Appendix C — Specifications
Low-pass filtering:
AC coupling:
Frequency response (–3 dB):
DC drift:
CMRR (differential):
Input crosstalk:
Input noise:
Sampling
ADC resolution:
Linearity error:
Maximum sampling rates:
Available sampling rates:
Output Amplifier
Number of outputs:
Output configuration:
Output resolution:
Maximum output current:
Output impedance:
Slew rate:
Settling time:
Linearity error:
1, 2, 5, 10, or 20 kHz (software-selectable)
DC or 0.1 Hz (software-selectable)
20 kHz @ ±10 V full scale, all gain ranges
Software-corrected
96 dB @ 50 Hz (typical)
–110 dB typical
< 1 µV
referred to input
rms
16 bits (150 µV resolution at 10 V range)
±1 LSB (from 0 °C to 70 °C)
200 kHz on one channel;
100 kHz on two channels;
40 kHz on three or four channels;
20 kHz on five to eight channels.
200 kHz down to 0.003 Hz using Chart
200 kHz down to 2 Hz using Scope
200 kHz to 1 Hz using Chart for Windows
Sampling on USB rather than SCSI may
limit the maximum sampling rates.
2
Single-ended or differential
14 bits (0.6 mV resolution at 10 V range)
±25 mA
0.1 Ω typical
10 V/µs
2 µs (to 0.01% of FSR for LSB change)
±1 LSB (from 0 °C to 70 °C)
51
