  • Page 1 PCM-9576F ® Socket 370 Celeron™/Pentium SBC with triple Ethernet, CFC and GPIO User's Manual...

  • Page 2: Copyright Notice

    Copyright notice This document is copyrighted, 2001. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of the original manufacturer.
  • Page 3 Windbond is a trademark of Winbond Electronics Corp. All other product names or trademarks are properties of their respec- tive owners. For more information on this and other Advantech products please visit our websites at: http://www.advantech.com http://www.advantech.com/epc For technical support and service for please visit our support website at: http://support.advantech.com...

  • Page 4: Packing List

    Packing list Before you begin installing your card, please make sure that the following materials have been shipped: • 1 PCM-9576F all-in-one single board computer • 1 CD disc with utility and drivers • 1 Startup Manual If any of these items are missing or damaged, contact your distributor or sales representative immediately.

  • Page 5: Table Of Contents

    Contents Chapter 1 General Information....... 1 1.1 Introduction ....................2 1.2 Features ..................... 3 1.3 Specifications .................... 3 Standard SBC functions ................. 3 PCI SVGA/flat panel interface (optional) ..........4 PCI bus Ethernet interface ..............4 Solid state disk ..................5 Mechanical and environmental ...............
  • Page 6 2.12.3 Watchdog output ............... 19 2.12.4 Reset switch ................20 2.13 Power connectors (FAN1, CN16, CN9) ..........20 2.13.1 Peripheral power connector, -5 V, -12 V (CN16) ...... 20 2.13.2 Main power connector, +5 V, +12 V (CN9) ......20 2.13.3 Fan power supply connector (FAN1) ........
  • Page 7 3.2.10 Auto detect hard disk ..............44 3.2.11 Save & exit setup ............... 44 3.2.12 Exit without saving ..............44 Chapter 4 PCI SVGA Setup (Optional) ..45 4.1 Introduction ..................... 46 4.1.1 Chipset ..................46 4.1.2 Display memory ................. 46 4.1.3 Display types ................
  • Page 8 C.9 Backlight connector (CN25) optional ..........80 C.10 Peripheral power connector (CN16) ..........80 C.11 CRT display connector (CN17) ............81 C.12 24-bit LCD display connector (CN18) optional ........ 82 C.13 Ext. LCD display connector (CN19) optional ........83 C.14 LCD signal mapping ................84 C.15 Front panel connector (CN20) ............
  • Page 9 Tables Table 2-1: Jumpers ......................8 Table 2-2: Connectors ....................9 Table 2-3: CMOS clear (J1) ..................15 Table 2-4: Buzzer enable/disable (J8) ................15 Table 2-5: ATX power on function select (J4) ............22 Table 2-6: COM2 RS-232/422/485 setting (J9) ............23 Table 2-7: Serial port default settings ................
  • Page 10 Figure 4-1: Selecting display settings ..............47 Figure B-1: PC/104 module mounting diagram ..........71 Figure B-2: PC/104 module dimensions (mm) (±0.1) ........71 Figure F-1: PCM-9576F mechanical drawing - component side ....100 Figure F-2: PCM-9576F mechanical drawing - solder side ......101...

  • Page 11: Chapter 1 General Information

    General Information This chapter gives background information on the PCM-9576F. Sections include: • Introduction • Features • Specifications • Board layout and dimensions...

  • Page 12: Introduction

    EMI. The PCM-9576F has been certified as complying with FCC Class A and CE Marking Class A. Triple Ethernet for Communication Appliances The PCM-9576F supports 3 Ethernet interfaces designed for the Communication Market.

  • Page 13: Features

    1.2 Features • 2 or 3 Ethernet function on board • Wake on LAN, modem (Optional for RTL 8139 LAN chip) • Supports 3 GPIO for Ethernet communication status display • Optional: VGA/LCD function • Optional: Additional 3rd and 4th serial ports •...

  • Page 14: Pci Svga/Flat Panel Interface (Optional)

    RTL8139) PCI-bus Ethernet controller • Ethernet interface: PCI 100/10 Mbps Ethernet, IEEE 802.3U protocol compatible • Connection: On-board 10 pin header x 3 • I/O address switchless setting • Built-in boot ROM (optional for RTL8139 LAN chip) PCM-9576F User's Manual...

