Appendix C — Specifications
Physical Configuration
Dimensions (w × h × d):
Weight:
Operating voltage:
Nominal power needs:
Maximum power needs:
Replacement fuses:
Operating temperature range:
PowerLab/16
Input
Number of inputs:
Input configuration:
Amplification ranges:
Maximum input voltage:
Input impedance:
300 mm × 60 mm × 300 mm
(11.8" × 2.4" × 11.8")
4.8 kg (10 lb 8 oz)
220–240 V or 110–120 V (internally set)
17 VA (no front-ends attached)
30 VA (full complement of front-ends)
100–120 V: 1 Amp (5 × 20 mm) slow blow
(voltage rating 120 or 250 V)
220–240 V: 400 mA (5 × 20 mm) slow blow
(voltage rating 250 V only)
0 to 35 °C, 0 to 90% humidity (non-
condensing)
Specifications
SP
16
Single-ended
±2 mV to ±10 V full scale in 12 steps
± 10 V
± 5 V
± 2 V
± 1 V
± 0.5 V
± 0.2 V
± 0.1 V
± 50 mV
± 20 mV
± 10 mV
± 5 mV
± 2 mV
±15 volts
≈ 1 MΩ || 47 pF @ DC
