1660 Barcode Scanner

1.2 MEMORY

The collected data can be sent back to a host computer one by one via the transmit
buffer (SRAM) or stored in flash memory when the scanner is set to Memory mode.

1.2.1 TRANSMIT BUFFER

The scanner is designed to send any collected data to a host computer one by one via
the transmit buffer (SRAM). Upon reading a barcode successfully, the scanner responds
with one short beep (high tone) and its LED indicator becomes solid green and goes off
quickly. However, the host computer may not receive the data immediately if getting out
of range. With the 1 KB transmit buffer, the scanner can ignore the transmission status
and keep on reading barcodes until the buffer is full. A warning is given when the
transmit buffer it full — the scanner will respond with one long beep (low tone) and its
LED indicator will become solid red and go off quickly.
You are advised to get back to range if using Bluetooth.
Note: The 1 KB transmit buffer on the scanner can hold as many as 64 scans based on
EAN-13 barcodes. Data will be cleared out once the scanner is turned off or
running out of battery power!

1.2.2 MEMORY MODE

The scanner keeps 128 KB flash memory for memory mode operation. When the 1660
scanner is in memory mode, it means Bluetooth connection is disabled.
Enable Memory Mode
Warning: Bluetooth cannot work unless memory mode is disabled.
14
User Guide
*Disable Memory Mode
Enter Setup