  • Page 15: Solid State Disk

    Solid state disk • One 50-pin socket: For one CompactFlash card, shared with one IDE channel Mechanical and environmental • Dimensions (L x W): 203 x 146 mm (8" x 5.75") • Power supply voltage: +5 V ±5% • Power requirements: 5.2 A @ 5 V (4.75 to 5.25) (typical, 64 MB DRAM, ™...

  • Page 16: Board Layout And Dimensions

    1.4 Board layout and dimensions Figure 1-1: PCM-9576F dimensions PCM-9576F User's Manual...

  • Page 17: Chapter 2 Installation

    Installation This chapter tells how to set up the PCM-9576F hardware, including instructions on setting jumpers and connecting peripherals, switches and indicators. Be sure to read all the safety precautions before you begin the installation procedure.

  • Page 18: Jumpers

    2.1 Jumpers The PCM-9576F has a number of jumpers that allow you to configure your system to suit your application. The table below lists the function of each of the board’s jumpers: Table 2-1: Jumpers Label Function CMOS clear Watchdog timer action...

  • Page 19: Connectors

    2.2 Connectors On-board connectors link the PCM-9576F to external devices such as hard disk drives, a keyboard, or floppy drives. The table below lists the function of each of the board’s connectors: T a b l e 2 - 2 : C o n n e c t o r s...

  • Page 20: Locating Jumpers

    2.3 Locating jumpers Figure 2-1: Locating jumpers PCM-9576F User's Manual...

  • Page 21: Locating Connectors

    2.4 Locating connectors 2.4.1 Component side Figure 2-2: Locating connectors (component side) Chapter 2 Installation...

  • Page 22: Solder Side

    2.4.2 Solder side Figure 2-3: Locating connectors (solder side) PCM-9576F User's Manual...

  • Page 23: Setting Jumpers

    2.5 Setting jumpers You configure your card to match the needs of your application by setting jumpers. A jumper is the simplest kind of electric switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.

  • Page 24: Cpu Installation And Upgrading

    2.6.1 Installing a CPU in the ZIF socket The PCM-9576F provides a Zero Insertion Force (ZIF) socket for easy CPU installation. 1. Make sure the ZIF socket lever is in the upright position. To raise the lever, pull it out to the side a little and raise it as far as it will 2.

  • Page 25: Cmos Clear (J1)

    When the CPU is installed, the lever should snap into place at the side of the socket. Note: To remove a CPU, pull the lever out to the side a little and raise it as far as it will go. Lift out the CPU chip. 2.6.2 CMOS clear (J1) Warning: To avoid damaging the computer, always turn off the...

  • Page 26: Installing Dram (Sodimms)

    2.8 IDE Hard Drive Connector (CN13) You can attach one or two Enhanced Integrated Device Electronics hard disk drives to the PCM-9576F’s internal controller. The PCM-9576F’s IDE controller uses a PCI local-bus interface. This advanced IDE controller supports faster data transfer, PIO mode 3, mode 4.

  • Page 27: Connecting The Hard Drive

    2.9 Floppy drive connector (CN11) You can attach up to two floppy drives to the PCM-9576F’s on-board controller. You can use any combination of 5.25” (360 KB and 1.2 MB) and/or 3.5” (720 KB, 1.44 MB, and 2.88 MB) drives.

  • Page 28: Connecting The Floppy Drive

    2.10 Parallel port connector (CN14) Normally, the parallel port is used to connect the card to a printer. The PCM-9576F includes a multi-mode (ECP/EPP/SPP) parallel port, accessed through CN14, a 26-pin flat-cable connector. You will need an adapter cable if you use a traditional DB-25 connector. The adapter cable has a 26-pin connector on one end and a DB-25 connector on the other.

  • Page 29: Keyboard And Ps/2 Mouse Connector (Cn7)

    2.12.1 Speaker The PCM-9576F can drive an 8 Ω speaker at 0.5 watts. Make sure that alternatives to this specification do not overload the card. 2.12.2 LED interface The front panel LED indicator for hard disk access is an active low signal (24 mA sink rate).

