IP Camera CL-3FBMX User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

User Manual

IP CAMERA
1/53

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CL-3FBMX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IP Camera CL-3FBMX

Summary of Contents for IP Camera CL-3FBMX

  • Page 1: User Manual

    User Manual IP CAMERA 1/53...
  • Page 2 WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS. CAUTION CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION：TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK).

  • Page 3: Table Of Contents

    Content PREFACE ......................4 PRODUCT SPECIFICATIONS ................4 III. PRODUCT INSTALLATION ................. 7 A. M ......................7 ONITOR ETTING ....................8 ARDWARE NSTALLATION IP A ......................10 SSIGNMENT D. I : ..................13 NSTALL CTIVE CONTROL IV. LIVE VIDEO ....................... 15 IP CAMARA CONFIGURATION ................

  • Page 4: Preface

    I. Preface This is a 1/4’’ CMOS 1.3MegaPixel IP camera with the web server built in. User can view real-time video via IE browser. It supports H.264, JPEG and MPEG4 video compression which provides smooth and high video quality. The video can be stored in the SD card and playback remotely.
  • Page 5 PoE Power consumption Max：2.88W Operating Temperature 0°C ~ 45°C Dimensions φ 44x100mm Weight 135g(IP camera), 255g (with bracket) Network Ethernet 10/ 100 Base-T Network Protocol HTTP, HTTPS, SNMP, QoS/DSCP, Access list, IEEE 802.1X, RTSP, TCP/IP, UDP, SMTP, FTP, PPPoE, DHCP,...
  • Page 6 authentication for network protection, QoS/DSCP Firmware Upgrade HTTP mode, can be upgraded remotely Simultaneous Connection Up to 10 Micro SD card management Recording Trigger Motion Detection, IP check, Network break down (wire only),Schedule, DI Video Format AVI, JPEG Video Playback Delete Files Web browsing requirement Windows 7, 2000, XP, 2003, Microsoft IE 6.0 or above,...

  • Page 7: Product Installation

    III. Product Installation A. Monitor Setting Right-Click on the desktop. Select “ Properties” Change color quality to highest (32bit). 7/53...

  • Page 8: Hardware Installation

    B. Hardware Installation Install the IP Camera together with its mounting bracket as shown in the picture below. Prepare a PoE switch. iii. Connect the IP Camera to local network with Ethernet cable If there is not having PoE switch, please add PoE injector between IP camera and Ethernet switch.
  • Page 9 PoE ( Power Over Ethernet)(Optional) 802.3af, 15.4W PoE Switch is recommended Power over Ethernet (PoE) is a technology that integrates power into a standard LAN infrastructure. It enables power to be provided to the network device, such as an IP phone or a network camera, using the same cable as that used for network connection.

  • Page 10: Ip Assignment

    C. IP Assignment Use the software, “IP Installer” to assign the IP address of IP CAMERA. The software is in the attached software CD. IP installer supports two languages IPInstallerCht.exe：Chinese version IPInstallerEng.exe：English version iii. There are 3 kinds of IP configuration.
  • Page 11 Connection PropertiesInternet Protocol (TCP/IP) Properties Please make sure your IP Camera and PC have the same Subnet. If not, please change IP Camera subnet or PC IP subnet accordingly. A quick way to access remote monitoring is to left-click the mouse twice on a selected IP Camera listed on “Device list”...
  • Page 12 Then, please key in the default “user name: admin” and “password: admin”. 12/53...

  • Page 13: Install Active Xcontrol

    D. Install ActiveX control: For the first time to view the camera video via IE, it will ask you to install the ActiveX component. If the installation failed, please check the security setting for the IE browser. IE  Tools  Internet Options…  Security Tab  Custom Level…  Security Settings ...
  • Page 14 When popup the following dialogue box, click “Yes”. 14/53...

  • Page 15: Live Video

    IV. Live Video Start a IE browser, type the IP address of the IP camera in the address field. It will show the following dialogue box. Key-in the user name and password. The default user name and password are “admin” and “admin”.
  • Page 16 (When streaming 2 setting in『Video Setting』 is closed, this function will not display) IP Camera supports 2-way audio. Click the “Chatting” check box. Then you can use microphone which connects to the PC to talk to server side, which is IP...
  • Page 17 17/53...

