Advantech PCM-9579 Startup Manual

PCM-9579 EBX ULV Intel Celeron / LV Intel
Pentium III SBC with CPU, VGA/ LCD, LVDS,
Ethernet, and Audio
Startup Manual
Packing List
Before you beg in installing your card, please make sure
that the following materials have been shipped:
• 1 PCM-9579 all-in-one single board computer
• 1 startup manual
• CD-ROM or disks for utility, drivers, and manual (in PDF
format)
• 1 power cable p/n: 1703080101
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Note: For detailed contents of the PCM-9579,
please refer to the enclosed CD-ROM or disk
(in PDF format)
.
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our
support website at:
http://service.advantech.com.tw/eservice/
This manual is for the PCM-9579 series Rev. A1.
Part No. 2006957901
Standard SBC Functions
• CPU: Embedded Intel® Ultra Low Voltage Celeron™
• BIOS: Award 256 KB Flash memory
• System memory: One DIMM socket accepts 64 MB up
• 2nd cache memory: 256/512 KB on the processor
• Enhanced IDE interface: Two channels supports up to
• FDD interface: Supports up to two FDDs
• Serial ports: Four serial RS-232 ports, COM1, 3, 4: RS-
• Parallel port: One parallel port, supports SPP/EPP/ECP
• Infrared port: Shared with COM2
• Keyboard/mouse connector: Supports standard PC/
• Power management: Supports power saving modes
• Watchdog timer: 62 level timer intervals
• USB: Four universal serial bus ports
• Expansion: One PCI slot and PC/104 plus connector for
Solid State Disk
• Supports one 50-pin socket for CFC type I/II
• Supports M-Systems DOC
VGA/LCD Interface
• Chipset: VIA Twister chip with integrated Savage4 2D/
• Frame buffer: Supports 8/16/32MB frame buffer with
• Interface: 4X AGP VGA/LCD interface, Support for 9,
• Display mode: CRT Modes: 1920 x1440 @16bpp, 1280
• LVDS: Supports 2 Channel 18bit LVDS interface
2nd Edition
September 2003
Specifications
or
Low Voltage Pentium® III Processor, on die 32KB LI
cache memory ULV Celeron-400 (PCM-9579F-J0A1),
ULV Celeron-650 (PCM-9579F-M0A1), LV Pentium III-
933 (PCM-9579F-R0A1)
to 512 MB SDRAM
four EIDE devices. BIOS auto-detect, PIO Mode 3 or
Mode 4, UDMA 33 transfer. Primary IDE support up to
UDMA 66/100 mode
232, COM2: RS-232/422/485
mode
AT keyboard and a PS/2 mouse
including Normal/Standby/Suspend modes. APM 1.2
compliant
ISA and PCI I/O board
3D/Video Accelerator
system memory
12, 15, 18, 24, 36 bit TFT and 16- or 24-bit DSTN panel
x 1024@16bpp (60Hz), 1024 x 768@16bpp (85Hz);
LCD/Simultaneous Modes: 1280 x 1024@16bpp (60Hz),
1024 x 768@16bpp (60Hz)
PCM-9579 Startup Manual
®
