ADInstruments PowerLab C Series Owner's Manual

Front end interface and instrument interface
Hide thumbs
Table of Contents

Advertisement

Quick Links

RESEARCH PRODUCTS
Front End Interface and Instrument Interface
Owner's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PowerLab C Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ADInstruments PowerLab C Series

Summary of Contents for ADInstruments PowerLab C Series

  • Page 1 RESEARCH PRODUCTS Front End Interface and Instrument Interface Owner’s Guide...
  • Page 2 This document is, as far as possible, accurate at the time of release. However, changes may have been made to the soft ware and hardware it describes since then. ADInstruments NZ Limited reserves the right to alter specifications as required. Late-breaking information may be supplied separately.

  • Page 3: Table Of Contents

    Contents 1 Safety Notes Statement of Intended Use ..........1 Safety and Quality Standards .
  • Page 4 Using Multiple PowerLabs ..........16 Supplied Accessories .

  • Page 5: Safety Notes

    That is, no product supplied by ADInstruments is intended to be used to diagnose, treat or monitor a subject. Furthermore no product is intended for the prevention, curing or alleviation of disease, injury or handicap.
  • Page 6 Regulatory Symbols Devices manufactured by ADInstruments that are designed for direct connection to humans and animals are tested to IEC60601-1:1998 and IEC60601-1:2005 (including amendments 1 and 2) and EN61326-1:2006, and carry one or more of the safety symbols below. Warning symbol. The exclamation mark inside a triangle means that the supplied documentation must be consulted for operating, cautionary or safety information before using the device.

  • Page 7: General Safety Instructions

    • The entry of liquids into equipment may also compromise the isolation barrier. If spillage occurs, ADInstruments should be contacted before using the equipment. • The PowerLab depends on the presence of a Protective Earth for it’s electrical safety requirement.

  • Page 8: Cleaning And Sterilization

    • They shall only be used for supplying power to equipment which is intended to form part of the system. Cleaning and Sterilization ADInstruments products may be wiped down with a lint free cloth moistened with industrial methylated spirit. Inspection and Maintenance PowerLab systems and ADInstruments front-ends are all maintenance-free and do not require periodic calibration or adjustment to ensure safe operation.

  • Page 9: Environment

    • Unwanted equipment bearing the Waste Electrical and Electronic Equipment (WEEE) Directive symbol requires separate waste collection. For a product labeled with this symbol, either forward to a recycling center or contact your nearest ADInstruments representative for methods of disposal at the end of its WEEE Directive working life.

  • Page 10: Overview

    Chapter 2 Overview The PowerLab C and C Series devices are ADInstruments’ range of modern, high quality, research grade laboratory data acquisition hardware. They work seamlessly with LabChart 8 and LabChart Lightning to provide a reliable foundation on which to integrate a variety of input and output devices suitable for a range of life science applications.

  • Page 11: How To Use This Guide

    At the end of this guide is a glossary of hardware terms. Soft ware Installation The ADInstruments application soft ware should be installed before connecting or using a PowerLab C or any C Series device. The Getting Started with PowerLab manual provides full installation instructions for the LabChart soft ware.

  • Page 12: Power-On Self Diagnostics

    2. The PowerLab will also give a Red status LED if the test detects a hardware fault. The devices contain no user-serviceable parts inside. If a hardware fault is reported by a PowerLab C or any C Series device, an ADInstruments representative should be contacted.

  • Page 13: Setting Up

    Chapter 3 Setting Up This chapter describes: • Connecting the Hardware. • Installing the soft ware Figure 3-1 C Series devices connected Owner’s Guide...

  • Page 14: Connecting The Hardware

    Connecting the Hardware The PowerLab C and C Series devices use USB-C to communicate with either a host computer, or a PowerLab C. With a PowerLab C The PowerLab C should be connected to the host computer using either the included USB-C to USB-A cable, or the USB-C to USB-C cable depending on port availability.

  • Page 15: Without A Powerlab C

    Using USB cables supplied by ADInstruments is recommended. If using 3rd party cables with the PowerLab C or any C Series devices it is critical that cables used to connect between them meet the following requirements: •...