  • Page 18: Ip Camara Configuration

    V. Configuration Click to get into the administration page. Click to go back to the live video page. 18/53...

  • Page 19: System

    A.System i、 System Information Server Information: Set up the camera name, select language, and set up the camera time. Server Name：This is the Camera name. This name will show on the IP Installer. Select language：There are English, Traditional Chinese, and Simplified Chinese to select.
  • Page 20 IP CAMERA supports three different users, administrator, general user, and anonymous user. Anonymous User Login： Yes：Allow anonymous login No：Need user name & password to access this IP camera Add user： Type the user name and password, then click “Add/Set”. 20/53...
  • Page 21 To update the firmware online, click “Browse…” to select the firmware. Then click “Upgrade” to proceed. Reboot system：re-start the IP camera Factory default：delete all the settings in this IP camera. Setting Management ： User may download the current setting to PC, or upgrade from previous saved setting.

  • Page 22: Network

    (Default: 80) HTTPs Port: setup the https port(Default: 443) UPnP This IP camera supports UPnP, If this service is enabled on your computer, the camera will automatically be detected and a new icon will be added to “My Network Places.”...
  • Page 23 that video streams can be sent out from a LAN. There are three External port can be set, Web Port, Http Port and RTSP port. To utilize of this feature, make sure that your router supports UPnPTM and it is activated. Note: UPnP must be enabled on your computer.
  • Page 24 Created Request: remove secure identification in Created request mode. There is a warning message showing. Please set “Yes” to remove secure identification. Setting the secure identification and apply it. Installed Certificate: remove Certificate in .Installed Certificate mode. There will be a warning message to check again. There are two ways to set Certificate- Install Signed Certificate and Create Self-Signed Certificate.
  • Page 25 SNMP(Simple Network Management Protocol)： Enable SNMPv1 or SNMPv2 and write the name of Write Community and Read Community. Enable SNMPv3, please set Security Name, Authentication Type, Authentication Password, Encryption Type, Encryption Password of Write mode and Read mode. Enable SNMPv1/SNMPv2 Trap can detect the Trap server. Please set what event need to detect.
  • Page 26 QoS/DSCP(Quality of Server/Differentiated Services Code-point)： DSCP specifies a simple mechanism for classifying and managing network traffic and provide QoS on IP networks. DSCP is a 6-bit in the IP header for packet classification purpose. Please define the reserve for Live Stream, Event / Alarm and Management. IEEE 802.1x：...
  • Page 27 Please check what version of the authenticator and authentication server support. This camera supports EAP-TLS method. Please enter ID, password issued by the CA, then upload related certificates. iii、 PPPoE & DDNS： PPPoE：Select “Enabled” to use PPPoE. Key-in Username and 27/53...
  • Page 28 password for the ADSL connection. Send mail after dialed：When connect to the internet, it will send a mail to a specific mail account. For the mail setting, please refer to “Mail and FTP” settings. DDNS： It supports DDNS (Dynamic DNS) service. DynDNS：...
  • Page 29 Please enable this service Key-in user name. IP Schedule update is default at 5 minutes Click “Apply”. DDNS Status (1) Updating：Information update (2) Idle：Stop service (3) DDNS registration successful, can now log by http://<username>.ddns.camddns.com：Register successfully. (4) Update Failed, the name is already registered：The user name has already been used.
  • Page 30 iv、 Server setting There are three choices of server types available: Email, FTP and SAMBA. Select the item to display the detailed configuration options. You can configure either one or all of them. To send out the video via mail of ftp, please set up the configuration first. To send out the video via mail of ftp, please set up the configuration first.
  • Page 31 31/53...

  • Page 32: A/V Setting

    Click Area button first and pull a area on the above image. Finally, click Save button to reserve the setting. Adjust “Brightness”, “Contrast”, “Saturation” , “Exposure”, “Sharpness” to get clear video. Moreover, IP CAMERA supports “AGC”, “Shutter Time”, “D-WDR”, “Noise reduction” and “Video Orientation” 32/53...
  • Page 33 ii、 Video Setting User may select the camera system type, Streaming 1 Setting: Basic mode and Advanced mode Streaming 2 Setting: Basic mode, Advanced mode, and 3GPP mode (Max Video Frame Rate for both streaming combined is 30 FPS) Streaming 1 Basic Mode： Resolution：...
  • Page 34 Streaming 1 Advanced Mode： Resolution： There are 5 resolutions can be chosen. 1280x800, 1280x720, 640x480, 320x240, 176x144 Bitrate Control Mode There are CBR﹝Constant Bit Rate﹞ and VBR﹝Variable Bit Rate﹞to use. CBR：32Kbps~8Mbps (the higher the CBR is, the better the video quality is) VBR：1(Low)~10(High) –...
  • Page 35 Streaming 2 Basic Mode： Resolution： There are 5 resolutions can be chosen. 1280x800, 1280x720, 640x480, 320x240, 176x144 Quality： There are 5 levels to adjust: Best/ High/ Standard/ Medium/ Low The higher the quality is, the bigger the file size is. Also not good for internet transmitting Video Frame Rate：The video refreshing rate per second.
  • Page 36 good for internet transmitting Video Frame Rate：The video refreshing rate per second. Video Format：H.264, MPEG4 or M-JPEG RTSP Path: RTSP output connecting route 3GPP Streaming mode: 3GPP mode suggested setting: 176x144 resolution, 5FPS, MPEG4 format Enable or Disable 3GPP Streaming 3GPP: 3GPP output name 36/53...
  • Page 37 Camera Built-in mic to remote PC; User can also send audio from remote PC to IP Camera’s external speaker. Audio from IP camera built-in mic to local PC: select “Enable” to start this function and also can select the audio type.