  • Page 30: Reset Switch

    Supplies secondary power to devices that require -5 V and -12 V. 2.13.2 Main power connector, +5 V, +12 V (CN9) Supplies main power to the PCM-9576F (+5 V) and devices that require +12 V. 2.13.3 Fan power supply connector (FAN1) Provides power supply to optional CPU cooling fan.

  • Page 31: Atx Power Control Connector (Cn2, J3)

    2.14 ATX power control connector (CN2, J3) 2.14.1 ATX feature connector (CN2) and power button (J3) The PCM-9576F can support an advanced power button if an ATX power supply is used. To enable the power button: 1. Take the specially designed ATX-to-PS/2 power cable PCM-9576F optional item, P/N 1703200201.

  • Page 32: Atx Power On Function Select (J4)

    ATX power switch button J3. 2.16 IR connector (CN10) The PCM-9576F provides an IrDA port for transfer rates of 115 Kbps. This connector supports the optional wireless infrared transmitting and receiving module. This module mounts on the system case. You must configure the setting through BIOS setup.

  • Page 33: Com2 Rs-232/422/485 Setting (J9) (Optional)

    The IRQ and the address range for COM1, 2, 3, 4 are fixed. However, if you wish to disable the port or change these parameters later you can do this in the system BIOS setup. The table below shows the settings for the PCM-9576F’s serial ports. Table 2-7: Serial port default settings Port...

  • Page 34: Table 2-8: Com1 Ri Pin Setting (J6)

    Table 2-8: COM1 RI pin setting (J6) +5 V +12 V * RI (default setting) Table 2-9: COM2 RI pin setting (J7) +5 V +12 V * RI (default setting) PCM-9576F User's Manual...

  • Page 35: Table 2-10: Com3 Ri Pin Setting (J7)

    Table 2-10: COM3 RI pin setting (J7) (optional) +5 V +12 V * RI (default setting) Table 2-11: COM4 RI pin setting (J7) (optional) +5 V +12 V * RI (default setting) Chapter 2 Installation...

  • Page 36: Vga Interface Connections (Optional)

    CN18 is a 40-pin connector which can support a 24-bit TFT LCD. It is Hirose’s product no. DF13A-40DP-1.25V. The PCM-9576F provides a bias control signal on CN18 that can be used to control the LCD bias voltage. It is recommended that the LCD bias voltage not be applied to the panel until the logic supply voltage (+5 V or +3.3 V) and panel video signals are stable.

  • Page 37: Vga (Sw2)

    2.18.4 LCD Panel type select (SW2) SW2 is a 7-pin dip switch for LCD Panel type select SW2: Panel type select (optional) t l u *default setting Chapter 2 Installation...

  • Page 38: Optional Video Out Interfaces (Cn26)

    1. Run the appropriate installation software program, located in the utility disk. 2.20 Ethernet configuration The PCM-9576F is equipped with a high performance 32-bit PCI-bus Ethernet interface which is fully compliant with IEEE 802.3U 10/100Mbps CSMA/CD standards. It is supported by all major network operating systems.

  • Page 39: 100Base-T Connector (Cn1, Cn4, Cn5)

    CN4 (2nd lan) and CN5 (3rd lan). When users only use one ethernet interface, they have to use the 1st lan interface (CN1). 100Base-T connects to the PCM-9576F via an adapter cable to a 10-pin polarized header (CN1, CN4, CN5). For 10/100Base-T RJ-45 operation, an adapter cable converting CN1, CN4, CN5 into a standard RJ-45 jack is required.

  • Page 40: Lan Controller Power Select(J12)

    +5 V* standby 5 V * default setting Note: PCM-9576F supports wake-on on LAN. For wake- on LAN,J12 has to select standby 5 V (2-3 position) 2.21 Watchdog timer configuration An on-board watchdog timer reduces the chance of disruptions which EMP (electro-magnetic pulse) interference can cause.

  • Page 41: Usb Connectors (Cn21)

    USB connector on the other. The USB interfaces can be disabled in the system BIOS setup. 2.23 GPIO (CN6) The PCM-9576F supports general purpose out; CN6. The 3 digital outputs can control output devices by programming. Chapter 2 Installation...
  • Page 42 PCM-9576F User's Manual...

