Belling 70cm User Manual

Built in 70cm electric oven
Hide thumbs

Advertisement

Quick Links

Belling
Built-in Electric AU
082751601
18.10.2010

Advertisement

loading

  Also See for Belling 70cm

  Summary of Contents for Belling 70cm

  • Page 1 Belling Built-in Electric AU 082751601 18.10.2010...
  • Page 2: Table Of Contents

    CONTENTS Introduction Before Using Safety Using the Grill Using the Ovens Programmer/clock Cleaning Installation Technical Customer Care Please keep this handbook for future reference, or for anyone else who may use the appliance.
  • Page 3 OUR WARRANTY Should you need it ..Inside the paperwork which has come with this appliance, there is a leaflet and card explaining the terms of our extended warranty and guarantee. In order to apply for our five year guarantee, simply fill in the details on the card and post it off, this will register your appliance.
  • Page 4: Before Using

    BEFORE USING THE PRODUCT • Make sure that you have removed all packaging and wrapping. Some of the items inside this appliance may have additional wrapping. • It is advised that you turn the ovens and/or grill on for a short while. This will burn off any residues left from manufacturing.
  • Page 5: Safety

    SAFETY Caution: This appliance is for cooking OVEN/GRILL purposes only. It must not be used for • Always take care when removing food other purposes, for example room heat- from the oven as the area around the ing. cavity may be hot. GENERAL •...
  • Page 6 USING THE GRILL - ELECTRIC USING THE GRILL USING THE GRILL If cleaning the grill pan when it is hot, Caution: Accessible parts may the handle to pour hot fats from the Caution: Accessible parts may Caution: Accessible parts may the handle to pour hot fats from the use oven gloves to move it.
  • Page 7: Using The Grill

    USING THE GRILL - ELECTRIC Using the grill When using the grill in the top oven, Caution : Accessible parts may the speed of grilling can be controlled be hot when the grill is used, by adjusting the grill setting or by young children should be kept selecting a higher or lower shelf position.
  • Page 8: Shelf Positions

    USING THE TOP OVEN - ELECTRIC When you are cooking keep children away from the vicinity of the oven. If you are not preheating the oven, the Caution: The top element gets extremely cooking times in the following guide may hot when in use, so take extra care to need to be extended, as they are based avoid touching it.
  • Page 9 USING THE TOP OVEN - ELECTRIC Top oven baking guide Cooking temperatures Cooking times The temperature settings and time given in the Baking Guides are based on dishes These times are based on cooking in a made with block margarine. If soft tub preheated oven.
  • Page 10: Manual Operation

    USING THE MAIN OVEN - ELECTRIC FANNED Accessible parts may be hot when Manual Operation the oven is used. Young children The programmer must be set to manual should be kept away. operation before the main oven can be used. If A (Auto) is on the programmer display, return the oven to manual To switch on the oven by pressing the up and down buttons...
  • Page 11 USING THE MAIN OVEN - ELECTRIC FANNED Main Oven This makes it ideal for batch baking - eg; Slow cooking ( Setting) Slow cooking ( Setting or 100°C) when planning a party as all the items will I Make sure that frozen foods are •...
  • Page 12: Using The Main Oven

    USING THE MAIN OVEN - ELECTRIC FANNED Be safe There is no need to interchange dishes onto different shelves part way through Do not defrost stuffed poultry using this cooking, as with a conventional oven. method. To help the air circulate freely Do not defrost larger joints of meat and Position the shelves evenly within the poultry over 2kg/4lb using this method.
  • Page 13 USING THE MAIN OVEN - ELECTRIC FANNED Note: this is a high efficiency oven, therefore some adjustment will have to be made to conventional cooking temperatures. The table below shows conventional cooking temperatures, ‘A’ efficiency temperatures and gas marks. For optimum results, conventional temperatures need to be converted to ‘A’...
  • Page 14 USING THE MAIN OVEN - ELECTRIC FANNED Main oven baking guide Dish Recom- Approximate mended cooking time temperature (preheated °C oven) Scones 8 - 15 mins Meringues 2 - 3 hours Cakes Small cakes 15 - 25 mins Whisked sponge 15 - 20 mins Swiss roll 10 - 12 mins...
  • Page 15: Traditional Fruit Cakes

