  • Page 1 PA-301 User's Manual...
  • Page 3 ©2014 RuggON Corporation. All rights reserved. TRADEMARKS RuggON logo is a trademark of RuggON Corporation, registered in the United States Patent and Trademark Office and in other countries. Microsoft and the Windows logo are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

  • Page 5: Table Of Contents

    Table of Contents About This Manual Related Information ..................1 Conventions ....................1 Basic Safety Guidelines Intended Use ....................2 Maintenance and Operation Overview ............2 Safety ......................2 Electrical Hazards ..................3 Safety Guidelines for Mounting ..............3 Environmental ....................3 Radio Transmissions ..................4 Cleaning and Servicing .................4 Regulatory and Certification .................4 Lithium Battery Safety Statement ..............5 Chapter 1.
  • Page 6 Chapter 3. Operation First Time Use ....................49 Powering On and Off the Device ..............50 Connecting to Network ................51 Paring the NFC Device ................52 Chapter 4. Troubleshooting Chapter 5. Maintenance Cleaning the Device ...................57 Returning the Device ..................57 Contacting RuggON ...................57...

  • Page 7: About This Manual

    About This Manual The PA-301 User’s Manual provides instruction for qualified personnel to follow when setting up a new PA-301 device. This document is intended for use by qualified personnel to compliment the training and expertise, not to replace it.

  • Page 8: Basic Safety Guidelines

    The PA-301 is designed and manufactured according to strict controls and following the stated safety regulations. The following list identifies incorrect operating uses of the PA-301. Incorrect use of the PA-301 can lead to hardware damage, safety issues and possible risk to personnel health: The PA-301 is under operation by untrained personnel;...

  • Page 9: Electrical Hazards

    Environmental Ambient Temperature The PA-301 operates on the basis of a passive cooling concept which internal waste heat is released via the housing surface and requires fresh airflow in the environment. Operating the PA-301 with no fresh cooling air may cause overheating and damage to the „...

  • Page 10: Radio Transmissions

    The operator is solely responsible for this type of operation. Radio Frequency Limited Locations Considering the radio frequency limitation in hospitals and aircraft, the PA-301 can only be installed with permission. Industrial computers may affect the function of implanted medical devices such as pacemakers and may cause malfunction.

  • Page 11: Lithium Battery Safety Statement

    conditions for satisfying RF exposure compliance. Europe – EU Declaration of Conformity This device complies with the essential requirements of the R&TTE Directive 1999/5/EC and EMC directive 2004/108/EC. The following test methods have been applied in order to prove presumption of conformity with the essential requirements of the R&TTE Directive 1999/5/EC and EMC directive 2004/108/EC: •...

  • Page 13: Chapter 1. Introduction

    5 MP AF rear camera with LED flash About This Guide The PA-301 User Manual provides instruction for qualified personnel to use as a guide for setup of the device. This document is not intended to replace the training and expertise of the end-user.

  • Page 14: Parts List

    Introduction Parts List The PA-301 does not ship with any accessories. All accessories are sold and ordered separately. For help, contact your local RuggON sales representative. See “Contacting RuggON” on page PA-301 2-Point Carrying Handle 4-Point Handstrap 2-Point Shoulder Strap...

  • Page 15: Technical Specifications

    Introduction Technical Specifications Table 1. Technical Specifications Item Description Display 7-inch LED Backlight, 1280 (W) x 800 (H) WXGA Touch Screen Two-point capacitive touch screen Brightness 350nits OMAP Platform (OMAP4470 dual-core, 1.5GHz) ® Operating System Android™ 4.0.4 (ICS) 2GB LPDDRII memory Storage 1 x 32GB Flash eMMC „...
  • Page 16 Introduction Item Description Security BIOS On/Off for I/Os Data Collection Front: 1.2 Mega-Pixels camera „ Camera „ Rear: 5.0 Mega-Pixels camera with LED auxiliary light and Auto-focus Barcode Scanner Optional snap-on module Mag Stripe Reader Optional snap-on module Rugged Specifications Drop 152 cm (59.8”), 26 drops on plywood Vibration (MIL-STD-810G Method 514.6 Category 4, Fig...

  • Page 17: Identifying The Device

    Introduction Identifying the Device Overview Figure 1. Overview Table 2. Overview Item Description Left view See “Side View” on page 14 for further information. Front view See “Front View” on page 12 for further information. Rear view See “Rear View” on page 15 for further information. Right view See “Side View”...