  • Page 16: Powerlab C

    Chapter 4 PowerLab C The unit, together with a range of specialized application programs, provides a versatile data recording and analysis system when used with a Windows or Macintosh computer. This chapter provides an overview of the PowerLab® system and describes the basic features, connectors and indicators of the PowerLab.

  • Page 17: The Powerlab C

    The PowerLab C The PowerLab C provides 4 downstream-facing USB-C (with Power Delivery) ports for connection to equipment with a USB-C interface (such as the Front-End Interface) and provides 2 upstream-facing ports for connection to a computer supporting USB-C with Power Delivery.

  • Page 18: The Rear Panel

    Downstream facing USB Ports The downstream facing ports are primarily intended for connection to any ADInstruments C Series device. These devices should be connected using an ADInstruments supplied USB-C to USB-C Cable. If using a third party cable it must support both alternate mode and be capable of 100W USB-PD.

  • Page 19: Checking And Replacing Fuses

    For further assistance please contact your nearest ADInstruments representative. Note: Fuse replacement should only be attempted by appropriately qualified service personnel. If the fuse is suspected as blown, please contact ADI service representative or appropriately qualified service personnel.

  • Page 20: Using Multiple Powerlabs

    Using Multiple PowerLabs Multiple PowerLab C units can be connected in one of two ways: 1. Daisy Chained: The ‘Computer’ port of the second PowerLab C is connected to one of the downstream facing ports on the first PowerLab C. This allows the second PowerLab to be powered by the first, allows full use of the PowerLab Figure 4–5 Event Link (PEL) between devices but comes at the cost of using one of the...

  • Page 21: Supplied Accessories

    Figure 4–6 PowerLabs con- nected to host computer Supplied Accessories Accessory MLAC89/2 USB-C to USB-C cable (1m) MLAC89/3 USB-C to USB-A cable (1m) Owner’s Guide...

  • Page 22: Front End Interface

    Front End Interface The Front End Interface allows existing ADInstruments Front Ends with I2C and BNC connectors to be connected to the PowerLab C. The Front End Interface provides analog-to-digital conversion, USB-C/PD interface for connection to the PowerLab C and FE device detection.

  • Page 23: The Front End Interface

    The front of the Front End Interface (Figure 5–2) provides an I2C port for connection to The Front End any ADInstruments Front End. The product is designed to connect directly to the rear of Interface does not all current Front Ends. It can also be connected via the MLAC02 DB9M -DB9F Cable (sold support daisy separately) if required.

  • Page 24: The Rear View

    Interface does not matrix below for details. support daisy • Guide Screws for securely attaching to the rear of a supported ADInstruments chaining Front Ends. Front End. These screws should be done up finger tight only. Note these screws The ‘I2C Output’...

  • Page 25: Analog Cable

    Analog Cable There are 4 variants of the analog cable assembly. • MLAC871 1 Channel Analog Cable • MLAC872 2 Channel Analog Cable • MLAC874 4 Channel Analog Cable • MLAC878 8 Channel Analog Cable When using a multi channel analog cable the connection order does not matter except when using a device with a stimulator output.

  • Page 26: Connecting A Front-End Into A System

    Interface using an analog cable, the Interface can be powered by directly connecting it to a computer. In this case, an ADInstruments supplied USB-C to USB-C cable must be used to connect the Interface to a USB-C port on the...

  • Page 27: Supplied Accessories

    computer. Please note that the USB port must be capable of delivering a minimum of 15W of power. Figure 5–7 Connecting a Front End directly to a computer Computer Supplied Accessories Accessory MLAC89/1 USB-C to USB-C cable (300mm) MLAC871 Analog Cable (1 Channel) MLAC872 Analog Cable (2 Channels) MLAC874 Analog Cable (4 Channels) MLAC878 Analog Cable (8 Channels)

