Thank you for purchasing a Pro-Ject Audio Systems record player.

In order to achieve maximum performance and reliability, please study these instructions carefully.

Warning of a hazard for the user, the unit or possible misuse

Important notice

The following instructions for adjusting the cartridge are provided in case the cartridge is replaced by a different

model at a later date.

During assembling and adjustment small parts could be lost if they are not carefully placed in a suitable

receptacle. Before starting assembly make yourself acquainted with the parts listed above which are

correspondingly numbered in the technical drawings above.

Safety instructions

The power supply is used to connect and disconnect the unit from the mains. Make sure that the plug

is always easily accessible. Hold the plug when unplugging the power cord. Never handle the power

cord while your hands are wet or damp.

Avoid letting liquids enter the device. Never place any item containing liquid, like a flower vase, on or

near the device. Never spill any liquid on the device. Never place any naked flame sources, like lighted

candles, on or near the device. The product shall not be used in damp or wet locations, next to a

bathtub, sink, swimming pool or any other similar conditions.

Keep plastic bags away from children to prevent any risk of suffocation.

Adjustment of the sub-chassis

Remove the sub-platter (17) from the bearing. Screw the adjusting screw (24) into freely accessible thread in

the sub-chassis (16) until the tip dips into the silicone oil of the damping tank (26), secure the adjusting screw

(24) by (only finger-tight) tightening the counter nut (25). The thread of the adjusting screw (24) should

protrude approx. 5mm over the surface of the sub-chassis.

The final setting of the adjustment screw (24) for the sub-chassis damping is left to experimentation and

personal listening habits.

Then carefully insert the sub-platter back into the bearing. Place the main platter (2) on the spindle of the

sub-platter (16). Place the drive belt (3) around the main platter (2) and the pulley (3). Remember that hand

sweat or grease can impair the function of the belt. Please use a clean cloth or a sheet of kitchen paper. Put

a record on and turn the record clamp onto the thread of the spindle.

Remove the transport lock from the tonearm tube. Pack the transport lock and the three transport lock screws

(18) of the sub-chassis in a labelled, sealed envelope and keep it in the original box for later transport or

shipping.

Turn the tonearm counterweight (8) with slight pressure on the counterweight support rod.