  • Page 38: Event List

    IP CAMERA provides multiple event settings. i、 Event Setting Motion Detection： IP CAMERA allows 3 areas motion detection. When motion is triggered, it can send the video to some specific mail addresses, transmit the video to remote ftp server, trigger the relay, and save video to local SD card.
  • Page 39 Network Dis-connected： IP Camera will scan ones per second. Image will be record to SD card after IP Camera detect network dis-connected, if set “Save to SD card”.
  • Page 40 40/53...
  • Page 41 iii、 Log List Sort by System Logs, Motion Detection Logs and I/O Logs. In addition, System Logs and I/O Logs won’t lose data due to power failure. iv、 SD card Choose “The 1 day” meads the recoding file will be keep one day. Example: It is five o’clock now.

  • Page 42: Network Configuration

    IP address：More than one real IP or one dynamic IP IP CAMERA and PC connect to the internet Device needed：Switch Hub For fixed real IP, set up the IP into IP CAMERA and PC. For dynamic IP, start PPPoE. 42/53...
  • Page 43 Configuration 3： Internet Access：ADSL or Cable Modem IP address：one real IP or one dynamic IP IP CAMERA and PC connect to the internet Device needed：IP sharing Use virtual IP, set up port forwarding in IP sharing. 43/53...

  • Page 44: I/O Configuration

    VII. I/O Configuration 1. I/O Connection a. Please connect the G & AO pin to the external relay (buzzer) device b. Please connect the G & A-I pin to the external trigger device. c. I/O PIN definition • GND (Ground) •...
  • Page 45 If you select "N.O" in "Input sensor setting", when external device or circuit makes DI and GND pin connected, the camera input alarm is triggered, and then camera will execute the action user has set, for example, send snapshot to E-mail address. If you select "N.C"...
  • Page 46 2. I/O Setup a. Click I/O Setting from the system setup page via IE, and check “Out1” to enable I/O signal. b. Output Test After the external input and output hardware is installed, you can use the "Relay Out" bottom on the live video page to test if DO / Relay Out works.
  • Page 47 (ii) Time Switch mode: Click "Pulse", the camera will trigger the external output device for several seconds; the duration length is according to the "interval" setting in Output Setting. 47/53...

  • Page 48: Factory Default

    Unplug the power adapter first. Then, press the following button in the back of IP Camera.  Plug the Ethernet. Do not release the button during the IP Camera booting.  It will take around 30 seconds to boot the IP Camera.

  • Page 49: Universal Password

    Note: Universal password will be valid only when you enable the function in User Management. 1. First, you need to know the IP address and MAC of your IP camera. You can use IP installer to scan the LAN, and see the IP address and MAC on the side column.
  • Page 50 2. Find the .html file named “Universal Password” in CD-ROM. Click to open it. 3. Key in the camera IP address “IP Adder.” column and MAC in “MAC” column, and then click “encoder”. You will see a set of username and password appear, as below: The universal username and password are generated from the IP address and MAC you key in, so if you change the camera IP address, the universal password changes,...
  • Page 51 5. Now you are logging in as administrator. Turn to User Management page. The use of universal password does not affect the previous user setting, so the administrator account password does not change until you edit it. Please click “Edit” to give a new administrator password. 51/53...

  • Page 52: Package Contents

    IX. Package contents IP Camera Quick Installation Guide Mounting Bracket Screws x3 Wall Plug x3 • The CD includes user manual and software tools 52/53...

  • Page 53: Micro Sd Card Compatibility

    X. Micro SD Card Compatibility The following is the Micro SD Card recommended: Transcend SDHC class4 16GB SDHC class4 32GB class4 16GB class4 32GB SDHC class6 SDHC class6 SDHC class6 16GB class6 class6 class6 16GB SanDisk SDHC class4 SDHC class10 SDHC class4 SDHC...
