General
The operating instructions describe the most important
functions and the regular maintenance required for F205P
and its ventilation equipment.
Front panel
Thermometer
A
40
20
0
Thermometer
A
The boiler temperature is indicated here. The value
depends on the cut-off temperature of the electric
heater element, the set value for the cut-off tem-
perature of the compressor and the quantity of hot
water drawn off.
Pressure gauge
B
The radiator circuit pressure is indicated here. The
gauge is
graduated from 0 – 4 bar. Normal pressure is 0.5 –
1.5 bar.
Indicators lamps
C
Upper lamp
Lit Compressor in operation.
Flashing Alarm for actuated pressure regula-
tors or indication of stand-by operation.
(Compressor blocked).
Unlit Compressor not in operation.
Middle lamp
Lit Defrosting in progress.
Flashing Air filter requires cleaning.
Lower lamp
Lit Electric heater element in operation.
Not lit Electric heater element not in operation.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they
do not play with the appliance. Rights to make any design or technical modifications are reserved. ©NIBE 2009.
F205P
TM
Pressure gauge
B
60 2
80
1 3
C bar
100
120
0 4
T G T G
( )
E
Hot water priority (hidden*)
OPERATING INSTRUCTIONS
NIBE F205P
TM
For detailed information, see Assembly and Operating
Instructions.
Warning lamps
C
Switch
D
0
Heat pump switched off completely
1 Fan in operation. The compressor and the circu-
lation pump are started up as required.
2 Fan in operation. The compressor, the electric
heater element and the circulation pump are
started up as required.
3
Stand-by mode. Fan in operation. Compressor
not in operation. The electric heater element
and the circulation pump are started up as re-
quired.
Hot water priority
E
Auto
Hot water priority permanently activated
(same function as "1")
1 Hot water priority permanently activated.
0 Hot water priority not activated.
Circulation pump
F
with 2 positions "Auto" - "1":
Auto The circulation pump is switched on and
off by the control system or the clock ther-
mostat.
1
Circulation pump in continuous operation.
*These functions are accessible after removing the upper front cover.
Switch
D
F
Circulation pump (hidden*)