  • Page 18: Front View

    Introduction Front View Figure 2. Front View 10 9 Table 3. Front View Item Description Snap-on module Open to access snap-on module connector. connector cover Touch screen Anti-glare tempered capacitive touch panel. Easy to grip rubber bumpers enable the rugged tablet to withstand Rubber bumpers shocks and drop for use in demanding environments.

  • Page 19: Bottom View

    Introduction LED Status Table 4. LED Status Item Status Description Green: On Power on / not charging Green: Power Battery charging Blinking Amber: On Low battery Green: On GPS is located Green: GPS is locating Blinking Green: On Wi-Fi is enabled Wi-Fi Wi-Fi is disabled Bottom View...

  • Page 20: Side View

    Item Description Left I/O compartment Open to access the left I/O ports. cover Connect the PA-301 to an Ethernet interface. RS-232 Connect the PA-301 to a serial device. USB 2.0 Connect USB devices to the PA-301. Power key Turns the PA-301 on or off.

  • Page 21: Rear View

    Introduction Rear View Figure 5. Rear View Table 7. Rear View Item Description Snap-on module Open to access snap-on module connector. connector cover External battery Open to access external battery connector. The external battery is connector cover optional. Securing holes Location of holes to secure the handstrap.

  • Page 22: Dimensions

    Introduction Dimensions The following image lists the device dimensions without add-ons (mm/inches)--bumpers are included. Figure 6. Front View Dimensions 240.00 / 9.45 225.00 / 8.86 Figure 7. Side View Dimensions 40.00 / 1.57 26.50 / 1.04...

  • Page 23: Touch Screen

    Introduction Touch Screen Never use an actual pen, pencil, or sharp/abrasive object on the touch screen. Touch the screen to perform an action or initiate a function. The following actions are available through the the touch screen: Open applications „ „...

  • Page 24: Chapter 2. Getting Started

    Getting Started Chapter 2. Getting Started This section provides an outline of the steps necessary to setup a PA-301. A detailed guide follows the listed items. For additional technical assistance, contact your RuggON representative. See “Contacting RuggON” on page 57.

  • Page 25: Replacing The Snap-On Module Connector Cover

    Getting Started Remove the cover. Figure 10. Removing the Snap-on Module Connector Cover Replacing the Snap-on Module Connector Cover The snap-on module connector is located on the rear side of the device. For further information see “Overview” on page 11. Locate the snap-on module connector cover.
  • Page 26 Place the device display side down on a clean work surface. Figure 12. Installing the Snap-on Module Connector Cover Secure the cover and the PA-301 with screws. Figure 13. Securing the Screws Snap-on module connector cover is not be closed well may damage the PA-301.

  • Page 27: Opening The I/O Cover

    Getting Started Opening the I/O Cover The PA-301 has two I/O covers. In the following example, the left I/O cover is used to demonstrate how to open and close a compartment cover. Locate the I/O covers. Figure 14. Side View: Locating the I/O Covers...

  • Page 28: Closing An I/O Cover

    Getting Started Closing an I/O Cover The PA-301 has two I/O covers. In the following example, the left I/O cover is used to demonstrate how to close a compartment cover. Locate the I/O cover. Figure 16. Side View: Locating the I/O Covers...

  • Page 29: Installing The Micro Sim Card

    Check with your network or cellular service provider for availability and cost rates. Power off the PA-301. Open the right I/O cover. See “Opening the I/O Cover” on page 21. Locate the micro SIM slot in the right I/O parts.
  • Page 30 Getting Started The micro SIM card has a corner missing. Align the micro SIM card with the slot making sure that the corners match. Insert the micro SIM card and press it in until an audible click sounds. Figure 20. Installing the Micro SIM Card Install the securing bracket.

  • Page 31: Removing The Micro Sim Card

    Getting Started Removing the Micro SIM Card Power off the PA-301. Open the right I/O cover. See “Removing the I/O Cover” on page 21. Locate the micro SIM slot in the right I/O parts. Figure 22. Right View: Locating the Micro SIM Slot...
  • Page 32 Getting Started Press the micro SIM card in to release it. The card springs out. Grasp the micro SIM card and remove it from the slot. Figure 24. Removing the Micro SIM Card Install the securing bracket. Secure the securing bracket with a screw. Figure 25.

