Parts List - Intelligent Weighing Technology QHD+3 Service Manual

Parts List

No Parts Name
1 Pan
2 Pan
3 Battery cover
4 Battery
5 Foam
6 Rear Overlay
7 Top Cover
8 Name Plate
9 Internal Allen Screw
10 Washer (M6)
11 Spring Washer(M6)
12 Load cell upper bracket
13 Load cell
14 Star (+) Screw
15 Load cell lower bracket
16 Self thread Screw
17 Insulative Washer
18 Power Socket
19 Power Socket Spacer
20 Power Switch
21 Foot
22 Key board
23 Front display overlay
24 Level bubble
25 Screw
26 Front Display PCBA
27 Insulative Washer
28 Star (+) Self thread screw
29 Star (+) Self thread screw
30 Hexagon Nut
31 Main PCBA
32 Screw for D connector
33 D type connector
34 Hexagon nut for D connector 4
35 Overlay
36 Bottom Cover
37 Self thread screw
- 34 -
Qty Material
1 SST
1 ABS
1 ABS
1 Lead Acid
1 CR
1
1 ABS
1
4
4 65Mn
4
1 Aluminum
1 Aluminum Alloy
4 20Mn
1 Aluminum
4 S18C
4 EDPM
1
1 PC
1
4 PVC
1
1
1
1
1
5 EDPM
5 20Mn
5 20Mn
4
1
4
2
1
1
5 20Mn
Spec
230mmx300mm
230mmx300mm
6V/4Ah
M6x16, 8.8
200-300HV
HRC42-50
M4x16
4x10
8x3.1x1.2t
14.7mm
M4x35
8x3.1x1.2t
M3x20
M4x20
Zn Coating
ABS
4x12