    USING THE MAIN OVEN - ELECTRIC FANNED Traditional fruit cakes Roast turkey It should be remembered that ovens can Roasting turkey involves cooking two vary over time, therefore cooking times different types of meat - the delicate light can vary, making it difficult to be precise breast meat, which must not be allowed when baking fruit cakes.
  • Page 16 USING THE MAIN OVEN - ELECTRIC FANNED Notes: Roasting guide • When cooking stuffed meat or poultry The times given in the roasting guide calculate the cooking time from the are only approximate, because the size total weight of the meat plus the and age of the bird will influence cooking stuffing.
  • Page 17 USING THE MULTI-FUNCTION OVEN/GRILL Oven & Grill Functions The chart below details all of the funtions which are available. Your oven may not have all of the functions shown here. Symbol Function / Recomended Uses Feature Conventional Grill This function cooks food from the top and is ideal for a range of food from toast to steaks.
  • Page 18 USING THE MULTI-FUNCTION OVEN/GRILL Grilling in the main oven Manual operation The main oven grill & fanned grill are The programmer must be set to manual fixed settings using the inner element operation before the main oven or grill functions can be used. If A (Auto) is only.
  • Page 19: Automatic Operation

    USING THE MULTI-FUNCTION OVEN/GRILL Manual operation To help the air circulate freely Set the programmer to manual operation. • Position the shelves evenly within the See ‘Programmer / Clock’ section. Turn oven and maintain a clearance from the the selector control knob to the symbol oven roof and base.
  • Page 20: Intensive Bake

    USING THE MULTI-FUNCTION OVEN/GRILL Be safe Fan oven • Do not defrost stuffed poultry using this (i) Turn the selector control knob to the method. fan oven symbol. • Do not defrost larger joints of meat or (ii) Turn the main oven control knob to poultry over 2kg / 4lb using this method.
  • Page 21: Programmer/Clock

    setting up the automatic cooking. See This me below for details. when y USING THE PROGRAMMER/CLOCK - ELECTRIC (if fitted) PROGRAMMER / CLOCK of time Press once : Minute Minder Press twice : Cook Time Press three times : End Time automa PROGRAMMER / CLOCK The programmer button...
  • Page 22: Setting The Minute Minder

    USING THE PROGRAMMER/CLOCK - ELECTRIC (if fitted) PROGRAMMER / CLOCK PROGRAMMER / CLOCK To set the time of day To set the time of day To set the time of day Setting the minute minder Setting the minute minder Setting the minute minder Press the Up and Down buttons Press the Up and Down buttons To set the Minute Minder, press the...
  • Page 23 USING THE PROGRAMMER/CLOCK - ELECTRIC (if fitted) Semi-automatic cooking For the instructions on how to use both of these functions, please see the following There are two types of semi automatic page. cooking available on this appliance. Fully automatic cooking The oven must be switched on, and in use to use either of these This function incorporates both a duration...
  • Page 24: Semi-Automatic Cooking

    USING THE PROGRAMMER/CLOCK - ELECTRIC (if fitted) PROGRAMMER / CLOCK Semi-automatic cooking 1. The Duration method Semi-automatic cooking The Duration method • Press the Function button twice,(1) The Duration method which will skip past the Minute Minder. Press the Function button twice,(1) •...
  • Page 25 USING THE PROGRAMMER/CLOCK - ELECTRIC (if fitted) PROGRAMMER / CLOCK Fully automatic cooking (example) Fully automatic cooking (example) This programming method is best suited This programming method is best suit- for when a delayed start time is required. ed for when a delayed start time is Unlike the semi automatic methods this requires both the duration and the end required.
  • Page 26: Cleaning

    CLEANING GENERAL • Baby oil can be used to restore stain- less steel finishes - but only use a few • It is important to clean the product drops. Don’t use cooking oils as they regularly as a build up of fat can affect can contain salts, which will damage the its performance or damage it and may metal.
  • Page 27 CLEANING • Always make sure that the glass is pushed fully into the Stop position. • To remove the glass panel, open the door wide, hold the top and bottom edges and slide out. Warning: DO NOT operate the ap- •...
  • Page 28 INSTALLATION INSTRUCTIONS - 60CM Step 1 : Prepare installation Do not lift the appliance by the door handle. Whilst every care is taken to eliminate burrs and raw edges from this product, please take care when handling - we recommend the use of protective gloves during installation.
  • Page 29: Installation