  • Page 33: Installing The Micro Sd Card

    Installing the Micro SD Card The device supports micro SD card for easier data storage. Power off the PA-301. Open the right I/O cover. See “Opening the I/O Cover” on page 21. Locate the micro SD slot in the right I/O parts.

  • Page 34: Removing The Micro Sd Card

    Getting Started Removing the Micro SD Card Power off the PA-301. Remove the right I/O cover. See “Removing the I/O Cover” on page 21. Locate the micro SD slot in the right I/O parts. Figure 28. Right View: Locating the Micro SD Slot...

  • Page 35: Connecting To External Cabling

    Connect USB Cabling The PA-301 have a USB Type A port for connecting USB devices, such as a digital camera, scanner, printer, modem, and mouse. The USB ports support USB 2.0 devices. Open the left I/O cover. See “Closing an I/O Cover” on page 22.
  • Page 36 Getting Started Connect Ethernet Cabling The PA-301 provide mini USB to RJ45 dougle for connecting Ethernet. Use a shielded cable is required to maintain emissions and susceptibility compliance. Open the left I/O cover. See “Removing the I/O Cover” on page 21.
  • Page 37 Getting Started Connect RS-232 Cabling Connect to RS-232 devices via RS-232 cable. Open the left I/O cover. See “Closing an I/O Cover” on page 22. Align the RS-232 cable with the port in the device and connect it. Figure 34. Connect RS-232 Cabling...

  • Page 38: Handstrap, Carrying Handle And Shoulder Strap

    Getting Started Handstrap, Carrying Handle and Shoulder Strap The PA-301 comes with a handstrap, carrying handle and shoulder strap. All three accessories are not installed prior to packing. The handstrap can be installed with either the shoulder strap or the carrying handle. However, the handle and strap can not be installed together due to space constraints.

  • Page 39: Attaching The Carrying Handle

    Getting Started Removing the Handstrap Unscrew the D-rings securing the handstrap to the device. Remove the handstrap from the PA-301. Figure 36. Removing the Handstrap Attaching the Carrying Handle The handle must face the correct way. The securing post and velcro should be facing outward.
  • Page 40 Getting Started Pull the strap end through the loop and insert the post through the slit on the strap. Secure the strap by attaching the two velcro ends together. Figure 38. Securing the Strap Repeat fro the remaining strap end. Removing the Carrying Handle Remove the strap from the velcro and securing post.
  • Page 41 Getting Started Repeat for the remaining side. Remove the carrying handle. Attaching the Shoulder Strap The shoulder strap must face the correct way. The securing post and velcro should be facing outward. Thread one end of the strap through the metal loop on the bumper. Figure 41.
  • Page 42 Getting Started Removing the Shoulder Strap Remove the strap from the velcro and securing post. Figure 43. Removing the Strap Pull the strap through the metal loop on the bumper. Figure 44. Removing the Shoulder Strap Repeat for the remaining side. Remove the shoulder strap.

  • Page 43: Charging The Battery

    Getting Started Charging the Battery When you use the AC adapter to connect your PA-301 to a power outlet, the internal and external (optional) battery will automatically begin to recharge. While the battery is charging, the Power LED will be active. When the battery is fully charged, the Power LED is lit a solid green.

  • Page 44: Right View

    Getting Started After charging the battery, disconnect the AC adapter and close the DC-IN cover. Locate the DC-IN cover. Figure 48. Right View: Locating the DC-IN Cover Right view DC-IN Cover Flip the DC-IN cover and install. Figure 49. Installing the DC-IN Cover The DC-IN cover must be inserted correctly to prevent internal damage to the device.

  • Page 45: Installing The External Battery

    Getting Started Installing the External Battery The external battery is an optional component. Only use components specifically designed for this device. Contact your local representative for ordering information. Make sure the power switch is switched to ON before installing the external battery. See “First Time Use”...
  • Page 46 Getting Started Align the tabs on the external battery bracket with the slots on the rear side of the PA-301 . Figure 52. Aligning the External Battery Bracket Push the external battery bracket toward to lock. Figure 53. Installing the External Battery Bracket Securing the external battery bracket and the PA-301 with screws.
  • Page 47 Getting Started Install the connector cover in the cover placeholder. Figure 55. Placing the External Battery Connector Cover in the Cover Placeholder Align the tabs on the external battery with the slots on the external battery bracket. Angle the battery in place and set the tabs in the bracket slots. 10.
  • Page 48 Getting Started 11. Press the locking switch on the top-left side to lock the external battery. Figure 57. Locking the External Battery...