  • Page 43: Chapter 3 Award Bios Setup

    Award BIOS Setup This chapter describes how to set BIOS configuration data.

  • Page 44: System Test And Initialization

    3. The CMOS memory has lost power and the configuration information has been erased. The PCM-9576F’s CMOS memory has an integral lithium battery backup. The battery backup should last ten years in normal service, but when it finally runs down, you will need to replace the complete unit.

  • Page 45: Award Bios Setup

    3.2 Award BIOS setup Award’s BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. 3.2.1 Entering setup Power on the computer and press <Del>...

  • Page 46: Standard Cmos Setup

    This standard Setup Menu allows users to configure system components such as date, time, hard disk drive, floppy drive and display. Once a field is highlighted, on-line help information is displayed in the left bottom of the Menu screen. Figure 3-2: CMOS setup screen PCM-9576F User's Manual...

  • Page 47: Bios Features Setup

    3.2.3 BIOS features setup By choosing the BIOS FEATURES SETUP option from the INITIAL SETUP SCREEN menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9576F. Figure 3-3: BIOS features setup Chapter 3 Award BIOS Setup...

  • Page 48: Chipset Features Setup

    3.2.4 Chipset features setup By choosing the CHIPSET FEATURES SETUP option from the INITIAL SETUP SCREEN menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9576F. Figure 3-4: Chipset features setup PCM-9576F User's Manual...

  • Page 49: Power Management Setup

    3.2.5 Power management setup By choosing the POWER MANAGEMENT SETUP option from the INITIAL SETUP SCREEN menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9576F. Figure 3-5: Power management setup Chapter 3 Award BIOS Setup...

  • Page 50: Pnp/Pci Configuration

    3.2.6 PnP/PCI configuration By choosing the PnP/PCI CONFIGURATION option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9576F. Figure 3-6: PnP/PCI configuration PCM-9576F User's Manual...

  • Page 51: Integrated Peripherals

    By choosing the INTEGRATED PERIPHERALS option from the INITIAL SETUP SCREEN menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9576F. The PANEL TYPE by default supports an 18-bit 640 x 480 TFT LCD panel display. Figure 3-7: Integrated peripherals...

  • Page 52: Load Bios Defaults

    LOAD BIOS DEFAULTS loads the default system values directly from ROM. If the stored record created by the Setup program becomes corrupted (and therefore unusable), these defaults will load automatically when you turn the PCM-9576F on. Figure 3-8: Load BIOS defaults PCM-9576F User's Manual...

  • Page 53: Change Password

    3.2.9 Change password To change the password, choose the PASSWORD SETTING option form the Setup main menu and press <Enter>. 1. If the CMOS is bad or this option has never been used, a default password is stored in the ROM. The screen will display the following messages: Enter Password: Press <Enter>.

  • Page 54: Auto Detect Hard Disk

    This record is required for the system to operate. 3.2.12 Exit without saving Selecting this option and pressing <Enter> lets you exit the Setup program without recording any new values or changing old ones. PCM-9576F User's Manual...

  • Page 55: Chapter 4 Pci Svga Setup (Optional)

    PCI SVGA Setup (Optional) • Introduction • Installation of SVGA Driver - for Windows 95/98/ME - for Windows NT/2000 • Further Information Chapter 4 PCI SVGA Setup...

  • Page 56: Introduction

    4.1 Introduction The PCM-9576F has an onboard AGP flat panel/VGA interface. The specifications and features are described as follows: 4.1.1 Chipset The PCM-9576F uses a LynxEM SMI 710/721 chipset from Silicon Motion Inc. for its AGP/SVGA controller. It supports many popular LCD, EL, and gas plasma flat panel displays and conventional analog CRT monitors.

  • Page 57: Dual/Simultaneous Display

    4.1.4 Dual/simultaneous display The PCM-9576F uses a SMI Lynx 710/721 LCD controller that is capable of providing multiple views and simultaneous display with mixed video and graphics on a flat panel and CRT. To set up dual display under Windows 98, Windows ME, Windows NT, follow these steps: 1.

