Table Of Contents - ADInstruments PowerLab/4SP Owner's Manual

Contents
iii
Safety Notes
v
1 Overview
1
How to Use this Guide 2
First, Check Your PowerLab! 2
The PowerLab System 3
Computer Requirements 3
The Application Programs 4
ADInstruments Front-Ends 5
The PowerLab 5
The Front Panel 5
The Back Panel 9
2 Setting Up
15
Self-Test 16
The USB Connection 17
Connecting the PowerLab Using USB 18
USB Connection Rules 19
The SCSI Connection 20
SCSI Connection Rules 20
Setting the SCSI ID Number 22
SCSI Termination Rules 23
Connecting the PowerLab: Macintosh 23
Connecting the PowerLab: Windows 24
SCSI Strikes Back 26
PowerLab Owner's Guide
Contents
A Technical Aspects
How Does it Work? 27
The Analog Inputs 31
PowerLab Accuracy 33
The External Trigger 33
The Analog Output 34
Connections 35
USB Port 35
SCSI Port 35
2
I C Expansion Port 36
Digital Input and Output Ports 37
Pod Connectors 37
B Troubleshooting
Problems: Macintosh 39
Problems: Windows 42
C Specifications
PowerLab/4sp Specifications 47
PowerLab/8sp Specifications 50
PowerLab/16sp Specifications 53
Glossary
57
Index
61
Licensing & Warranty Agreement
27
39
47
63
iii