  • Page 49: Removing The External Battery

    Getting Started Removing the External Battery Press the locking switch on the top-left side to the unlock position. Figure 58. Unlock the External Battery Press and hold the release button as shown in the image to release the battery. Hold the battery and angle the top side up to remove. Figure 59.
  • Page 50 Figure 60. Removing the External Battery Connector Cover Remove the screws securing the external battery bracket. Figure 61. Removing the Screws Push the external battery bracket forward the bottom of the PA-301 to release the bracket. Figure 62. Releasing the External Battery Bracket...
  • Page 51 Getting Started Remove the external battery bracket. Figure 63. Removing the External Battery Bracket Install the connector cover in the external battery compartment to protect the battery connector. Figure 64. Installing the External Battery Connector Cover...

  • Page 52: Mag Strip Reader And Barcode Scanner

    Align connectors on the module and the device. Insert the device over the connector and press down. An audible click sounds when the module is installed correctly. Figure 65. Installing the Module Secure the module and the PA-301 with the provided screws. Figure 66. Installing the Screws...
  • Page 53 Getting Started Removing the Module Remove the Add-on compartment cover. See “Removing the Snap-on Module Connector Cover” on page 18. Remove the screws securing the module. Figure 67. Removing the Screws Grasp the module from both sides and gently pull the module off. Remove the module.

  • Page 54: Removing The Protective Film From The Display

    Getting Started Removing the Protective Film from the Display The screen on the PA-301 is protected during transport by a transparent film. Keep the protective film on the screen during the assembly to avoid damage to the screen’s surface. Only remove the film once all of the assembly work has been completed.

  • Page 55: Chapter 3. Operation

    Operation Chapter 3. Operation First Time Use Turn the device over and place it on a clean surface. Remove the external battery connector cover. Figure 74. Removing the External Battery Connector Cover Find the DIP switch located in the connector compartment. Switch the DIP switch to ON. Figure 75.

  • Page 56: Powering On And Off The Device

    Figure 76. Installing the External Battery Connector Cover Powering On and Off the Device Powering On the Device Only power on the PA-301 after connecting all of the attachments. Press and hold the power key for 1 second. Figure 77. Power On the PA-301 Powering Off the Device Press and hold the power key for 5 seconds.

  • Page 57: Connecting To Network

    Tap Save. Connecting to Wireless Network Before you can make use of the PA-301 wireless functions, you will need to connect to a network. Wi-Fi communication requires access to an existing Wireless Access Point (WAP). WAPs can be Open (unsecured, as with most hotspots) or Secured (requiring you to provide login credentials).

  • Page 58: Paring The Nfc Device

    Tap APPS > Setting > More..Tap NFC to turn the NFC function on. Use your NFC-enabled device to touch to the PA-301. Figure 79. Paring the NFC Device Once the two devices are paired, information sharing is available through the NFC connection.

  • Page 59: Chapter 4. Troubleshooting

    Troubleshooting Chapter 4. Troubleshooting Refer to this resource page for useful information about the Android 4.0 Ice Cream Sandwich (ICS) operating system loaded in your tablet. You may also go to the Android ICS page (android.com/about/ice-cream-sandwich/) for more details. How do I change the home screen wallpaper? To change the wallpaper, tap and hold your finger on the Home Screen to open your wallpaper options.
  • Page 60 To exit from the Recent Apps list you can tap the down arrow in the lower-left corner or tap your screen outside of the apps list. How do I remove the browser history on my PA-301? Internet browsers store a list of all the sites you visit called history. If you wish to delete...
  • Page 61 Make sure to perform a backup before proceeding. My PA-301 does not display correct time and date even after adjusting the settings. How can I fix this? Replace the 3V lithium battery with a new one. The device uses a battery to retain system...
  • Page 62 What can I do if my tablet does not power on? If your PA-301 does not power on, try the following to resolve the issue: Ensure that the power cord and/or AC adapter are plugged into the computer and that „...

  • Page 63: Chapter 5. Maintenance

    Maintenance Chapter 5. Maintenance Cleaning the Device Danger to electric shock when cleaning or maintaining the PA-301. To avoid electric shock, turn the PA-301 off and disconnect it from the power supply before cleaning or maintaining it. Housing „ The housing of the PA-301 is best cleaned with a damp cloth.