  • Page 58: Installation Of Svga Driver

    Complete the following steps to install the SVGA driver. Follow the procedures in the flow chart that apply to the operating system that you you are using within your PCM-9576F. Important: The following windows illustrations are examples only. You must follow the flow chart instructions and pay attention to the instructions which then appear on your screen.

  • Page 59: Installation For Windows 95

    4.2.1 Installation for Windows 95 a. Select "Start", "Settings", "Control Panel", "Display", "Settings". b. Press the "Advanced Properties". a. Choose the "Adapter" label. Press the "Change..." button. Press the "Have Disk" button. Chapter 4 PCI SVGA Setup...
  • Page 60 Type the path: D:\ Biscuit\9572\VGA\ SM721\Win98&Me a. Select the highlighted item. Click the "OK" button. "Silicon Motion LynxEM" appears in the adapter label. Click the "Apply" button. Click the "OK" button. Press "Yes" to reboot. PCM-9576F User's Manual...

  • Page 61: Installation For Windows 98/Me

    4.2.2 Installation for Windows 98/ME a. Select "Start", "Settings", "Control Panel", "Display", "Settings". b. Press the "Advanced..." button. a. Choose the "Adapter" label. Press the "Change..." button. Choose the second option: "Display...". Press the "Have Disk..." button. Chapter 4 PCI SVGA Setup...
  • Page 62 Insert the disc into the CD-ROM drive. Type the path "D:\ Biscuit\9572\VGA\ SM721\Win98&Me" Press "OK". a. Select the highlighted item. Click the "OK" button. "Silicon Motion LynxEM" appears in the adapter label. Click the "Apply" button. Press "Yes" to reboot. PCM-9576F User's Manual...

  • Page 63: Installation For Windows Nt/2000

    4.2.3 Installation for Windows NT/2000 Note: Service Pack X (X = 3, 4, 5, 6, ...) must be installed first before you install the Windows NT VGA driver. a. Select "Start", "Settings", "Control Panel". b. Double click the "Display" icon. a.
  • Page 64 Type the path "D:\ Biscuit\9576\VGA\ SMI721\WinNT40" Press the "OK" button. a. Select the highlighted item. Click the "OK" button. Press the "Yes" to proceed. Press "OK" to reboot. PCM-9576F User's Manual...

  • Page 65: Further Information

    4.3 Further Information For further information about the AGP/SVGA installation in your PCM-9576F, including driver updates, troubleshooting guides and FAQ lists, visit the following web resources: Silicon Motion Website: www.siliconmotion.com Advantech websites: www.advantech.com www. advantech.com.tw Chapter 4 PCI SVGA Setup...
  • Page 66 PCM-9576F User's Manual...

  • Page 67: Chapter 5 Pci Bus Ethernet Interface

    PCI Bus Ethernet Interface This chapter provides information on Ethernet configuration. • Introduction • Installation of Ethernet driver - Installation for Windows 95/98 - Installation for Windows NT • Further information...

  • Page 68: Introduction

    5.2 Installation of Ethernet driver Before installing the Ethernet driver, note the procedures below. You must know which operating system you are using in your PCM-9576F, and then refer to the corresponding installation flow chart. Then just follow the steps described in the flow chart. You will quickly and successfully complete the installation, even if you are not familiar with instructions for MS-DOS or WINDOWS.

  • Page 69: Installation For Windows 95/98 & Windows 2000

    5.2.2 Installation for Windows 95/98 & Windows 2000 a. Select "Start", "Settings", "Control Panel". b. Double click "Network". a. Click "Add" and prepare to install network functions. a. Select the "Adapter" item to add the Ethernet card. a. Click "Have Disk" to install the driver.

  • Page 70: Installation For Windows Nt

    CD-ROM drive. b. Type: D:\BISCUIT\ 9576\Lan\82559 D:\BISCUIT\9576\Lan\82559ER c. Click "OK". a. Choose the "82559ER" item. b. Click "OK". a. Make sure the configurations of relevant items are set correctly. b. Click "OK" to reboot. E N D PCM-9576F User's Manual...
  • Page 71 a. Select "Start", "Settings", "Control Panel". b. Double click "Network". a. Choose the "Adapters" label. b. Click the "Add" button. a. Press "Have Disk". a. Type "D:". b. Press "OK". D: OK Chapter 5 PCI Bus Ethernet Interface...
  • Page 72 CD-ROM drive. Type: D:\BISCUIT\ 9576\Lan\82559ER D:\BISCUIT\9576\Lan\82559ER c. Click "OK". a. Choose the "82559ER" item. b. Click "OK". a. Make sure the configurations of relevant items are set correctly. b. Click "OK" to reboot. E N D PCM-9576F User's Manual...

