Keep proper footing and balance at all times. This enables SFX-ERB1127-M-050510.indd 4 2005-5-10 16:36:25... - Page 5 - Work in a well-ventilated area. -Work with approved safety equipment, such as those dust masks that are specially designed to filter microscopic particles. 1080W Percussion Drill SFX-ERB1127-M-050510.indd 5 2005-5-10 16:36:25...
-
Page 6: Additional Safety Points For Your Drill
9. Ensure that if a side handle or stabilising handle is provided with the power tool then these are adjusted into a comfortable position and that both handles are used to securely grip the power tool when in use. SFX-ERB1127-M-050510.indd 6 2005-5-10 16:36:25... - Page 7 SYMBOLS Read the manual Wear gloves Warning Wear dust mask,eye & ear protection 1080W Percussion Drill SFX-ERB1127-M-050510.indd 7 2005-5-10 16:36:25...
- Page 8 1. ON/OFF SWITCH 2. SWITCH LOCK-ON BUTTON 3. FORWARD AND REVERSE ROTATION CONTROL 4. VARIABLE SPEED CONTROL 5. AUXILIARY HANDLE 6. ADJUSTABLE DEPTH STOP 7. HAMMER OR DRILLING CONTROL 8. GEAR CONTROL 9. CHUCK ADJUSTMENT SFX-ERB1127-M-050510.indd 8 2005-5-10 16:36:26...
-
Page 9: Technical Data
A weighted sound power 102dB (A) Wear ear protection when sound pressure is over 85dB (A) Typical weighted vibration 6.2m/s ACCESSORIES Assorted drill bits 5pcs (HSS - 5,6,8mm; Masonry -8,10mm) Auxiliary handle Depth stop 1080W Percussion Drill SFX-ERB1127-M-050510.indd 9 2005-5-10 16:36:27... - Page 10 Always use the auxiliary handle (See Fig 2). 6. ADJUSTABLE DEPTH STOP Fit the drill bit or driver bit into the chuck. Loosen the depth stop by rotating the handle clockwise. Slide the depth stop until the distance between SFX-ERB1127-M-050510.indd 10 2005-5-10 16:36:27...
-
Page 11: Working Hints For Your Drill
HSS drill bits in good condition. Always use a magnetic bit holder when using short screwdriver bits. Where possible use a pilot hole before drilling a large diameter hole. 1080W Percussion Drill SFX-ERB1127-M-050510.indd 11 2005-5-10 16:36:28... -
Page 12: Maintenance
The wire that is coloured brown must be connect- ed to the terminal that is marked with the letter L. A 13AMP (BS1363 or BS1363/A) plug must be used and a 13 AMP fuse must be fitted. SFX-ERB1127-M-050510.indd 12 2005-5-10 16:36:28... - Page 13 13 AMP FUSE BLUE N (NEUTRAL) BROWN L (LIVE) OUTER SLEEVE CABLE GRIP 1080W Percussion Drill SFX-ERB1127-M-050510.indd 13 2005-5-10 16:36:28...
- Page 14 SFX-ERB1127-M-050510.indd 14 2005-5-10 16:36:28...
- Page 15 98/37 EC. –Machinery Directive. Standards and technical specifications referred to: EN 60745-1:2003/+A1:2003 EN 60745-2-1:2003 EN 55014-1:2000/+A1:2001/+A2:2002 EN 55014-2:1997/+A1:2001 EN 61000-3-2:2000 EN 61000-3-3:1995/+A1:2001 Authorised Signatory Date: 03/15/05 Signature: Name: Peter Harries Screwfix Direct Ltd Quality Manager 2005 SFX-ERB1127-M-050510.indd 15 2005-5-10 16:36:28...
- Page 16 SFX-ERB1127-M-050510.indd 16 2005-5-10 16:36:28...
