4.3.14 Fuser Unit Disassembly

1. Remove the Paper Eject Sensor (PS3). (See Figure 4-17)
2. Remove the Heater Lamp Holder Cover. (One screw)
(See Figure 4-18)
Disassembly and Assembly Disassembly and Reassembly of the Printer Body
Figure 4-17. Paper Eject Sensor (PS3) Removal
Figure 4-18. Heater Lamp Holder Cover Removal