  • Page 73: Further Information

    5.3 Further information ® Intel website: www.intel.com Advantech websites:www.advantech.com www.advantech.com/support Chapter 5 PCI Bus Ethernet Interface...
  • Page 74 PCM-9576F User's Manual...

  • Page 75: Appendix A Programming The Watchdog Timer

    Programming the Watchdog Timer The PCM-9576F is equipped with a watchdog timer that resets the CPU or generates an interrupt if processing comes to a standstill for whatever reason. This feature ensures system reliability in industrial standalone, or unmanned, environments.

  • Page 76: Programming The Watchdog Timer

    After data entry, your program must refresh the watchdog timer by rewriting the I/O port 443 (hex) while simultaneously setting it. When you want to disable the watchdog timer, your program should read I/O port 443 (hex). PCM-9576F User's Manual...
  • Page 77 The following example shows how you might program the watchdog timer in BASIC: REM Watchdog timer example program OUT &H443, data REM Start and restart the watchdog GOSUB 1000 REM Your application task #1 OUT &H443, data REM Reset the timer GOSUB 2000 REM Your application task #2 OUT &H443, data...
  • Page 78 PCM-9576F User's Manual...

  • Page 79: Appendix B Installing Pc/104 Modules

    Installing PC/104 Modules This appendix gives instructions for installing PC/104 modules.

  • Page 80: Installing Pc/104 Modules

    (Refer to the diagram on the following page.) 4. Mount the PC/104 module onto the CPU card by pressing the module firmly but carefully onto the mounting connectors. 5. Secure the PC/104 module onto the CPU card using the four mounting spacers and screws. PCM-9576F User's Manual...

  • Page 81: Figure B-1: Pc/104 Module Mounting Diagram

    Figure B-1: PC/104 module mounting diagram 8 .9 8 2 .5 9 5 .9 ∅ 9 0 .8 6 .4 9 0 .8 ∅ 3 .2 5 .1 5 .1 5 .1 8 5 .1 9 0 .2 Figure B-2: PC/104 module dimensions (mm) (±0.1) Appendix B Installing PC/104 Modules...

  • Page 82: Table B-1: Pc/104 Connectors (Cn10)

    SA10 IRQ7 — — IRQ6 — — IRQ5 — — IRQ4 — — IRQ3 — — DACK2* — — — — BALE — — +5 V — — — — — — — — * active low PCM-9576F User's Manual...

  • Page 83: Appendix C Pin Assignments

    Pin Assignments This appendix contains information of a detailed or specialized nature. It includes: • Ethernet 10/100Base-T connector (CN 1,4,5) • ATX power feature connector (CN 2) • Keyboard and PS/2 mouse connector (CN 7) • Main power connector (CN 9) •...

  • Page 84: Ethernet 10/100Base-T Connector (Cn4, Cn5)

    Table C-1: Ethernet 10Base-T connector (CN4, CN5)) Signal CRS LED RCV+ RCV- BNC LED XMT+ XMT- C.2 ATX power feature connector (CN2) Table C-2: ATX power feature connector (CN2) Signal 5 V SB (Stand-by voltage) 5 V SB (VPSON) PCM-9576F User's Manual...

  • Page 85: Keyboard And Ps/2 Mouse Connector (Cn7)

    C.3 Keyboard and PS/2 mouse connector (CN7) Table C-3: Keyboard and mouse connector (CN7) Signal MS VCC MS DATA MS CLOCK KB VCC KB DATA KB CLOCK Appendix C Pin Assignments...

  • Page 86: Main Power Connector (Cn9)

    C.4 Main power connector (CN9) Table C-4: Main power connector (CN9) Signal +12 V +5 V C.5 IR connector (CN10) Table C-5: IR connector (CN10) Signal IR IN IR OUT PCM-9576F User's Manual...

