Advantech PCM-9588 Startup Manual

PCM-9588 Intel® Celeron® M EBX SBC with DVI/ TTL/
VGA/ LVDS/ LAN/ 6 COM/ 2 SATA/ 6 USB2.0/16-bit GPIO
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 PCM-9588 all-in-one single board computer
• 1 Startup manual
• 1 CD disk for utility and drivers
• 1 Mini Jumper (10 pcs package) p/n: 9689000002
• 1 ATX power cable p/n: 1700001112
• 1 AT power cable P/N:1700006196
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note 1: For detailed contents of PCM-9588, please refer
to information on the enclosed CD-ROM (in PDF
format).
Note 2: Acrobat Reader is required to view any PDF
file.Acrobat Reader can be downloaded at:
www.adobe.com/Products/acrobat/readstep2.
html (Acrobat is a trademark of Adobe)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our
support website at:
http://service.advantech.com.tw/eservice/
This manual is for the PCM-9588 series Rev. A1.
Part No. 2006958800
Printed in China
Specifications
General
• CPU: Intel® Celeron® M series
• 2nd Cache Memory:
• System Chipset: Intel 910GMLE/ICH6M Chipset
• BIOS: AWARD 4 Mbit Flash BIOS
• System Memory: 1 x 200-pin SODIMM sockets, DDR2
400MHz up to 2 GB
• Power Management: APM 1.2, ACPI support
• Watchdog Timer: 255-level interval timer
• Expansion Interface: PC-104 plus
• Battery: Lithium 3 V / 196 mA
I/O
• I/O Interface: 1 x EIDE (UDMA 33/66/100/133), 2 x SATA
150, 1 x K/B, 1 x Mouse, 4 x RS232, 2 x RS232/422/485
(Default RS-422/485, RS-232 by optional request), 1 x
LPT and 1 x EIDE device
• USB: 6 x USB 2.0 compliant Ports
• Audio: AC97, Line-in, Line-out, Mic-in, speaker out (R/L)
• IrDA: 115kbps (optional by request) shared from COM2
• GPIO: 16-bit General Purpose I/O
Ethernet
• Chipset: 1 x Realtek RTL8100CL-LF (Optional
RTL8110SCL-LF for Giga LAN)
• Speed: 10/100 Mbps (1000Mbps for optional)
• Interface: 1 x RJ45 by cable
• Standard: IEEE 802.3u 100Base-T (IEEE 802.3ab
1000Base-T for optional)
Display
• Controller: Intel 910GMLE
• VRAM: Optimized Shared Memory Architecture up to
128 MB system memory
• VGA: QXGA (2048 x 1536)
• LVDS LCD: 1 x 48-bit LVDS
• DVI: 36bit DVI (PCM-9588F-S0A1E only)
• TTL LCD: Support 18/36bit TTL
• Dual Independent Display: CRT+ LVDS / DVI+
LVDS/ DVI+ CRT/ CRT+ TTL/ TTL+DVI
1st Edition,
Dec. 2008
Celeron® M 600 MHz: PCM-9588T-M0A1E
Celeron® M 1.0 GHz: PCM-9588F-S0A1E
Celeron® M 600MHz: 512KB
Celeron® M 1.0GHz: 0KB
PCM-9588 Startup Manual
