Technical data DHP-AX

Air to water heat pump
Refrigerant Type
Amount
Test pressure
Design pressure
Compressor Type
Oil
Electrical data Main supply
3-N~50Hz
Rated power compressor
Rated power, fan
Start current
Circuit breaker
Electrical data Main supply
1-N~50Hz
Rated power compressor
Rated power, fan
Start current
Circuit breaker
Performance 6 COP
COP
Heating capacity
Power input
Nominal flow Heating circuit
3
Lowest outdoor temperature allowed for compressor start
Max temperature 4 Heating circuit
Pressure switches Low pressure
Operating
High pressure
Water volume
Condensor
Number of units
Outdoor unit Dimensions LxWxH
Weight
Sound power level
Fan speed
Air flow
Control unit
Dimensions LxWxH
Weight
The measurements are performed on a limited number of heat pumps which can cause variations in
the results. Tolerances in the measuring methods can also cause variations.
At A7W35 Δ10K warm side.
1)
2) At A7W35 according to EN 14511.
Nominal flow: heating circuit Δ10K.
3)
At minimum outdoor temperature 0 C.
4) o
5) According to ISO 3741.
The values apply to a new heat pump with clean heat exchangers.
6)
DHP-AX
1
2
2
2
5
6 8
R407C R407C
kg 1,6 1,6
MPa 3,4 3,4
MPa 3,1 3,1
Scroll Scroll
POE POE
Volt 400 400
kW 2,0 2,3
kW 0,3 0,3
A 16 17
A 10 10
Volt 230 230
kW 3,3 4,2
kW 0,3 0,3
A 56 76
A 20 20
4,37 4,47
3,81 3,99
kW 6,20 7,93
kW 1,6 2,0
l/s 0,3 0,4
o C -16 -16
o C 60 60
MPa 0,03 0,03
MPa 2,85 2,85
MPa 3,10 3,10
l 1,3 2,2
2 2
mm 661x1167x1290 661x1167x1290
kg 108 113
dB(A) 67,7 67,8
rpm 890 890
m /h 3667 3667
3
210x380x600 210x380x600
mm
kg 18 18
VMBMH302
10 12
R407C R407C
2,5 2,7
3,4 3,4
3,1 3,1
Scroll Scroll
POE POE
400 400
3,6 4,4
0,3 0,3
22 22
16 16
230 230
5,4 5,7
0,3 0,3
97 108
25 32
4,47 4,26
4,05 3,81
10,2 11,2
2,5 2,9
0,5 0,5
-16 -16
60 60
0,03 0,03
2,85 2,85
3,10 3,10
2,7 2,7
2 2
661x1167x1290 661x1167x1290
123 140
68,1 70,4
890 940
3667 4045
210x380x600 210x380x600
18 18
Service – 9
