Summary of Contents for Erbauer ERB150D
- Page 1 WARRANTY YEARS ERB150D 18kg BREAKER...
- Page 3 Congratulations on your purchase of a quality power tool from Screwfix Direct Ltd. This product should give you reliable service but for your peace of mind this power tool does carry a 24-month guarantee, the terms of which are detailed below. If this product develops a fault within the guarantee period contact Screwfix Direct Ltd on Freephone 0500 41 41 41.
-
Page 4: Safety Instructions
SAFETY INSTRUCTIONS WARNING! Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. SAVETHESE INSTRUCTIONS 1. Work area a. Keep work area clean and well lit.Cluttered and dark areas invite accidents. b. - Page 5 e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
- Page 6 - Work in a well-ventilated area. - Work with approved safety equipment, such as those dust masks that are specially designed to filter microscopic particles. ADDITIONAL SAFETY RULES FOR YOUR BREAKER This is a powerful concrete breaker and pick. Caution needs to be observed when operating.
-
Page 7: Double Insulation
Double insulation: The tool is double insulated.This means that all the external metal parts are electrically insulated from the mains power supply. This is done by placing insulation barriers between the electrical and mechanical components making it unnecessary for the tool to be earthed. - Page 8 1. RUBBER PROTECTOR 2. STOP LEVER 3. FRONT COVER 4. KNOB 5. ON/OFF SWITCH 6. LOCK-ON BUTTON 7. CORD SHEATH 8. GEAR BOX COVER 9. AUXILIARY HANDLE 10. POINT CHISEL AND FLAT CHISEL 11. GREASE X 1 12. HEXAGON WRENCH...
-
Page 9: Technical Data
TECHNICAL DATA Voltage 230V~50Hz Power input 1700W Impact rate 1300min Double insulation: Weight: 17.7kg NOISE AND VIBRATION DATA Sound pressure level: 83.0 dB(A) Sound power level: 105.0 dB(A) Vibration level: 13.68m/s ACCESSORIES Point chisel (For gravel) Flat chisel (For crushing asphalt, grooving and squaring) 18kg BREAKER... -
Page 10: General Description
GENERAL DESCRIPTION The concrete breaker and pick can be cut crushing asphalt, grooving and squaring, ram tamping sand and gravel, dig ground in various foundation, etc.The machine uses a single phase alternating current 230V, 50Hz motor, its compact and robust format makes it versatile and efficient for uses described in specific safety instructions. -
Page 11: Maintenance
operation (see fig5), To switch off just release the on/off switch. GEARBOX MAINTENANCE Always check there is sufficient grease in the grease box before usage. Check every 5 hrs of usage. Open the grease box using the Hexagon key provided, as shown fig6. Top up the gear. CHANGE THE CARBON BRUSH Fig 6 Replace when the Carbon brush wear down to... -
Page 12: Troubleshooting
TROUBLESHOOTING 1. If your breaker do not start, check the plug and fuse on the mains supply the plug and fuse on the mains supply first. 2. If your concrete breaker and pick work efficiency is too low, please add sufficient grease in the grease box. -
Page 13: Plug Replacement
PLUG REPLACEMENT The fuse in the main plug of your power tool should always be replaced with one of identical rating. Check the voltage given on your power tool matches the supply voltage. The power tool is supplied with a fitted plug, however if you should need to fit a new plug follows the instruction below. -
Page 14: Declaration Of Conformity
Houndstone Business Park Yeovil BA 22 8RT Declare that the product 18kg breaker ERB150D Complies with the essential health and safety requirements of the following directives: 89/336/EEC, 93/68/EEC - EMC Directive. 73/23/EEC, 93/68/EEC – Low Voltage Directive 98/37/EC – Machinery Directive. - Page 15 18kg BREAKER...
