V101 SIP VoIP Telephony Adapter

V101 SIP VoIP Telephony Adapter
The V101 is a telephony adapter (TA) for »Voice over IP« applications (VoIP) based on SIP protocols. Once connected to the Internet the TA
can link two stations having IP addresses with each other through the Internet. The TA features two Ethernet LAN ports for hooking up a
DSL modem / router and a PC, as well as one port for an analog phone. Thanks to its integrated NAT/DHCP server the TA can be configured
through a Web browser. This feature makes it ideally suited for customers of ITSPs (Internet Telephony Service Providers) and SOHO users,
enabling them to use Internet telephony.
Each TA needs one IP address, one subnet mask and one Gateway / Router IP address for connecting to the Internet. This data is supplied to
you by your Internet Service Provider. In case your provider uses dynamic IP address allocation towards their customers, users of the TA
may activate the PPPoE or DHCP functions to have a dynamic IP address assigned automatically. The MAC hardware address (Media Ac-
cess Control of TA) can be found on the bottom side of the TA. Additional information can be found on page 9 and beyond, »Configuration
through the Web Browser«.

V101 SIP VoIP Telephony Adapter Features

The V101 TA offers the following features:
•
SIP v1 (RFC2543), v2 (RFC3261) with MD5 Authentication (RFC2069 and RFC 2617).
•
two RJ45 Ethernet ports and an RJ11 port for connection to analog terminal devices.
•
ITU-T G.711, G.723, G.726, G.729A/B, VAD and CNG for Voice Codec.
•
ITU-T G.165/168 Echo Compensation.
•
Three LED Indicators: POWER, PHONE, LAN.
•
Configuration supported through Web browser and keypad on phone set.
•
Integrated NAT/DHCP server.
•
PPPoE/DHCP Client for dynamic IP address allocation, plus NAT, DNS, and DDNS clients.
•
Supports STUN Server for NAT Traversal.
•
Hot Line Mode support.
•
Supports T.38 FAX via IP.
•
Interactive voice response system (IVR) reads out IP status of phone.
•
Remote firmware upgrade from HTTP or TFTP server through Web-enabled PC.
•
Direct IP/URL dialing without assistance through SIP proxy or subscriber number provisioning through SIP server.
•
Telephony Features: Volume Adjustment, Phone Book, Speed Dialing, Call Forwarding, Call Waiting, Call Hold and
Three-Party Conferencing, Redialing, and Flash.
•
Outband DTMF (RFC 2833) / Inband DTMF / Send DTMF SIP Info.

Compatibility

The V101 VoIP TA supports the following standards:
VoIP Protocol:
SIP Authentication:
Voice codec:
Echo Compensation:

Package Contents

•
V101 SIP VoIP Telephony Adapter.
•
Power Supply Block 230V AC /12 VDC, 1 A.
•
CD-ROM with User Manual.
•
Brief description of functions.
•
RJ 11 to TAE adapter.
Please check whether the packaging is damaged or whether parts are missing. If that is the case, please contact your dealer.
2
IETF RFC3261 and RFC 2543 for SIP.
IETF RFC2069 and RFC 2617 for MD5.
see page 22, as well as VAD (Voice Activity Detection) and CNG.
ITU-T G.165/168.
