- Page 1 WARRANTY YEARS ERB706SA 650W PENDULUM JIGSAW SFX-ERB706SA-M-050908.indd 1 2005-9-8 18:42:34...
- Page 2 SFX-ERB706SA-M-050908.indd 2 2005-9-8 18:42:35...
- Page 3 This guarantee does not affect your statutory rights.This guarantee is only valid in the UK. For further technical advice, spare parts or repair service (outside of guarantee) please contact the customer helpline number on 0845 607 6380 650W PENDULUM JIGSAW SFX-ERB706SA-M-050908.indd 3 2005-9-8 18:42:35...
-
Page 4: Safety Instructions
Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. e. Do not overreach. Keep proper footing and balance at all times. This enables SFX-ERB706SA-M-050908.indd 4 2005-9-8 18:42:35... -
Page 5: Health Advice
- Work in a well-ventilated area. -Work with approved safety equipment, such as those dust masks that are specially designed to filter microscopic particles. 650W PENDULUM JIGSAW SFX-ERB706SA-M-050908.indd 5 2005-9-8 18:42:36... - Page 6 15. Always use the appropriate safety equipment that is required for the product. e.g. Goggles / Safety Spectacles, Ear defenders (essential with tools with a noise rating of over 85 dB(A), Gloves and face masks. In all cases ensure that the safety equipment is in good condition. SFX-ERB706SA-M-050908.indd 6 2005-9-8 18:42:36...
- Page 7 SYMBOLS Read the manual Warning Wear gloves Wear dust mask,eye & ear protection Conforms to relevant safety standards 650W PENDULUM JIGSAW SFX-ERB706SA-M-050908.indd 7 2005-9-8 18:42:36...
- Page 8 5. PENDULUM ACTION CONTROL 6. TOOLFREE BLADE HOLDER 7. BLADE GUIDE 8. BLADE GUARD 9. BASE PLATE 10. PARALLEL GUIDE FIXTURES 11. DUST EXTRACTION ADAPTOR PORT 12. PARALLEL GUIDE 13. ALLEN KEY 14. PROTECTION FINGER (See Fig 11) SFX-ERB706SA-M-050908.indd 8 2005-9-8 18:42:36...
-
Page 9: Technical Data
Typical weighted vibration 4m/s ACCESSORIES Blades 6pcs (wood 2pcs aluminium 2pcs steel 2pcs) Parallel guide Dust tube Allen Key You can only use the blade type shown in fig 1. Don’t use other blade types. 650W PENDULUM JIGSAW SFX-ERB706SA-M-050908.indd 9 2005-9-8 18:42:36... -
Page 10: Operating Instructions
This can also be adjusted during no load running. Refer to the chart (See chart 2) for more details. Do not use excessive blade force when cutting with the pendulum action. The blade cuts on the upward stroke only. Fig 4 SFX-ERB706SA-M-050908.indd 10 2005-9-8 18:42:37... -
Page 11: Blade Guide
9. BASE PLATE Adjusting the angle of the base plate enables bevel cutting.The base plate must always be held firmly against the material being cut to reduce saw vibration, blade jumping or blade breakage. 650W PENDULUM JIGSAW SFX-ERB706SA-M-050908.indd 11 2005-9-8 18:42:37... - Page 12 14. DUST BLOWER AIR HOLE This is a small aperture located underneath the housing just behind the blade guide. Ensure this is kept clean to allow the air flow to continually blow dust away from the cutting area. Fig 11 SFX-ERB706SA-M-050908.indd 12 2005-9-8 18:42:37...
-
Page 13: Working Hints For Your Jigsaw
Both wood and sheet metal must be cut. Do not force the cutting blade when cutting thin metal or sheet steel as they are harder materials and will take longer to 650W PENDULUM JIGSAW SFX-ERB706SA-M-050908.indd 13 2005-9-8 18:42:38... -
Page 14: Environment Protection
L. A 13AMP (BS1363 or BS1363/A) plug must be used and a 5 AMP fuse must be fitted. 5 AMP FUSE BLUE N (NEUTRAL) BROWN L (LIVE) OUTER CABLE GRIP SLEEVE SFX-ERB706SA-M-050908.indd 14 2005-9-8 18:42:38... -
Page 15: Declaration Of Conformity
98/37/EC. –Machinery Directive. Standards and technical specifications referred to: EN 60745-1:2003+A1 EN 60745-2-11:2003 EN 55014-1:2000+A1+A2 EN 55014-2:1997+A1 EN 61000-3-2:2000 EN 61000-3-3:1995+A1 Authorised Signatory Date: 15/09/05 Signature: Name: Peter Harries Screwfix Direct Ltd Quality Manager 2005 650W PENDULUM JIGSAW SFX-ERB706SA-M-050908.indd 15 2005-9-8 18:42:38... - Page 16 SFX-ERB706SA-M-050908.indd 16 2005-9-8 18:42:38...
