56
Physical Configuration
Dimensions (w × h × d):
Weight:
Operating voltage:
Nominal power needs:
Maximum power needs:
Replacement fuses:
Operating temperature range:
ADInstruments reserves the right to alter these specifications at any time.
300 mm × 60 mm × 300 mm
(11.8" × 2.4" × 11.8")
5 kg (10 lb 10 oz)
220–240 V or 110–120 V (internally set)
25 VA (no front-ends attached)
35 VA (full complement of front-ends)
100–120 V: 1 Amp (5 × 20 mm) slow blow
(voltage rating 120 or 250 V)
220–240 V: 400 mA (5 × 20 mm) slow blow
(voltage rating 250 V only)
0 to 35 °C, 0 to 90% humidity (non-
condensing)
PowerLab Owner's Guide
