RuggON PM-511 Quick Setup Manual

Getting Started
1. Switch ON the main battery
a. Main battery switch is located on rear side of
yellow label battery door
b. Adjust DIP switch to "ON"
c. Place the battery door back
2. Plugging the Power Cable
(Figure 2)
a. Plug the AC power cord into the power
socket of the AC power adapter.
b. Plug the other end of the AC power
cord to a live AC wall outlet.
c. Plug the connector of the AC adapter
to the DC-IN port found at the left side
of the PM-521.
3. Turning on the PM-521 System
(Figure 3)
To turn on the PM-521 System, press
the power button. The power LED will
light up to indicate that the PM-521
System is on.
Main Packing List
Main system
Power Adapter
Corner Rubber
Accessories (Option)
Barcode Scanner
Vehicle Docking
Battery Charger
External Battery Pack
Exploring Your PM-511 System
PM-511 Quick Setup Guide v1.0
(Figure 1)
QTY
1 Stylus
1 Hand Strap
2 Shoulder Strap
QTY
1 MSR
1 GPS
1 Carrying Bag
1
QTY
1 Hand Screws
1 Corner Rubber Screw
1 Ethernet Cable
QTY
1 DeskTop Docking
1 Vehicle Power Adapter
1 Handle Secures
Figure 1
Figure 2
Figure 3
QTY
4
4
1
QTY
1
1
1