  • Page 87: Floppy Drive Connector (Cn11)

    C.6 Floppy drive connector (CN11) Table C-6: Floppy drive connector (CN11) Signal Signal DENSITY SELECT* DRIVE TYPE INDEX* MOTOR 0* DRIVE SELECT 1* DRIVE SELECT 0* MOTOR 1* DIRECTION* STEP* WRITE DATA* WRITE GATE* TRACK 0* WRITE PROTECT* READ DATA* HEAD SELECT* DISK CHANGE* * low active...

  • Page 88: Ide Hard Drive Connecto(Cn13)

    DATA 14 DATA 0 DATA 15 SIGNAL GND HDD 0 IO WRITE IO READ HD READY HDACK 0* IRQ14 ADDR 1 ADDR 0 ADDR 2 HARD DISK SELECT 0* HARD DISK SELECT 1* IDE ACTIVE* * low active PCM-9576F User's Manual...

  • Page 89: Parallel Port Connector (Cn14)

    C.8 Parallel port connector (CN14) Table C-8: Parallel port connector (CN14) Signal Signal STROBE* AUTOFD* INIT* SLCTINI* ACK* BUSY SLCT * low active Appendix C Pin Assignments...

  • Page 90: Backlight Connector (Cn25) Optional

    C.9 Backlight connector (CN25) optional Table C-9: Backlight connector (CN25) Signal +12 V Enable Reserved N.C. C.10 Peripheral power connector (CN16) Table C-10: Peripheral power connector (CN16) Function -5 V -12 V PCM-9576F User's Manual...

  • Page 91: Crt Display Connector (Cn17)

    C.11 CRT display connector (CN17) Table C-11: CRT display connector (CN17) Signal Signal SIGNAL GND DDC power H-SYNC GREEN Signal GND SIGNAL GND V-SYNC BLUE Signal GND Signal GND DDC_DAT Chassis GND Appendix C Pin Assignments...

  • Page 92: 24-Bit Lcd Display Connector (Cn18) Optional

    PD1 (R6) PD0 (R7) SHIFT CLOCK DCLK (reserved) ENAVEE Note 1: The model number of the CN16 connector is DF13A-40DP-1.25V (Hirose Electric Co., Ltd.) Note 2: The signals shown in parentheses are for 24-bit TFT color bits. PCM-9576F User's Manual...

  • Page 93: Ext. Lcd Display Connector (Cn19) Optional

    C.13 Ext. LCD display connector (CN19) optional Table C-13: Ext. LCD display connector (CN19) Signal Signal PD24 PD25 PD26 PD27 PD28 PD29 PD30 PD31 PD32 PD33 PD34 PD35 Note 1: The model number of the CN17 connector is DF13A-20DP-1.25V (Hirose Electric Co., Ltd.). The model number of the CN16 connector is DF13A-40DP-1.25V (Hirose Electric Co., Ltd.).

  • Page 94: Lcd Signal Mapping

    Table C-14: LCD signal mapping Pin Name 16-bit DSTN 18-bit TFT 24-bit TFT 36-bit TFT PD10 PD11 PD12 PD13 PD14 PD15 PD16 PD17 PD18 PD19 PD20 PD21 PD22 PD23 PD24 PD25 PD26 PD27 PD28 PD29 PD30 PD31 PD32 PD33 PD34 PD35 PCM-9576F User's Manual...

  • Page 95: Front Panel Connector (Cn20)

    C.15 Front panel connector (CN20) Table C-15: Front panel connector (CN20) Signal HDD LED- (HARD DISK ACTIVE) HDD LED+ (V SPEAKER+ SPEAKER- (GND) WATCHDOG OUTPUT* RESET SWITCH- (GND) RESET SWITCH+ * low active C.16 USB connectors (CN21) Table C-16: USB connectors (CN21) Signal Signal +5 V...

  • Page 96: Com Port Connector (Cn22)

    C.17 COM PORT connector for 4COM port (CN22) 40 38 Table C-17: COM port connector (CN22) Signal Signal DCD1 DSR1 RTS1 CTS1 DTR1 DCD2 DSR2 RTS2 CTS2 DTR2 DCD3 DSR3 RTS3 CTS3 DTR3 DCD4 DSR4 RTS4 CTS4 DTR4 PCM-9576F User's Manual...

