300w orbital sander

Advertisement

WARRANTY
YEARS
ERB108SDR
300W ORBITAL SANDER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ERB108SDR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Erbauer ERB108SDR

  • Page 1 WARRANTY YEARS ERB108SDR 300W ORBITAL SANDER...
  • Page 2 Congratulations on your purchase of a quality power tool from Erbauer (UK) Ltd. This product should give you reliable service but for your peace of mind this power tool does carries a 24-month guarantee, the terms of which are detailed below.
  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS WARNING! Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. 1. Work area safety a. Keep work area clean and well lit.Cluttered and dark areas invite accidents.
  • Page 4 or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents. d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
  • Page 5 ADDITIONAL SAFETY RULES - FOR ROTARY SANDERS 1. Never use this sander for wet sanding or liquid polishing. Failure to follow this rule may result in risk of electrical shock. 2. Always wear eye protectors when using this sander. 3. Always wear a dust mask when using this sander. 4.
  • Page 6 VIBRATION The European Physical Agents (Vibration) Directive has been brought in to help re- duce hand arm vibration syndrome injuries to power tool users.The directive requires power tool manufacturers and suppliers to provide indicative vibration test results to enable users to make informed decisions as to the period of time a power tool can be used safely on a daily basis and the choice of tool.
  • Page 7: Double Insulation

    Avoid using tools in temperatures of 10C or less Plan your work schedule to spread any high vibration tool use across a number of days. Health Surveillance All employees should be part of an employer’s health surveillance scheme to help identity any vibration related diseases at an early stage, prevent disease progression and help employees stay in work.
  • Page 8 ON/OFF WITCH SOFT GRIP HANDLE VARIABLE SPEED CONTROL DUST EXTRACTION OUTLET BASE PLATE SANDING PAPER (See Fig. B) DUST BAG...
  • Page 9: Technical Data

    TECHNICAL DATA Rated voltage: 230-240V~50Hz Rated power: 300W No load speed: 5,000-12,000min Base size: Ø125mm Orbital dia: Ø2.5mm Protection class: Machine weight: 1.8kg ACCESSORIES Dust bag Dust extraction adaptor Sanding sheet 2pcs Hole punch 300W ORBITAL SANDER...
  • Page 10: Operation Instructions

    OPERATION INSTRUCTIONS NOTE: Before using the tool, read the instruction book carefully. 1. CHANGING HOOK & LOOP SANDING PAPER (See Fig A, B) The sandpaper and sanding plate are provided with a hook and loop attachment system to allow quick and easy changing of the sanding and polishing accessories.
  • Page 11: Using The Sander

    3. ON/OFF SWITCH (See Fig E) To start your sander, depress the protective cover over the switch at the position marked“I” . To stop your sander, depress the protective cover at the position marked “0” . 4. VARIABLE SPEED CONTROL (See Fig F) With the variable speed control (3), the required speed can be selected (also while running).The required speed is dependent on the material and...
  • Page 12: Maintenance

    Do not start sanding without having the sandpaper fitted. Do not allow the sandpaper to wear away, this will damage the base-plate.The guarantee does not cover base-plate wear and tear. Use coarse grit paper to sand rough surfaces, medium grit for smooth surfaces and fine grit for the final surfaces.
  • Page 13: Troubleshooting

    TROUBLESHOOTING 1. If your sander will not operate, check the power at the mains plug. 2. If the sander does not abrade the work piece, check the condition of the sanding paper. If the sanding paper is worn or damaged, replace with new sanding paper and try again.The paper must be kept in a dry place, if it is allowed to become damp, the abrasive particles will lose...
  • Page 14: Plug Replacement

    PLUG REPLACEMENT The fuse in the main plug of your power tool should always be replaced with one of identical rating. Check the voltage given on your power tool matches the supply voltage. The power tool is supplied with a fitted plug, however if you should need to fit a new plug follows the instruction below.
  • Page 15: Declaration Of Conformity

    Declaration of Conformity We, Importer Erbauer (UK) Ltd BA22 8RT Declare that the product 300W ORBITAL SANDER ERB108SDR Complies with the essential health and safety requirements of the following directives: Machinery Directive 98/37/EC Low Voltage Directive 2006/95/EC Electromagnetic Compatibility Directive 2004/108/EC...
