Page 1: Hdmi Extender
HDMI over ONE CAT5E/CAT6 HDMI Extender CHE-1 Operation Manual C a b l e a n d C o n n e c t i v i t y C o m p a n y... - Page 2 Introduction The HDMI Extender over ONE CAT5E/CAT6 is a tool for extending your HDMI signal over long distances to a compatible display. Instead of using expensive HDMI cables, your existing CAT5E/CAT6 cables/sockets can be utilized to perform advanced functions like transferring Deep Color (12 bits/color) video and digital audio, with a bandwidth up to 225MHz.
- Page 3 Specification Frequency Bandwidth 2.25Gbps (single link) HDMI Transmitter Input/Output Ports 2 x HDMI Female port/1 x CAT5E/CAT6 HDMI Receiver Input/Output Ports 1 x HDMI Female port/1 x CAT5E/CAT6 Power Supply 5V/1A DC 2 Years Parts & Labor Warranty Dimensions (mm) 65(W) X 100 (D) X 25 (H) Chassis Material Aluminum...
- Page 4 Operation Controls and Functions 1. HDMI Extender Transmitter Front Panel 1) HDMI1:HDMI1 Input port. 2) SW: Switch the HDMI1 and HDMI2 input port. 3) HDMI2:HDMI2 Input port. Front Panel Rear Panel 1) Power: Plug the 5VDC power supply into the unit and connect the adaptor to AC wall outlet.
- Page 5 of the HDMI over single CAT5E/CAT6 receiver. 2. HDMI Extender Receiver Front Panel 1) HDMI Out: HDMI output port. 2) LED indicator: When the HDMI input signal is locked, Front Panel the indicator will be light. Rear Panel 1) Power: Plug the 5VDC power supply into the unit and connect the adaptor to AC wall outlet.
- Page 6 Connection and Installation Package Product SUM(PCS) Remark HDMI Extender Transmitter HDMI Extender Receiver 5V DC Power Supply adaptor Operation Manual English 55 Ruta Ct. South Hackensack, NJ 07606 Toll Free: 800 526-0242 Email: sales@comprehensivecable.com customerservice@comprehensivecable.com www.comprehensivecable.com...
