Dear music lover,
Thank you for purchasing a Pro-Ject Audio Systems record player.
In order to achieve maximum performance and reliability with this record player you should study these instructions
for use carefully.
Warning of a hazard for the user, the unit or possible misuse.
!
Important notice.
During assembly and adjustment of the deck small parts could be lost if not carefully placed in a suitable
receptacle.
Before starting assembly make yourself acquainted with the parts listed above and correspondingly numbered
in the technical drawings above. Separately packed items are marked with an asterisk *.

Safety instructions

Make sure that the power supply is easily accessible at all times. Never handle the power supply
while your hands are wet or damp.
Avoid letting liquids enter the device. Never place any item containing liquid, such as a flower vase
on or near the device. Never spill any liquid on the device. Never place any naked flame sources,
!
such as lighted candles on or near the device. The product shall not be used in damp or wet locations,
next to a bathtub, sink, swimming pool or any other similar conditions.
Keep plastic bags away from children to prevent any risk of suffocation.
Set-up
The deck is supplied partially disassembled and carefully packaged for safe transport. Carefully remove all
parts from the transport packaging. The description of all packaged parts you can find on the last page of these
instructions for use.
Screw the three feet (22) onto the threaded bolts located on the underside of the plinth. Every foot is marked
by small sticker with the correct position (FRONT LEFT, FRONT RIGHT, BACK). Make sure the surface you
wish to use the turntable on is level (use a spirit level) before placing the turntable on it.
Carefully place the platter bearing housing over the bearing axle. Put the record weight on the platter and
level the plinth using a spirit level and the adjustable feet (22).
Please note: Every foot is pre-adjusted from the factory to the correct position. Every foot has different
inside construction. The turntable was balanced in the factory before packing. Watch out for the
correct position of each foot!
Never try to adjust the individual height of each foot, because the internal magnet assembly can be
seriously damaged, when this is done by unqualified personnel. For further assistance, please
!
contact your local dealer or distribution!
Fit the drive belt (3) around the platter (4) and the smaller diameter part of the motor pulley (2).
Avoid getting sweat or grease on the belt as these will deteriorate the performance and reduce the belt's
lifespan. Use absorbent kitchen paper to remove any oil or grease from the outer edge of the hub and the belt.
Put the pulley cover on its rests.
Please note: We recommend to use the record player without a mat on the platter.
4