  • Page 28: Front End Compatibility Table

    Front End Compatibility Table Front End Supported Minimum Limitations Supported Cable without Requirement PowerLab C? Figure 5–8 Front End ‘35 Series’ Front-Ends Compatibility Table FE231 Bio Amp 1 Channel Y (=>7.5W Port) MLAC871 FE232 Dual Bio 2 Channel Y (=>7.5W Port) MLAC872 FE234 Quad Bio 4 Channel...
  • Page 29 Front End Supported Minimum Limitations Supported Cable without Requirement PowerLab C? IN125/X NIBP 2 Channel Trigger in/out not Y (=>7.5W Port) Controller supported MLAC872 IN175 STH 1 Channel Y (=>7.5W Port) Pump MLAC871 Controller FE132 Bio Amp 1 Channel Y (=>7.5W Port) MLAC871 FE135 Dual Bio 2 Channel...
  • Page 30 Front End Supported Minimum Limitations Supported Cable without Requirement PowerLab C? ML155 1 Channel Y (=>7.5W Port) Stimulator HC MLAC871 ML125/X NIBP 2 Channel Y (=>7.5W Port) Controller MLAC872 ML175 1 Channel Y (=>7.5W Port) STH Pump MLAC871 Controller ML132 Bio Amp 1 Channel Y (=>7.5W Port) MLAC871...
  • Page 31 Front End Supported Minimum Limitations Supported Cable without Requirement PowerLab C? ML160 Potentiostat ML162 PicoStat ML164 QuadStat ML130 Bio Amp ML133 Bio Amp (CF Rated) Owner’s Guide...

  • Page 32: Instrument Interface

    Chapter 6 Instrument Interface The Instrument Interface is a 4 channel device providing analog input capability to the PowerLab C. The device is powered and controlled by a single USB-C/PD cable connecting to the PowerLab C, or to a host computer. Connection to the PowerLab C provides adaptive mains filtering (when PowerLab C is powered from mains) and enables advanced synchronization features.

  • Page 33: The Instrument Interface

    The Instrument Interface This section describes the connectors and indicators of the Instrument Interface. The Front Panel The front panel (Figure 6–2) provides the connectors and indicators for various functions. • The 4x BNC Input Ports for connection to analog instruments using a BNC-BNC Cable.

  • Page 34: The Rear Panel

    The Rear Panel The rear panel of the Instrument Interface is shown below (Figure 6-3).It provides the USB-C Port for connection to the PowerLab C or computer. Figure 6–3 The rear panel of the Instrument Interface USB-C Port Connecting an Analog Instrument into a system An Analog Instrument can be connected using the Instrument Interface in the following ways: 1.

  • Page 35: Supplied Accessories

    Instrument Interface through the BNC sockets on the front panel, the Interface can be powered by directly connecting it to a computer. In this case, an ADInstruments supplied USB-C to USB-C cable or USB-C to USB-A cable can be used depending on port availability on the computer.
  • Page 36 Instrument Compatibility The Instrument Interface is designed to work with most 3rd party instruments that feature an analog output between -10V and +10V. Many instruments feature a BNC output port, some may require an adapter cable. Owner’s Guide...

  • Page 37: Technical Specifications

    Chapter 7 Technical Specifications This chapter describes some of the important technical aspects of the PowerLab C and C Series devices. You do not need to know the material here to use these products. It is likely to be of special interest to the technically minded, however it should not be used as a service manual: user modification of the PowerLab voids your rights under warranty.

  • Page 38: Specifications

    Do not use in the presence of flammable anaesthetic - air mixtures. Avoid operating near high voltage, RF or strong magnetic fields that may cause interference. Method of Disposal: Forward to recycling center or return to manufacturer. ADInstruments reserves the right to alter these specifications at any time. Owner’s Guide...
  • Page 39 PLC01 PowerLab C Physical Configuration Dimensions (h × w × d): 70 mm × 240 mm × 260 mm (2.8” × 9.4” × 10.2”) Weight: 2.9 kg (6 lb 6 oz) Operating Requirements Operating voltage range: 100–240 V AC, 50/60 Hz Rated Power: 400 VA Earth Leakage Current:...
  • Page 40 PLCF1 Front End Interface Analog Inputs Number of input channels: Configuration: Single-ended Amplification ranges: Range Resolution ± 10 V 313 µV ± 5 V 156 µV ± 2 V 62 µV ± 1 V 31 µV ± 500 mV 15 µV ±...
  • Page 41 Output impedance: 1 KΩ Output level: 4.5 V Physical Configuration Dimensions (h × w × d): 27.5 mm x 68 mm x 88 mm (1.1” x 2.7” x 3.5”) Weight: 0.1 kg (0 lb 4 oz) Operating Requirements Operating voltage range: 5 - 15 V Rated Power: 15 W...
  • Page 42 Frequency response: 24K Hz (all ranges) Crosstalk: >90 dB (unused channels 1K terminated) Low pass filters: Off , 20, 50, 100, 200, 500, 1000, 2000 Hz Sampling ADC sampling: Simulaneous across channels ADC resolution: 18-bits (16-bit eff ective) ADC linearity: ±4 LSB Available sampling rates: Upto 100 000 samples/s...

