5

Disassembly and Reassembly

5-1 Order of Disassembly

Refer to "Disassembly Flowchart" in Fig. 5-1-1 for the order of
removing components. When reassembling components, use the
reverse order to removal unless otherwise specified.
Note:
When replacing components in the VK-S274R/S274ER/K274R/
K274ER, be sure to use only those shown in "Replacement Parts
List".
Reading Disassembly Flowchart:
After locating the target component in the flowchart, remove all
components of the target in sequence, following the arrows
(routes) from the top of flowchart.

5-2 Disassembly

Information:
Numbers in figures are step numbers in disassemble procedure, and letters in brackets [
the types of screw.
Chassis L and R (Fig. 5-2-1)
1) Remove four screws [A] and remove the chassis L.
2) Remove two screws [A] and remove the chassis R.
CHASSIS R
A
LENS
UNIT
CSR
CIRCUIT
1 [A]
BOARD
Fig. 5-2-1 Chassis L and R
Fig. 5-1-1 Disassembly Flowchart
B
PC
CIRCUIT
BOARD
SP
CIRCUIT
1 [A]
BOARD
B
A
2 [A]
CHASSIS L
5 - 1
Item
Component name
No.
Chassis R
1) and 2)
Chassis L
3) to 5)
PC Circuit Board
6) and 7)
CSR Circuit Board
SP Circuit Board
8) and 10)
Image Sensor
11)
Lens unit
] show
[A] M2×3 (Black)