  • Page 97: Table C-18: Com2 Port For Rs-232, Rs-422 And Rs-485 (Cn22)

    Note1 : The cable of serial port (CN22) comes with four DSUB-9 male connectors. The pin assignments of each DSUB-9 connector are listed below for your reference: Note2 : PCM-9576 standard configuration is 2 RS-232 ports (CN22 is pin1-p20). 1 additional RS/232/422/485 and 1 RS-232 port, CN22 is pin1-pin40 (optional).

  • Page 98: Compactflash™ Card Connector (Cn24)

    C.18 CompactFlash™ card connector (CN24) Table C-19: CompactFlash card connector (CN24) Signal Signal -CS0 -ATA SEL -IOCS16 -CD2 -CD1 -CS1 -VS1 -IORD -IOWR INTRQ -CSEL -VS2 -RESER IORDY -INPACK -REG -DASP -PDIAG PCM-9576F User's Manual...

  • Page 99: Fan Power Connector (Fan1)

    C.19 Fan power connector (FAN1) Table C-20: Fan power connector (FAN1) Signal +12 V Appendix C Pin Assignments...
  • Page 100 PCM-9576F User's Manual...

  • Page 101: Appendix D System Assignments

    System Assignments • System I/O ports • 1st MB memory map • DMA channel assignments • Interrupt assignments...

  • Page 102: System I/O Ports

    D.1 System I/O ports Table D-1: System I/O ports Addr. range (Hex) Device 000-01F DMA controller 020-021 Interrupt controller 1, master 022-023 Chipset address 040-05F 8254 timer 060-06F 8042 (keyboard controller) 070-07F Real-time clock, non-maskable interrupt (NMI) mask 080-09F DMA page register, 0A0-0BF Interrupt controller 2 0C0-0DF...

  • Page 103: 1St Mb Memory Map

    D.2 1st MB memory map Table D-2: 1st MB memory map Addr. range (Hex) Device F000h - FFFFh System ROM D000h - EFFFh Unused *CC00h - CFFFh Ethernet ROM C000h - CBFFh Expansion ROM B800h - BFFFh CGA/EGA/VGA text B000h - B7FFh Unused A000h - AFFFh EGA/VGA graphics...

  • Page 104: Irq Mapping Chart

    D.4 IRQ mapping chart Table D-4: IRQ mapping chart Interval timer Keyboard Interrupt from Controller 2 COM2 COM1 (Reserved) (COM4) LPT1 Reserved (Reserved) COM3 Reserved (watchdog timer) PS/2 mouse INT from co-processor Primary IDE Secondary IDE (reserved for CompactFlash) * Ethernet interface IRQ select: 5, 9, 10, 11, 12, 15 * PnP USB IRQ select: 5, 9, 10, 11, 12, 15 PCM-9576D User's Manual...

  • Page 105: Appendix E Optional Extras

    Optional Extras...

  • Page 106: Pcm-10586- 4E Cable Kit For Pcm-9576

    E.1 PCM-10586- 4E cable kit for PCM-9576 The PCM-9576F requires several cables for normal operation. You can make them yourself or purchase an optional cable kit assembly, which includes the following: " 5 " 8 , n i o l f "...

  • Page 107: 4Com Cable And Vga Cable

    E.2 4COM Cable and VGA Cable The 4COM cable part no. is 1700400000. VGA Cable part no. is 1700160150 E.3 USB cable Optional USB cable, part no: 1703100260 E.4 24-bit LCD cable adapter This converts from the Hirose “DF20A” type connector transfer to a 20 x 2-pin header.
  • Page 108 PCM-9576F User's Manual...

  • Page 109: Appendix F Mechanical Drawings

    Mechanical Drawings...

  • Page 110: Component Side

    F.1 Component side Figure F-1: PCM-9576F mechanical drawing - component side PCM-9576 User's Manual...

  • Page 111: Solder Side

    F.2 Solder side Figure F-2: PCM-9576F mechanical drawing - solder side Appendix F Mechanical Drawings...
  • Page 112 PCM-9576 User's Manual...

Table of Contents
