Bosch C 950 Installation Manual page 63

13.2.4 Group 4
Fig. 85 Components Diagram
Item Description
1 Gas valve
2 Pressure tapping
3 Washer
4 Pipe
6 Gas supply pipe
7 Gas valve washer
8 Gas filter
9 Gasket
10 Gas / Fan connector
Table 58
Greentherm
Item
Reference
11
8 707 021 019 0
12
8 703 404 219 0
13
8 700 203 041 0
14
8 718 221 063 0
Table 58
8 700 715 389 0
8 700 103 014 0
8 700 507 002 0
8 704 701 085 0
8 705 202 140 0
Interior components diagram and parts list | 63
Description
Washer
Regulation screw
O-ring
Screw
Reference
8 704 701 062 0
8 703 404 220 0
8 700 205 009 0
2 910 149 181 0
6 720 805 440 (2014/11)