    INSTALLATION INSTRUCTIONS - 60CM i) When installed in a typical 600mm Important: Do not modify the outer pan- deep built in housing unit, the false back els of this appliance in any way. should be removed from the housing unit Ensure that you route all mains electrical to provide the necessary depth for cables and flexible tubing well clear of...
  • Page 30 INSTALLATION INSTRUCTIONS - 70CM Before you start - please read the If this appliance is to be installed near to instructions carefully - planning your a corner where the adjacent cabinets run installation will save you time and effort. at right angles forward of the appliance,...
  • Page 31 INSTALLATION INSTRUCTIONS - 70CM Method 1: Without housing unit 1. Take the 6 No 8 x 12mm (silver) self (between 2 base units) tapping screws from the polythene bag, and use them to fit one runner to each Before installing the appliance, check the side of the appliance.
  • Page 32 INSTALLATION INSTRUCTIONS - 70CM Method 1: Without housing unit (between 2 base units) Shown with fixing kit...
  • Page 33 INSTALLATION INSTRUCTIONS - 70CM Method 1: Without housing unit (between 2 base units) Shown without fixing kit...
  • Page 34 INSTALLATION INSTRUCTIONS - 70CM Method 2 : Housing unit with To fix the runners (if required) internal height less than 710mm. 1. Take the side trims, hold it against the Note: You will not need the 2 side trims side of the base unit, and use it to mark...
  • Page 35 INSTALLATION INSTRUCTIONS - 70CM Method 2: Housing unit with internal height less than 710mm Shown with fixing kit...
  • Page 36 INSTALLATION INSTRUCTIONS - 70CM Method 2: Housing unit with internal height less than 710mm Shown without fixing kit...
  • Page 37 INSTALLATION INSTRUCTIONS - 70CM Method 3: Housing unit with internal Remove any fixings that may prevent height 710mm or more entry of the oven into housing, or obstruct the gas inlet pipe. The cabinetry Note: You will not need the 4 runners and...
  • Page 38 INSTALLATION INSTRUCTIONS - 90CM Step 1 : Prepare installation When the false back is removed, it is normally the case that the support shelf Do not lift the appliance by the door for the appliance leaves a gap between handle. the back edge of the support shelf and Remove the fixing screws from the the rear wall of approximately 80mm.
  • Page 39 INSTALLATION INSTRUCTIONS - 90CM Dimensions The appliance is designed to fit into a standard 600mm wide housing unit, with minimum internal dimensions as shown. Note: All sizes are nominal, some varia- tion is to be expected.
  • Page 40: Installation Instructions

    INSTALLATION INSTRUCTIONS 4. First strip the wires, then push the Step 2 & 3 Connect to the electricity cable through the cable clamp in the supply terminal block cover. We recommend that the appliance is 5. Connect the cable to the terminal block connected by a competent person who &...
  • Page 41 Take 60/70/90 fixing positions care not to damage the appliance or cabinetry. 70cm only Method 1 : Care must be taken to en- sure the appliance runners are sufficiently engaged over the top of the runners on the base units.
  • Page 42 INSTALLATION INSTRUCTIONS Anti-stain trim The anti-stain trim is factory fitted to the edges of the appliance front frame. This trim provides the cabinetry with extra protection from any escape of heat. - When Installing the product, ensure the anti-stain trim is correctly located on the edges of the front frame, before positioning and securing the appliance to the cabinet.
  • Page 43 WIRING DIAGRAM...
  • Page 44 WIRING DIAGRAM...
  • Page 45 WIRING DIAGRAM...
  • Page 46: Technical Data

    TECHNICAL DATA ELECTRIC PRODUCTS Warning: This appliance must be earthed. Electrical supply/load 220 - 240V ~ 50Hz Databadge is located at the bottom of the front frame, behind the door. 60cm: load = 2.52 - 3.0kW 70/90cm: load = 4.12 - 4.9kW Countries of destination GB ;...
  • Page 47: Customer Care

    CUSTOMER CARE FAQs What parts of the appliance can be • Automatic cooking will normally washed in a dishwasher? produce condensation when the oven is cooling down with food inside. • Any enamelled parts such as the grillpan can be cleaned in a dishwasher, Should the cooling fan continue to run once the appliance has been as can oven shelves and shelf guides.
  • Page 48 CUSTOMER CARE CHANGING LIGHT BULBS (where fitted) Warning: There is a risk of electric shock, so always make sure you have turned off and unplugged your appliance before starting. Always allow the product to cool down before you change a bulb. Not all appliances have the same number and type of bulbs.
  • Page 49 CUSTOMER CARE Purchasing Cleaning Products and Accesories To order or enquire about any of the products on this page please visit our online Spares store at www.gdhaonline. co.uk or call the Spares Sales. Product Description Product Code Quantity Where Used Rectangular carbon filters 082612620 Hoods...
  • Page 50: Who May Use The Appliance

    Please keep this handbook for future reference, or for anyone else who may use the appliance.
  • Page 51 Please keep this handbook for future reference, or for anyone else who may use the appliance.
  • Page 52 CONTACT US Calling for a service If you should experience any problems with your cooker please contact your retailer or place of purchase. Important note: Service work is to be conducted by authorised persons only. It is also adviseable that your cooker is checked regularly and maintained in good condition. An annual maintenance is recommended.
