About the instructions

1.1

Introduction

These instructions are split into two parts: installation
instructions and service instructions.
The installation instructions start by describing DHP-AX
data. The installation instructions later give instructions in
a logical order covering unpacking, installation procedure,
and checking the installation.
The service instructions contain information about the
heat pump's function and control. The service instructions
also contain a complete menu description and covers
troubleshooting in-depth.
The first two sections, 1 About the instructions and 2 Safety
precautions are general sections and apply to all the
instructions, i.e. the installation instructions and service
instructions.
References to chapters and sections within the instruc-
tions are in italics, e.g.: 1 About the instructions.
References to menu options in the heat pump's control
system are in upper case, e.g.: INFORMATION -> OPERAT.
-> AUTO.
All figures in the instructions are numbered to help install-
ers and service technicians refer to them easily.
1.2

Symbols

The instructions contain different warning symbols, which,
together with text, indicate to the user that there are risks
involved with actions to be taken.
The symbols are displayed to the left of the text and three
different symbols are used to indicate the degree of dan-
ger:
BB B B
Hazardous electrical voltage! Indicates an
immediate danger that leads to fatal or serious
injury if necessary measures are not taken.
A B BB
Danger! Risk of personal injury! Indicates a
possible danger that can lead to fatal or seri-
ous injury if necessary measures are not taken.
D B BB
Risk of installation damage. Indicates a possible
hazard that can lead to item damage if necessary
measures are not taken.
A fourth symbol is used to give practical information or
tips on how to perform a procedure.
BB E B
I nformation regarding making the handling of
the installation easier or a possible operational
technical disadvantage.
4 – Installation
1.3

Terminology

The instructions contain terms throughout that designate
components and functions. The table lists the most com-
mon terms that are used in the instructions.
Term
Heating system
Supply line
Return line
Circulation pump
Refrigerant circuit
Refrigerant
2

Safety precautions

2.1

General safety precautions

D B BB
The heat pump must be installed by authorised
installation engineers and the installation must
follow the applicable local rules and regulations
as well as these installation instructions.
D B BB
This apparatus is not intended for persons
(including children) with reduced physical, sen-
sory or psychological capacity, or who do not
have knowledge or experience, unless super-
vised or they have received instructions on how
the apparatus functions from a safety qualified
person.
A B BB
Danger! Risk of personal injury! Children are
not permitted to play with the apparatus.
D B BB
The heat pump must be positioned outdoors
on a stable base. The floor must be able to sup-
port the gross weight of the heat pump. (see
Technical Specification)
D B BB
To prevent leaks ensure that there are no stress-
es in the connecting lines!
D B BB
It is important that the heating system is bled
after installation.
VMBMH302
Meaning
The circuit that generates heat to the
property or to the water heater.
The heating system's supply line with
flow direction from the heat pump to
radiators/under floor heating or water
heater.
The heating system's return line with
flow direction from radiators/under
floor heating or water heater to the
heat pump.
Circulation pump for heating system.
The energy carrying circuit between
outdoor air and heating system.
The gas/liquid that circulates in the
refrigerant circuit.