  • Page 43: Electromagnetic Compatibility

    Electromagnetic Compatibility The PowerLab C and C Series devices (the devices) have been tested to comply with IEC 60601-1-2:2014. The relevant basic EMC standards are IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11 and CISPR 11. Emissions • The devices are suitable for use in all establishments other than domestic and those directly connected to the public low-voltage power supply network that supplies buildings used for domestic purposes.
  • Page 44 Immunity test IEC 60601 test level Compliance level Electromagnetic environment guidance Conducted RF 3 Vrms Recommended separation IEC 61000-4-6 150 kHz to 80 MHz distance (see TableB–2 p. 50) Radiated RF 3 V/m 3 V/m Recommended separation IEC 61000-4-3 80 MHz to 2.7 GHz distance (see TableB–2 p.

  • Page 45: Glossary

    Glossary Adaptive mains filtering. An advanced signal processing technique that seeks to eliminate noise originating from mains power. ADC (analog-to-digital converter). A device that converts analog information into some corresponding digital voltage or current. amplitude. The maximum vertical distance of a periodic wave from the zero or mean position about which the wave oscillates.
  • Page 46 frequency response. The bandwidth in which a circuit passes a signal without too much attenuation. A low-pass filter’s frequency response is the frequency where the output voltage becomes 0.707 (1/√2) of the input voltage or has been attenuated by 3 decibels. If a low-pass filter has a frequency response of 200 Hz, say, then the signal is eff ectively unattenuated up to 150 Hz, and is 0.707 of the original value at 200 Hz.

  • Page 47: Warranty

    Warranty Product Purchase and License Agreement This Agreement is between ADInstruments NZ Ltd [‘ADI’] and the purchaser [‘the Purchaser’] of any ADI product or solution — software, hardware or both — and covers all obligations and liabilities on the part of ADI, the Purchaser, and other users of the product. The Purchaser (or any user) accepts the terms of this Agreement by using the product or solution.
  • Page 48 Hardware Warranty Limitations This warranty applies only to the ADI hardware specified in this document and used under normal operating conditions and within specification. Consumables, electrodes and accessories are not covered by this warranty. Third party equipment may be covered by the third party manufacturer’s warranty.
  • Page 49 ing out of sale, installation service or use of its products. EXCEPT FOR THE EXPRESS WARRANTY SET FORTH HEREIN, THE SOLUTION AS WELL AS ALL EQUIPMENT AND SOFTWARE PROVIDED HEREUNDER ARE PROVIDED “AS IS” AND ADI MAKES NO WARRANTY. AS TO ITS USE OR PERFORMANCE. EXCEPT FOR ANY WARRANTY, CONDITION, REPRESENTATION OR TERM THE EXTENT TO WHICH CANNOT BE EXCLUDED OR LIMITED BY APPLICABLE LAW, ADI AND ITS SUPPLIERS MAKE NO WARRANTY, CONDITION, REPRESENTATION, OR TERM (EXPRESS OR IMPLIED, WHETHER BY STATUTE, COMMON LAW, CUSTOM, USAGE OR...
  • Page 50 Copyright © ADInstruments NZ Ltd, 2021. All rights reserved. PowerLab, LabChart and ADInstruments are registered trademarks of ADInstruments NZL Ltd. Windows 8, Windows 7, Windows Vista and .NET Framework are trademarks of Microsoft Corporation. Apple, the Apple logo, MacOS, and Macintosh are trademarks of Apple Computer Inc.

This manual is also suitable for:

Powerlab c
